Summary of Contents for CHIEF PDC Series
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Large Dual Ceiling Mount PDC Series...
-
Page 2: Installation Instructions
IMPORTANT ! : The PDC Series mounts are designed to be mounted to a 1-1/2" NPT or NPSM following ANSI/ASME B1.20.1 (Schedule 40, 0.154" minimum thickness steel or... - Page 3 Installation Instructions PDC Series DIMENSIONS NOTE: PSBU INTERFACE BRACKETS NOT SHOWN. THE PSBU INTERFACE BRACKET WILL ADD 1” IN DEPTH AND MAY AFFECT THE LOCATION OF THE DISPLAY ON THE MOUNT. ON PSBU GOES HERE 1-1/2" NPSM FACE TILTS UP 5...
-
Page 4: Tools Required For Installation
Installation Instructions PDC Series TOOLS REQUIRED FOR INSTALLATION 9/16" 5/32" (included) PARTS B (1) 5/32" C (1) 5/16-18 x 3/8" A (1) [PDC assembly]... -
Page 5: Installation
Installation Instructions PDC Series INSTALLATION Attaching Interface Bracket to Displays Attach PSBU interface brackets to displays following instructions included with interface brackets. WARNING: FAILURE TO PROVIDE ADEQUATE Installing Displays on PDC STRUCTURAL STRENGTH FOR THIS COMPONENT CAN RESULT IN SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! It is the installer’s responsibility to make... - Page 6 PDC Series Installation Instructions Lower each display into place listening for audible "click" to ensure recessed area of mounting buttons are properly Remove bolt or seated in lower area of mounting holes. (See Figure 2) and padlock if used (See Figure 3) Pins in "Closed"...
- Page 7 Installation Instructions PDC Series Adjustments Roll Adjustment Loosen two Nylock nuts inside the PDC. (See Figure 5) Using the slotted holes, adjust the roll, or horizontal movement. Tighten two Nylock nuts. (Display and faceplate removed for clarity) Figure 5 Pitch Adjustment Loosen two screws on side of PDC.
- Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
