(2) UPS meters
The following information will be display in LCD panel: Input voltage,
input frequency, output voltage, output frequency, battery voltage, and
load meters. Quick press the button to switch display categories, items
within the same category will be switched automatically.
Category
Output
Load
Battery
Input
Bypass
(3) Battery information: display battery capacity level in present(%).
●When battery voltage is low, LOW icon will display as below:
●When battery fault, FAULT icon will display as below:
If charger is normal working, CHARGING icon will light up.
(4) Buzzer:
when buzzer beeps and
alarm. Press
(5) Fault/Alarm display:
Voltage
Active power(W)
Voltage
Voltage
Voltage
Grid Quantity
(from left to right)
1
2
3
4
5
6
icon display, it indicates UPS abnormal or fault
can end buzzer beeping(silence mode).
Items
Frequency
Apparent power(VA)
Capacity
3-Phase Frequency
Frequency
Capacity level
0%-15%
16%-35%
36%-55%
56%-75%
76%-95%
≥96%
- 24 -
-
Percent
Cells number
--
--
