VLT HVAC Drive Design Guide
Save Drive Settings:
1.
2.
3.
4.
All parameters are now stored in the PC.
Load Drive Settings:
1.
2.
3.
4.
5.
All parameter settings are now transferred to
the drive.
A separate manual for MCT 10 Set-up Soft-
ware is available.
The MCT 10 Set-up Software Modules
The following modules are included in the
software package:
Ordering number:
Please order your CD containing MCT 10 Set-
up Software using code number 130B1000.
MCT 10 can also be downloaded from the
Danfoss Internet:
Area: Motion Controls.
Connect a PC to the unit via USB com
port
Open MCT 10 Set-up Software
Choose "Read from drive"
Choose "Save as"
Connect a PC to the unit via USB com
port
Open MCT 10 Set-up software
Choose "Open"– stored files will be
shown
Open the appropriate file
Choose "Write to drive"
MCT 10 Set-up Software
Setting parameters
Copy to and from frequency
converters
Documentation and print out of
parameter settings incl. dia-
grams
Ext. User Interface
Preventive Maintenance Sched-
ule
Clock settings
Timed Action Programming
Smart Logic Controller Set-up
, Business
WWW.DANFOSS.COM
®
MG.11.B2.02 - VLT is a registered Danfoss trademark
MCT 31
The MCT 31 harmonic calculation PC tool en-
ables easy estimation of the harmonic distor-
tion in a given application. Both the harmonic
distortion of Danfoss frequency converters as
well as non-Danfoss frequency converters
with different additional harmonic reduction
measurements, such as Danfoss AHF filters
and 12-18-pulse rectifiers, can be calculated.
Ordering number:
Please order your CD containing the MCT 31
PC tool using code number 130B1031.
MCT 31 can also be downloaded from the
Danfoss Internet:
WWW.DANFOSS.COM
Area: Motion Controls.
