CHIEF PWS Installation Instructions

I N S T A L L A T I O N
Plasma Wall Swing-Out (PWS)
Wall Mount
The PWS wall mount is a rugged, versatile, and installer-friendly
solution to unique display mounting requirements. This instruction
manual contains instructions for Model PWS2000.
With the PWS securely mounted on a wall, simply hang your display
like a picture (vertical or horizontal). Using the Q-latch mounting sys-
tem permits you to hang and secure your display quickly.
The PWS allows you pull your display out 23.5" from the wall, pivot
it up to 90 degrees left or right of center, traverse up to 22" left or
right of center, and adjust the pitch 5 degrees up and 15 degrees down.
The PWS also provides 2 degrees roll adjustment right and left for
screen leveling.
Two electrical box openings in the wall plate is provided for cabling.
The cable tray hides cables for aesthetics and cable protection.
BEFORE YOU BEGIN
• Caution: To prevent damage to the PWS, which could affect or void the Factory warranty, and to the equipment that
will be attached to it, thoroughly study all instructions and illustrations before you begin the installation. Pay particu-
lar attention to the "Important Warnings and Precautions" on Page 1.
• The maximum weight to be installed on the PWS wall mount is 100 pounds (45.36Kg).
• The PWS wall mount is designed to be installed using wall studs or supporting framework. The wall to which the PWS wall
mount is anchored must be capable of supporting four times the total weight of the mount and all attached equipment.
• If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480.
