User Chases Mode; Operating Functions; Strobe; Blackout - SHOWTEC ColorCue 1 Manual

ColorCue 1
Preset chases color sequence
Button Chases
1 Program 1
2 Program 2
3 Program 3
4 Program 4
5 Program 5
6 Program 6
7 Program 7
8 Program 8
9 Program 9
10 Program 10
11 Program 11
12 Program 12

3.2. User Chases Mode

In this mode you can play a chase which you have previously recorded. Please refer to Record a Chase
Step on page 12 for more information.
01) Press the USER CHASES button (16) to enter User Chases Mode. The LED on the button will light up.
02) Press one of the CHASES buttons (01) – (12) to select the desired user chase. The LED on the button
will light up.
Note: If no user chase is assigned to a button, the LED will not light up when you press the button.
03) Press the PLAYBACK button (18) repeatedly until the LED on the button lights up in the color
corresponding to the desired playback option. There are three playback options. See Chase
Playback on page 11 for more information.

Operating functions

Strobe

The strobe function can be activated in any of the 3 operating modes: Manual Mode, Static Colors
Mode and Chases Mode.
When in the respective operating mode, turn the STROBE control (H) to add strobe effect. The adjustment
range is from OFF to FULL, from low to high frequency.
Note: The strobe effect cannot be recorded in a color or a chase.

Blackout

The blackout function can be activated in any of the 3 operating modes: Manual Mode, Static Colors
Mode and Chases Mode.
When in the respective operating mode, press the BLACKOUT button (17) to black out the light output of
the connected fixture.

Chase Playback

There are 3 playback options. Press the PLAYBACK button (18) repeatedly until the LED on the button
lights up in the color corresponding to the playback option.
● Auto playback: The LED on the button will light up in red. Turn the SPEED control (E) to increase or
decrease the speed. The chase will play automatically.
Note: If the SPEED control (E) is in OFF position, the chase will not play.
● Manual playback: The LED on the button will light up in green. Press the STEP+ (19) or the STEP- (20)
buttons to manually choose a step from the chase step sequence.
Order code: 50703
Color 1 Color 2
RED GREEN
RED BLUE
GREEN BLUE
RED WHITE
GREEN WHITE
BLUE WHITE
WHITE AMBER
PINK YELLOW
PINK CYAN
YELLOW MAGENTA
RED GREEN
RED GREEN
10
Color 3 Color 4
BLUE
BLUE CYAN MAGENTA
Color 5 Color 6
YELLOW
