  • Page 1 Instructions for use PHYSIO Evo/Evo F/One Always be on the safe side.
  • Page 2 Distributed by: Manufacturer: KaVo Dental GmbH Kaltenbach & Voigt GmbH Bismarckring 39 Bismarckring 39 D-88400 Biberach D-88400 Biberach Phone +49 (0) 7351 56-0 www.kavo.com Fax +49 (0) 7351 56-1488...

  • Page 3: Table Of Contents

    4 Installation..............................16 4.1 Packaging............................... 16 4.1.1 Transportation and storage....................... 16 4.1.2 Packed items..........................16 4.2 Assembly of operator stool PHYSIO Evo/Evo F/One................17 4.2.1 Mounting the castors......................... 17 4.2.2 Mounting the upholstery......................18 4.2.3 Mounting the backrest upholstery..................... 19 4.2.4...
  • Page 4 Instructions for use PHYSIO Evo/Evo F/One Table of contents 6.1 PHYSIO Evo............................30 6.1.1 Adjust the seat height........................ 30 6.1.2 Adjusting the seat........................30 6.1.3 Adjust the backrest angle......................31 6.2 PHYSIO Evo F............................32 6.2.1 Adjust the seat height........................ 32 6.2.2...

  • Page 5: User Instructions

    Instructions for use PHYSIO Evo/Evo F/One 1 User instructions | 1.1 User guide 1 User instructions 1.1 User guide Requirement Read these instructions before the initial startup to prevent misuse and damage. 1.2 Abbreviations Abbre‐ Explanation viation Instructions for use...

  • Page 6: Terms And Conditions Of Warranty

    Claims from this warranty can only be asserted when the transfer form (copy) belong‐ ing to the product has been sent to KaVo, and the original can be presented by the operator or user.

  • Page 7: Information On The Packaging: Storage And Transportation

    (in accordance with the General German Freight Forwarders´ Terms and Conditions, Art. 28) Outside Germany Note KaVo shall not be held liable for damage arising from transportation. The shipment must be checked on arrival. If the packaging is visibly damaged on delivery, please proceed as follows: 1.
  • Page 8 Instructions for use PHYSIO Evo/Evo F/One 1 User instructions | 1.7 Transportation and storage Protect from moisture! Permissible stacking load Temperature range Humidity Air pressure 8 / 38...

  • Page 9: Safety

    Damage from unsuitable accessories. The use of accessories, other components, and cables other than those specified (with the exception of components and cables sold by KaVo as spare parts for inter‐ nal components) can increase emissions or reduce the electromagnetic immunity of the product.
  • Page 10 Instructions for use PHYSIO Evo/Evo F/One 2 Safety | 2.2 Safety instructions CAUTION Damage due to working on the pressure vessel. Forceful opening of the pressure vessel or extensive heat exposure can lead to injury and damage. ▶ Only instructed specialists may work on or exchange parts in the vicinity of the seat height adjusting element.

  • Page 11: Description Of The Product

    3 Description of the Product 3.1 Purpose – Intended use The PHYSIO Evo/Evo F/One is an operator stool for dentists in a dental practice in accordance with DIN EN ISO 7493. All versions of the PHYSIO Evo/Evo F/One operator stool are tested and approved in accordance with the currently applicable guidelines.

  • Page 12: Operator Stool Physio Evo/Evo F/One

    3 Description of the Product | 3.2 Operator stool PHYSIO Evo/Evo F/One 3.2 Operator stool PHYSIO Evo/Evo F/One KaVo PHYSIO Evo/Evo F/One The operator stool PHYSIO Evo/Evo F/One is equipped with soft castors Mat. no. 1.010.3896 for hard flooring upon delivery. The running surface and housing of the castors are bi-chrome.

  • Page 13: Rating Plates And Instruction Labels

    Instructions for use PHYSIO Evo/Evo F/One 3 Description of the Product | 3.3 Rating plates and instruction labels 3.3 Rating plates and instruction labels The rating plates are located underneath the stool. KaVo PHYSIO Evo/Evo F/One rating plate ① KaVo Logo ②...

