  • Page 1 Quick Start Guide S08PT60-EVK...

  • Page 2: Quick Start Guide

    Quick Start Guide GET TO KNOW THE S08PT60-EVK Power/OSBDM Micro USB J13 JM60 SW1 Reset BDM Header GND-19 20-PTA3 PTB2-17 18-PTA2 J2 Header PTB0-15 16-AREF PTC7-13 14-GND J6 PT60 1-PTC5 NC-2 PTC6-11 12-PTE0 3-PTC4 P3V3-4 PTC1-9 10-PTB4 Header 5-PTB5 PTA5-6...
  • Page 3 STEP-BY-STEP INSTRUCTIONS Connect the S08PT60-EVK to a PC using the included micro USB cable to power/ OSBDM micro USB connectors (J7) of S08PT60-EVK board. A green LED (D5) will illuminate, indicating power is on. The S08PT60-EVK comes pre-programmed with a demo which leverages the on-board accelerometer.
  • Page 4 Download installation of phone numbers within your region. software and documentation at WARRANTY www.nxp.com/S08PT60-EVK. Visit www.nxp.com/warranty for complete warranty information. www.nxp.com NXP and the NXP logo are trademarks of NXP B.V. All other product or service names are the property of their respective owners.
