- Page 1 Quick Start Guide S08QL8-LITE...
- Page 2 Quick Start Guide GET TO KNOW THE S08QL8-LITE BOARD USB Port Reset Key OSBDM Debug Header PTA5 PTA0 PTA4 PTA1 VDD_MCU PTA2 S08QL MCU PTA3 PTB0 PTB7 PTB1 PTB6 PTB2 PTB5 PTB3 PTB4 PTC0 PTC3 Debug PTC1 PTC2 Header Buzzer...
- Page 3 Micro USB “J10.” A power LED will illuminate. The S08QL8-LITE comes preprogrammed with a demo which shows all the peripheral functions on board, including the potentiometer, thermistor, and buzzer. Download the sample code and Codewarrior IDE from nxp.com/S08QL8-Lite. Open the...
- Page 4 Quick Start Guide STEP-BY-STEP INSTRUCTIONS Debugger Support: ✓ Support download and debug through on-board OSBDM debugger ✓ Support download and debug through a Multilink debugger ✓ If there’s low power mode in the code, using Multilink can directly debug; Using on- board debugger need re-work the board, refer to next page for re-work instructions...
- Page 5 Quick Start Guide S08QL8-LITE OSBDM REWORK INSTRUCTIONS OSBDM need re-work to debug low power mode Steps: 1. Update OSBDM firmware using Multilink debugger (refer to next page) 2. Cut the connection between pin-23 of JM60 and POWER_EN signal 3. Connect JM60 pin-24 to POWER_EN signal...
- Page 6 3. Open the P&E Firmware Recovery Utility (windows start -> PEMicro -> P&E Firmware Recovery Utility) 5. Select firmware. The firmware stored under directory S08QL8-LITE FAT\OSBDM 6. Click “Update Firmware” 7. Wait for programming done, then unplug the USB cable,...
- Page 7 Quick Start Guide Get Started Download installation software and documentation at nxp.com/S08QL nxp.com/S08QL8-Lite...
