7. RS-485 Installation and Set-up
Bit 07, No warning/warning:
Bit 07 = '0': There are no warnings. Bit 07 = '1': A warning has occurred.
Bit 08, Speed≠ reference/speed = reference:
Bit 08 = '0': The motor is running but the present speed is different from the preset speed refer-
ence. It might e.g. be the case when the speed ramps up/down during start/stop. Bit 08 = '1':
The motor speed matches the preset speed reference.
Bit 09, Local operation/bus control:
Bit 09 = '0': [STOP/RESET] is activate on the control unit or
Site
is selected. You cannot control the frequency converter via serial communication. Bit 09 = '1'
It is possible to control the frequency converter via the fieldbus/ serial communication.
Bit 10, Out of frequency limit:
Bit 10 = '0': The output frequency has reached the value in par. 4-11
par. 4-13
Bit 11, No operation/in operation:
Bit 11 = '0': The motor is not running. Bit 11 = '1': The frequency converter has a start signal or
7
the output frequency is greater than 0 Hz.
Bit 12, Drive OK/stopped, autostart:
Bit 12 = '0': There is no temporary over temperature on the inverter. Bit 12 = '1': The inverter
stops because of over temperature but the unit does not trip and will resume operation once the
over temperature stops.
Bit 13, Voltage OK/limit exceeded:
Bit 13 = '0': There are no voltage warnings. Bit 13 = '1': The DC voltage in the frequency
converter's intermediate circuit is too low or too high.
Bit 14, Torque OK/limit exceeded:
Bit 14 = '0': The motor current is lower than the torque limit selected in par. 4-18
Bit 14 = '1': The torque limit in par. 4-18
Bit 15, Timer OK/limit exceeded:
Bit 15 = '0': The timers for motor thermal protection and VLT thermal protection are not exceeded
100%. Bit 15 = '1': One of the timers exceeds 100%.
150
Motor Speed High Limit . Bit 10 = "1": The output frequency is within the defined limits.
NB!
All bits in the STW are set to '0' if the connection between the Interbus option and
the frequency converter is lost, or an internal communication problem has occurred.