  • Page 14: Technical Specifications Physio Evo

    Instructions for use PHYSIO Evo/Evo F/One 3 Description of the Product | 3.4 Technical specifications PHYSIO Evo 3.4 Technical specifications PHYSIO Evo Lowest seat height, with load 465 mm Highest seat height, without load 660 mm Lowest seat height, loaded...

  • Page 15: Technical Specifications Physio One

    Instructions for use PHYSIO Evo/Evo F/One 3 Description of the Product | 3.6 Technical specifications PHYSIO One 3.6 Technical specifications PHYSIO One Lowest seat height, with load 465 mm Highest seat height, without load 660 mm Lowest seat height, loaded...

  • Page 16: Installation

    6. Air pressure 700 hPa to 1060 hPa 4.1.2 Packed items The operator stool PHYSIO Evo/Evo F/One is packed in a special carton. Besides the operator stool, the packaging contains further modules according to the order. The upholstery for the seat and backrest are packaged separately and must be moun‐...

  • Page 17: Assembly Of Operator Stool Physio Evo/Evo F/One

    4 Installation | 4.2 Assembly of operator stool PHYSIO Evo/Evo F/One 4.2 Assembly of operator stool PHYSIO Evo/Evo F/One Note The PHYSIO Evo/One operator stool is delivered in the lowest seat height and with the backrest folded forwards. Note Only specially trained personnel may work on or exchange parts of the seat adjust‐...

  • Page 18: Mounting The Upholstery

    Instructions for use PHYSIO Evo/Evo F/One 4 Installation | 4.2 Assembly of operator stool PHYSIO Evo/Evo F/One 4.2.2 Mounting the upholstery ▶ Engage the seat upholstery at the 4 ball pins. 18 / 38...

  • Page 19: Mounting The Backrest Upholstery

    Instructions for use PHYSIO Evo/Evo F/One 4 Installation | 4.2 Assembly of operator stool PHYSIO Evo/Evo F/One 4.2.3 Mounting the backrest upholstery ▶ Engage the backrest upholstery at the 4 ball pins. 19 / 38...

  • Page 20: Adjust The Gas Pressure Spring

    Note The pressure point of the gas pressure spring is set at the factory. If the seat height of the operator stool PHYSIO Evo/Evo F/One cannot be adjusted securely, the pressure point of the gas pressure spring must be adapted.

  • Page 21: Assembly Of Operator Stool Physio Evo F

    Instructions for use PHYSIO Evo/Evo F/One 4 Installation | 4.3 Assembly of operator stool PHYSIO Evo F 4.3 Assembly of operator stool PHYSIO Evo F Note The chair is equipped with soft castors for hard floors as a standard. Use the castors that are appropriate for the flooring.

  • Page 22: Mounting The Upholstery

    Instructions for use PHYSIO Evo/Evo F/One 4 Installation | 4.3 Assembly of operator stool PHYSIO Evo F 4.3.2 Mounting the upholstery ▶ Engage the seat upholstery at the 4 ball pins. 4.3.3 Mounting the backrest cushion ▶ Engage the backrest upholstery at the 4 ball pins.

  • Page 23: Adjust The Gas Pressure Spring Foot Control

    Instructions for use PHYSIO Evo/Evo F/One 4 Installation | 4.3 Assembly of operator stool PHYSIO Evo F 4.3.4 Adjust the gas pressure spring foot control ▶ Use an Allen key to adjust the pressure point as follows: Screw in the threaded pin, the gas pressure spring is unlocked earlier.

  • Page 24: Dismantling

    Instructions for use PHYSIO Evo/Evo F/One 5 Dismantling | 5.1 Dismantling the operator stool PHYSIO Evo/Evo F/One 5 Dismantling Note Only specially trained personnel may work on or exchange parts of the seat adjust‐ ment element. 5.1 Dismantling the operator stool PHYSIO Evo/Evo F/One ▶...

