Technical Data - Struers LaboForce-1 Instruction Manual

Subject
Motor output
Torque at disc
Amperage
The motor is equipped with a thermal
switch for protection against overload.
Rotational speed
Force per specimen
Safety Standard Please refer to the Declaration of Conformity
Noise Level 46 dB (A) at idle running, at a distance of 0.25m/10" from the machine
Power Supply LaboForce-1 is connected directly to LaboPol
Dimensions and Width
Weight
Depth
Height
Weight
14
LaboForce-1
Instruction Manual

5. Technical Data

Specifications
0.5 W
Continuous 0.5 Nm
16 mA/220-240 V
32 mA/100-120 V
8/9.5 rpm at 50/60 Hz
Min. approximately 2 N, max. approx. 20 N
190 mm/7.5" (including drip lubricator)
265 mm/10.5"
295 mm/11.6" (above grinding/polishing disc)
5.9 kg/13 lbs
