Tally Dascom 1140
5. Ensure to place the lever at
black marked form. The top edge of the form will then align with the printer's tear-off
blade. Press Next or Back until you see the black mark marginally exposed out of the
tear-off blade. Then press OK to allow the printer to scan the horizontal offset of the
black mark relative to the left edge of the page. (Meanwhile, the vertical position of the
black mark is measured and recorded.)
When the printer fails to scan the horizontal offset (see the below picture), it prompts
you to repeat the above procedures. If scanning is successful, it prompts:
Successfully setup black mark parameters.
Distance Offset From Black Mark To Print Position
6. The last prompt above invites you to set the next parameter --- vertical offset of the first
print line from the black mark. Like other setting dialogs, you have options:
1) to bypass this setting (by pressing Next or Back), (WARNING: Not to skip or change
the order in Black Mark Setting.)
2) to accept the Distance Offset (by pressing OK),
3) to leave the subsequent settings (by press Exit),
4) to terminate the session and save modified parameter(s) (by pressing Save and
Restart).
7. When you respond with "OK" to set the vertical offset, the printer prompts you to reload
a black marked fanfold form:
Press any key to eject the paper, and load paper with black mark in the Fanfold
Path.
The top edge of the form will then align with the printer's tear-off blade. Press Next or
Back to feed or reverse-feed the paper till the desired first print line position is reached.
(With the above measured vertical position, the printer will convert the next paper
feeding to the TOF relative to the black mark.) Press OK to confirm the vertical offset.
Then the print prompts the invitation for setting the tear-off position relative to the black
mark:
Successfully setup black mark parameters.
Distance Offset From Black Mark To Tear Position
Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es
position. Then press the Load/Eject key to load the