  • Page 25: Dismantling The Gas Pressure Spring

    If the gas pressure spring is knocked out of the stool base too violently, this could lead to damage to the paintwork of the PHYSIO Evo/One operator stool. To prevent damage to the paintwork, you can place a piece of wood between the gas pressure spring and the hammer.
  • Page 26 Instructions for use PHYSIO Evo/Evo F/One 5 Dismantling | 5.3 Dismantling the gas pressure spring ▶ Hammer the gas pressure spring out of the stool base as far as the stool support. 26 / 38...

  • Page 27: Dismantling The Gas Pressure Spring Evo F

    Instructions for use PHYSIO Evo/Evo F/One 5 Dismantling | 5.3 Dismantling the gas pressure spring 5.3.2 Dismantling the gas pressure spring Evo F. ▶ Dismantle the intervention protection cover of the gas pressure spring on the top part of the chair.
  • Page 28 Instructions for use PHYSIO Evo/Evo F/One 5 Dismantling | 5.3 Dismantling the gas pressure spring ▶ Dismantle the actuator plate. ▶ Unscrew 3 countersunk screws. 28 / 38...
  • Page 29 Instructions for use PHYSIO Evo/Evo F/One 5 Dismantling | 5.3 Dismantling the gas pressure spring ▶ Dismantle the spring mechanism from the standpipe. ▶ Use the soft hammer and an appropriate pipe, e.g. larger-sized socket wrench, to drive the gas pressure spring out of the base.

  • Page 30: Operation

    Instructions for use PHYSIO Evo/Evo F/One 6 Operation | 6.1 PHYSIO Evo 6 Operation 6.1 PHYSIO Evo PHYSIO Evo ① Adjust the seat height ② Adjust the seat angle ③ Adjust the backrest angle 6.1.1 Adjust the seat height ▶ Activate the lever ① on the left forwards.

  • Page 31: Adjust The Backrest Angle

    Instructions for use PHYSIO Evo/Evo F/One 6 Operation | 6.1 PHYSIO Evo 6.1.3 Adjust the backrest angle Note There are two methods to adjust the backrest: - Freely selectable inclination with lock - Freely moveable backrest for active support of the back muscles ▶...

  • Page 32: Physio Evo F

    Instructions for use PHYSIO Evo/Evo F/One 6 Operation | 6.2 PHYSIO Evo F 6.2 PHYSIO Evo F PHYSIO Evo F ① Foot actuator plate for adjustment of ② Adjust the seat angle the seat height ③ Adjust the backrest angle 6.2.1 Adjust the seat height...

  • Page 33: Adjust The Backrest Angle

    Instructions for use PHYSIO Evo/Evo F/One 6 Operation | 6.2 PHYSIO Evo F 6.2.3 Adjust the backrest angle Note There are two methods to adjust the backrest: - Freely selectable inclination with lock - Freely moveable backrest for active support of the back muscles ▶...

  • Page 34: Physio One

    Instructions for use PHYSIO Evo/Evo F/One 6 Operation | 6.3 PHYSIO One 6.3 PHYSIO One PHYSIO One ① Adjust the seat height ② Adjust the backrest / seat angle 6.3.1 Adjust the seat height ▶ Activate the lever ① on the left forwards.

  • Page 35: Reprocessing Methods According To Din En Iso 17664

    Instructions for use PHYSIO Evo/Evo F/One 7 Reprocessing methods according to DIN EN ISO 17664 | 7.1 General care instructions 7 Reprocessing methods according to DIN EN ISO 17664 7.1 General care instructions CAUTION Product damage due to improper disinfection.

  • Page 36: Troubleshooting

    Note The pressure point of the gas pressure spring is set at the factory. If the seat height of the operator stool PHYSIO Evo/Evo F/One cannot be adjusted securely, the pressure point of the gas pressure spring must be adapted.
