- Page 1 All manuals and user guides at all-guides.com BASIC PHONE Model 98380 OPERATING INSTRUCTIONS...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com This Interquartz telephone has been manufactured to very high standards and is very easy to use. Please read this manual carefully to find out how to use the features. Contents 1. Important Notes .................. -
Page 3: Important Notes
This apparatus is intended for use on 2 wire analogue PSTN and PABX circuits within the United Kingdom. Declaration of Conformity Interquartz (UK) Limited declares under its sole responsibility that this product Model: BASIC PHONE 98380 XWA Is in conformity with the following relevant harmonised standards Health &... -
Page 4: Ren Number
All manuals and user guides at all-guides.com REN number The Ren number of this telephone is 1. If you wish to connect any other equipment to the line, simply add the REN numbers of each piece together and ensure that the total does not exceed 4. -
Page 5: Installation
All manuals and user guides at all-guides.com 2. Installation This telephone is designed to plug straight into a modular style socket. If you do not have one of these sockets, they can be obtained from your Network Supplier. Connection Insert the line cord into the socket. Set the tone / pulse switch to the appropriate position. -
Page 6: Telephone Features
All manuals and user guides at all-guides.com 1. Release 2. Insert screw driver into slot phone number plate and then pry to release HANDSET RETAINER 4. HANDSET RETAINER 3. Insert the HANDSET RETAINER for wall mount HANDSET RETAINER for wall mount Figure 3 Handset Retainer for Wall Mounting 3. -
Page 7: Figure 4 Switch Location
All manuals and user guides at all-guides.com RINGER HI / LO / OFF SWITCH RINGER PITCH CONTROL TONE / PULSE SWITCH VOICE MESSAGING ( S1/ S2 / N ) SWITCH TIMED BREAK / EARTH RECALL SWITCH Figure 4 Switch Location Ringer Pitch Control Located on the base of the unit ( see Figure 4 ). -
Page 8: Operating Instructions
All manuals and user guides at all-guides.com 4. Operating Instructions To dial a number, lift the handset, wait for the tone and then key in the number required. Redial / Pause Function Depending on its use, this button either acts as a redial button or as a pause inserting button Redial 1. -
Page 9: Pabx And System Usage
All manuals and user guides at all-guides.com 5. PABX and System Usage This telephone can be used behind a PABX or on a network system that utilises the recall function. There are many such systems and whilst it is likely that no problems will be encountered, it cannot be guaranteed that the telephone will operate correctly under all circumstances and any cases of difficulty should be referred to your supplier. -
Page 10: Maintenance And Problem Solving
All manuals and user guides at all-guides.com Voice messaging When used behind a PABX, this telephone will respond to voice messaging systems on many PABX types, giving a visual signal of a message waiting. Your telephone manager will be aware of which system is relevant to your organisation and will adjust or advise you on the adjustment of your telephone accordingly. -
Page 11: Warranty And Service
April) 1995. Under the six year warranty, cover will apply until 10 April 2001. A warranty is designed to cover either manufacturing faults or component defects. It is not designed to cover fair wear and tear. The Interquartz warranty is no exception. - Page 12 This warranty is in addition to any statutory rights This telephone is approved to EEC directive 1999/5/EC Distributed in the United Kingdom by Interquartz (UK) Limited Manufactured by International Quartz Limited A Subsidiary of Chiaphua Industries Ltd. ©Copyright INTERNATIONAL QUARTZ LTD. 2000...
