I N S T A L L A T I O N I N S T R U C T I O N S
Horizontal Array Pole Clamp
Model: MSP-WTIKTA220
The WTIKTA220 pivot array allow horizontal (yaw),
vertical (pitch), and roll display adjustment. The pitch
adjustment range is 30° (15° up / 15° down). The mount
will pivot nearly full circle, depending on the mounting
base.
The mount is designed to mount two or three 17"
displays.
The mount accommodates standard VESA® 75mm/
100mm compliant displays.
BEFORE YOU BEGIN
CAUTION: To prevent damage to your display, which could affect or void the Factory warranty, thoroughly study all
instructions and illustrations before you begin to install the mount. Pay particular attention to the "Important Warnings
and Cautions" on Page 2.
CAUTION: The combined weight of the display(s) installed must not exceed 34 lbs (15.4 kg).
Pay particular attention to the Weight Specifications detailed on page 2.
If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480.
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY, STE 700
SAVAGE, MINNESOTA 55378 USA
8832-000241
2007 Chief Manufacturing
www.chiefmfg.com
08/07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSP-WTIKTA220 and is the answer not in the manual?

Questions and answers

Summary of Contents for CHIEF MSP-WTIKTA220

  • Page 1 CAUTION: The combined weight of the display(s) installed must not exceed 34 lbs (15.4 kg). • Pay particular attention to the Weight Specifications detailed on page 2. • If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480. CHIEF MANUFACTURING INC. 8832-000241 2007 Chief Manufacturing 1-800-582-6480 952-894-6280 FAX 952-894-6918 www.chiefmfg.com...
  • Page 2: Table Of Contents

    Model: MSP-WTIKTA220 Installation Instructions IMPORTANT WARNINGS AND CAUTIONS! WARNING: A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. CAUTION: A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow the corresponding instructions.
  • Page 3: Tools Required For Installation

    Unpack carton and verify kit contents . Read installation SCREW, Phillips Pan Head, M4 x 20mm instructions completely. If any listed cparts are missing, contact Chief Customer Service at 1-800-582-6480. SCREW, Phillips Pan Head, M4 x 30mm SPACER, Nylon, 3/8" (used with item 40) SPACER, Nylon, 3/4"...
  • Page 4: Installation

    Model: MSP-WTIKTA220 Installation Instructions INSTALLATION M4 x 12mm Phillips Pan Head Screw (30) 1. Remove pole mount back from pole mount front by loosening and removing 3 BHCS using 5/32" hex key. (See Figure 2) 2. Secure pole mount back to pole mount front and pole by tightening three BHCS using 5/32"...
  • Page 5: Attach Centris Head To Recessed Mount Display

    Installation Instructions Model: MSP-WTIKTA220 Attach Centris Head to Recessed Mount Display Phillips Pan Head Screw (40 or 50) CAUTION: If display uses a screw size other than those included in the kit, DO NOT use the screws provided. Using the wrong screws could result in Centris Head damage to your monitor.
  • Page 6: Adjustments

    Model: MSP-WTIKTA220 Installation Instructions Display Adjustment The WTIKTA220 allows horizontal, pitch, roll, and yaw Array Rail adjustment of each display with a maximum pitch range of 15° up and 15° down. End Lock The WTIKTA220 also allows a full 360 deg. of display roll.
  • Page 7 Installation Instructions Model: MSP-WTIKTA220...
  • Page 8 Model: MSP-WTIKTA220 Installation Instructions...
