- Page 1 Gemini Telephone Model 9330 OPERATING INSTRUCTIONS...
-
Page 2: Table Of Contents
This Interquartz telephone has been manufactured to very high standards and is very easy to use. Please read this manual carefully to find out how to use the features. 1. Important Notes ... 2 Intended use ... 2 Telephone facilities ... 2 REN number ... -
Page 3: Important Notes
Intended use This apparatus is intended for use on 2 wire analogue PSTN and PABX circuits within Europe. Interquartz (UK) Limited declares under its sole responsibility that this product Is in conformity with the following relevant harmonized standards Health & Safety Electromagnetic Compatibility EN55022 : 1998 &... -
Page 4: Ren Number
REN of 1 Emergency calls Calls can be made on this telephone to contact the emergency services. The European code for emergency services is 112, however, you can still use 999 in the UK. An access code may also be required, if the phone is connected to a PABX. -
Page 5: Installation
2. Installation This telephone is designed to plug straight into a modular style socket. If you do not have one of these sockets, they can be obtained from your Network Supplier. Connection Insert the line cord into the socket. Set the ringer volume control, as desired. - Page 6 To enable the handset to be supported in the cradle when the phone is mounted on the wall, follow the procedure shown in Figure 3 to reverse the HANDSET RETAINER. 1. Use your thumb to press the 2. Push the HANDSET RETAINER HANDSET RETAINER out of the slot 3.
-
Page 7: Telephone Features
3. Telephone Features Ringer Indicator Flashes when the telephone rings with an incoming call. Ringer Volume Switch Located on the base of the unit (see Figure 4). Move switch to select no sound (OFF), muted sound (LOW) or full sound (HIGH) for ringing on incoming call. -
Page 8: Mute Button
To answer in Headset mode, press the Headset button, the call will automatically be answered in Headset mode (Headset must be plugged into Headset Port). For servicing and replacement, you can purchase a suitable headset through an INTERQUARTZ approved distributor or call + 44 (0) 161 763 3122 or email sales@interquartz.co.uk. -
Page 9: Pause Function
To dial a number, lift the handset, wait for the tone and then key in the number required. If the number dialled is busy, obtain a new line - by replacing the telephone handset and then lifting it again. Press the button labelled REDIAL / PAUSE and... -
Page 10: Pabx & System Usage
5. PABX & System Usage This telephone can be used behind a PABX or on a network that utilises the recall function. There are many such systems and whilst it is likely that no problems will be encountered, it cannot be guaranteed that the telephone will operate correctly under all circumstances and any cases of difficulty should be referred to your supplier. -
Page 11: Voice Messaging
(Technical note : S1 and S2 are for reverse polarity messaging systems. With such a system in use, if the telephone does not respond in the S1 position, switch it to the S2 position and it should then respond. -
Page 12: Warranty And Service
2005. The six year warranty, cover will apply until 12 March 2011. A warranty is designed to cover either manufacturing faults or component defects. It is not designed to cover fair wear and tear. The Interquartz warranty is no exception. - Page 13 Make sure that you tell us what is wrong with the phone. DO NOT FORGET TO INCLUDE YOUR OWN NAME AND ADDRESS. We ask that you bear the cost of returning the telephone to us. We will return it to you, at our expense.
- Page 14 This telephone is approved to EEC directive 1999/5/EC Distributed in the United Kingdom by Interquartz (UK) Limited Manufactured by International Quartz Limited A Subsidiary of Chiaphua Industries Ltd. © Copyright INTERNATIONAL QUARTZ LTD. 2005 3C933001-HS12B...
