CHIEF MF1 Series Installation Instructions Manual
Single and dual display floor stands
Hide thumbs
Also See for MF1 Series:
- Installation instructions manual (12 pages) ,
- Brochure (16 pages) ,
- Installation instructions manual (12 pages)
Related Manuals for CHIEF MF1 Series
Summary of Contents for CHIEF MF1 Series
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Single and Dual Display Floor Stands MF1, MF2, PF1, PF2 Series...
-
Page 2: Important Warnings And Cautions
MF1, MF2, PF1, PF2 Series DISCLAIMER CSAV, Inc., and its affiliated corporations and subsidiaries (collectively, "CSAV"), intend to make this manual accurate and complete. However, CSAV makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product. -
Page 3: Installation Instructions
Installation Instructions DIMENSIONS [1316] 51-7/8 [889] [661] [431] [2180] 85-7/8 [1211] 47-5/8 [39] 1-1/2 [44] [65] 1-3/4 2-1/2 [1463] 57-5/8 [2327] 91-5/8 MF1, MF2, PF1, PF2 Series MF1, MF2 PF1, PF2... - Page 4 Installation Instructions LEGEND Tighten Fastener Apretar elemento de fijación Befestigungsteil festziehen Apertar fixador Serrare il fissaggio Bevestiging vastdraaien Serrez les fixations Loosen Fastener Aflojar elemento de fijación Befestigungsteil lösen Desapertar fixador Allentare il fissaggio Bevestiging losdraaien Desserrez les fixations Phillips Screwdriver Destornillador Phillips Kreuzschlitzschraubendreher Chave de fendas Phillips...
-
Page 5: Tools Required For Installation
Installation Instructions TOOLS REQUIRED FOR INSTALLATION 3/16" (included) PARTS B (1) (Single Display Models Only) [(2) for Single Display Models] [(4) for Dual Display Models] L (12) 5/16-18 x 1/2" 1/4" (To remove base plates from packaging) A (1) (PF Only) [(2) for Dual Display Models] E (1) - Page 6 MF1, MF2, PF1, PF2 Series ASSEMBLY CAUTION: Attachment holes may be damaged if a power drill is used to insert button head cap screws. Screws should first be inserted and turned BY HAND with the hex key or with a handheld screwdriver BEFORE using the hex head drill bit and power drill to complete the attachment.
- Page 7 Installation Instructions Figure 5 Place top base section and center post assembly on top of the four base pieces. (See Figure 6) Fasten lower base pieces to top base section and center post assembly using twelve 5/16-18 x 1/2" flat head cap screws (L).
- Page 8 MF1, MF2, PF1, PF2 Series Attaching Display to Stand WARNING: EXCEEDING MAXIMUM WEIGHT CAPACITY MAY LEAD TO SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! It is the installer’s responsibility to ensure the total amount of weight placed on the stand does not exceed 125 lbs (56.70 kg) for the MF1, 250 lbs (113.40 kg) for the MF2 [125 lbs (56.70 kg) per faceplate];...
-
Page 9: Cable Management
Installation Instructions Tilting Display The display(s) can be tilted up to 15 either backward or forward from a straight upright position. In a dual stand, the tilting is only restricted by the size of the display. Turn knob counterclockwise on back of head assembly to loosen the tilt. -
Page 10: Using The Stand
MF1, MF2, PF1, PF2 Series Using the Stand CAUTION: This stand is intended for use only with the products and maximum weights indicated: 125 lbs (56.70 kg) for the MF1, 250 lbs (113.40 kg) for the MF2 [125 lbs (56.70 kg) per faceplate]; 200 lbs (90.72 kg) for the PF1, 400 lbs (181.44 kg) for the PF2 [200 lbs (90.72 kg) per faceplate]. - Page 11 Installation Instructions MF1, MF2, PF1, PF2 Series...
- Page 12 MF1, MF2, PF1, PF2 Series 8809-000039 Rev. C 2007 Chief Manufacturing www.chiefmfg.com 11/07 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620...
