Short: Start / Stop
Long: Set marker
Arrow LED indicates proximity of rebar*
Measurement Center when Standard,
Large or Auto range is set (MC SLA)
*When an Arrow LED lights up move the
probe along the rebar axis until MC LED
14 15
or lights up. Then the MC is
precisely above a rebar axis.
© 2014 Proceq SA
12
17
14
16
Center Line (CL)
Measurement Center when
15
Spot range is set (MC Sp)
Short: Measure diameter
13
Long: Zeroing
17
Arrow LED indicates proximity of rebar*
12 13
By pushing and simultane-
ously the cursor jumps to the next line
(in Multi-Line, Area-Scan and Cross-Line
Mode only)
