S32R294 EVB User Guide
Revision 2.0 (SCH-32157_B)
by: NXP Semiconductor
1
Introduction
This user's manual details the setup and configuration of the NXP S32R294 Evaluation Board
(hereafter referred to as the EVB). The EVB is intended to provide a mechanism for easy
customer evaluation of the S32R294 microprocessor, and to facilitate hardware and software
development.
For the latest product information, please speak to your NXP representative.
The EVB is intended for bench / laboratory use and has been designed using normal
temperature specified components (+70°C).
1.1
List of Acronyms
Table 1 provides a list and description of acronyms used throughout this document.
Table 1. List of Acronyms
Acronym
Description
ADC
Analog-to-Digital converter
RESET_B
External signal reset
Advertisement
Table of Contents
Related Manuals for NXP Semiconductors S32R294
Summary of Contents for NXP Semiconductors S32R294
- Page 1 NXP Semiconductor Introduction This user’s manual details the setup and configuration of the NXP S32R294 Evaluation Board (hereafter referred to as the EVB). The EVB is intended to provide a mechanism for easy customer evaluation of the S32R294 microprocessor, and to facilitate hardware and software development.
-
Page 2: Evb Features
S32R294 EVB User Guide Acronym Description Evaluation board Ground High voltage (1.8V and/or 3.3V) Light emitting diode Low voltage (0.82V) Microcontroller Microprocessor Oscillator POR_B Power-on reset Power Receive SIPI Serial Interprocessor Interface To be defined Transmit Ground Liquid Crystal Display... - Page 3 S32R294 EVB User Guide • FlexRAY interface • 3 CAN-FD interfaces: o 1x up to 8Mbps communication speed (CAN2) o 2x up to 5Mbps communication speed (CAN0, CAN1) • UART to Micro USB interface • 2 user switches and 4 user LEDs, freely connectable •...
-
Page 4: Mcu Power
S32R294 EVB User Guide Configuration This section details the configuration of EVB’s functional blocks. The EVB has been designed with ease of use in mind and has been segmented into functional blocks as shown in Figure 1. Detailed silkscreen legend has been used throughout the board to identify all switches, jumpers and user connectors. - Page 5 S32R294 EVB User Guide 3.1.1 Power Supply Connectors 2.1mm Barrel Connector – P26: Figure 2. 2.1mm Power Connector 3.1.2 Supply Routing and Jumpers The figure below shows how the MCU power domains are connected. 10 0T 10 1T 10 1T...
- Page 6 S32R294 EVB User Guide Table 2. MCU power selection jumpers Jumper Description Connects VDD Core supplies to 0.82V Connects VDD LV PLL supplies to 0.82V Connects VDD LV MIPI supplies to 0.82V Connects VDD HV PLL AUR supplies to 1.8V Connects VDD HV MIPI supplies to 1.8V...
-
Page 7: Reset Circuit
Reset Circuit S32R294 POR_B reset is connected to FS8510 PGOOD signal as well as a reset switch SW1 via jumper J3. An orange LED D5 is illuminated after 0.82V, 1.8V, 3.3V working correctly, and the PGOOD signal is forced high simultaneously by the FS8510 PMIC. -
Page 8: Mcu External Clock Circuit
S32R294 EVB User Guide Jumper Description J56 1->2 Enable bi-direction connection between FS8510 RST pin and RESET_B pin J56 2->3 Enable single direction connection between FS8510 RST pin and RESET_B pin MCU External Clock Circuit In addition to the internal 48 MHz oscillator, the MCU can be clocked by different external sources. - Page 9 S32R294 EVB User Guide Figure 5. Effective single ended configuration JTAG The EVB is fitted with 14-pin JTAG debug connector. The following diagram shows the 14-pin connector pinout (0.1” keyed header). Figure 6. JTAG connector pinout...
-
Page 10: Nexus Aurora
S32R294 EVB User Guide Nexus Aurora Table 4 shows the pinout of the 34-pin Samtec connector for the S32R294 Aurora interface. Table 4. Aurora Trace connector pinout Pin No Function Pin No Function TX0+ VREF TX0- TCK/TCKC/DRCLK TMS/TMSC/TxDataP TX1+ TDI/TxDataN... -
Page 11: Camera Serial Interface (Mipi-Csi2)
TEF810-ADPT) is required. Contact your local NXP representative for details on how to order this board. For single MIPI-CSI2 front end usage connector J37 must be used since the MIPI-CSI1 instance on the S32R294 device contains the PLL. See the S32R294 device RM for more details. Figure 8. MIPI-CSI2 connector pinout... - Page 12 S32R294 EVB User Guide Figure 9. RGMII Signal Connections to headers The S32R294 device supports both 3.3V and 1.8V supply and I/O levels for the ethernet interface, therefore the EVB includes support for both of these options. This can be selected by changing the connection of J64, as shown in the table below.
- Page 13 S32R294 EVB User Guide Figure 10. UART to USB interface 3.10 FlexRAY The EVB supports one FlexRay interface with an NXP TJA1080TS/N FlexRay transceiver (U8). For flexibility, the FlexRAY transceiver is connected to a FlexRAY connector P1. By default the FlexRAY interface is not enabled. To enable the FlexRAY interface the jumpers detailed in Table 6 need to be placed.
- Page 14 An external 256Mbits Serial NOR Flash memory ( MX25U25645G, U21) is connected to S32R294 via the QSPI interface. Since there is no internal Flash inside of the MCU, code can be stored in the external flash, then loaded into SRAM in MCU after power-on over QSPI interface.
- Page 15 Figure 12. QSPI Flash circuit 3.13 EEPROM An external 64Kb EEPROM (AT24C64D, U6) is connected to S32R294 via I2C interface. The I2C read address is 0xA0 and write address is 0xA1. By default the I2C interface is not enabled, which can be enabled by jumpers J67 & J68.
-
Page 16: Boot Configuration
S32R294 EVB User Guide 3.14 BOOT Configuration The S32R294 device can support booting from different sources by applying a logic 1 or 0 to the BOOTMODE pins of the device, which in turn latches the input level on the RCON GPIO pins of the device at reset release. -
Page 17: Test Points
S32R294 EVB User Guide 3.15 Test Points EVB test points are listed and detailed in Table 8. Table 8. Test points Signal TP name Shape Description P12V Surface Pad 12V supply Do Not Use/ For auto part, ECS pin DNU/ECS Surface Pad from Flash. -
Page 18: Default Jumper Summary Table
S32R294 EVB User Guide Default Jumper Summary Table On delivery the EVB comes with a default jumper configuration. Table 9 lists and describes briefly the jumpers and indicates which jumpers are on/off on delivery of the board. Table 9. Default Jumper Table... -
Page 19: Known Issues
S32R294 EVB User Guide Jumper Default Pos PCB Legend Description CAN1 PA14 to PHY U10 TXD CAN1 PB1 to PHY U10 RXD CAN2 PF14 to PHY U20 TXD CAN2 PF15 to PHY U20 RXD CTE_RFS signal select CTE_RCS signal select... - Page 20 S32R294 EVB User Guide Change J56 to 3-pin jumper; Swap connection between MCU_CLK_P/N and TP10/11...
- Page 21 S32R294 EVB User Guide How to Reach Us: Home Page: www.nxp.com E-mail: support@nxp.com USA/Europe or Locations Not Listed: NXP Semiconductor Technical Information Center, CH370 1300 N. Alma School Road Chandler, Arizona 85224 +1-800-521-6274 or +1-480-768-2130 support@nxp.com Europe, Middle East, and Africa:...
