- Page 1 Quick Start Guide S08PB16-EVK...
-
Page 2: Quick Start Guide
Quick Start Guide GET TO KNOW THE S08PB16-EVK Power/OSBDM Micro USB SW1 Reset JM60 BDM Header NC-19 20-NC NC-17 18-NC NC-15 16-NC NC-13 14-GND NC-2 1-PTA2 J2 Header NC-11 12-NC P3V3-4 3-PTA1 PTA3-9 10-NC NC-6 5-PTB5 PTB3-7 8-NC P3V3-8 7-PTB4... - Page 3 STEP-BY-STEP INSTRUCTIONS Connect the S08PB16-EVK to a PC using the included Micro USB cable to power/ OSBDM Micro USB connectors (J15) of S08PB16-EVK board. A green LED (D6) will illuminate, indicating power is on. The S08PB16-EVK comes pre-programmed with a demo to test the onboard RGB LED (D8), potentiometer (R38) and buttons (SW2, SW3).
- Page 4 Download installation of phone numbers within your region. software and documentation at WARRANTY www.nxp.com/S08PB16-EVK. Visit www.nxp.com/warranty for complete warranty information. www.nxp.com NXP and the NXP logo are trademarks of NXP B.V. All other product or service names are the property of their respective owners.
