- Page 1 MANUAL ENGLISH Lite-4 Ordercode: 50328 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Lite-4 Table of contents Warning ....................................2 Unpacking Instructions ..............................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Connection with the mains............................4 Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 Overview ..................................5 Backside .................................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Lite-4 ● DC power adapter (1,5 m) ●... -
Page 4: Operating Determinations
For adult use only. Device must be installed out of the reach of children. Never leave the unit running unattended. ● The user is responsible for correct positioning and operating of the Lite-4. The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of this device. ●... -
Page 5: Connection With The Mains
Lite-4 Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER PHASE BLUE BLACK... -
Page 6: Description Of The Device
Lite-4 Description of the device Features The Showtec Lite-4 is a programmmable light controller equipped with a 4-channel chaser, 42 chase programs, memory backup and fade time control. ● Power input: DC 15-20V, 400mA ● Audio input: 100mV-1Vp-p ● DMX output: 3-pin DMX signal connector OUT ●... -
Page 7: Backside
22) 15-20V DC power connector IN Installation Remove all packing materials from the Lite-4. Check if all foam and plastic padding is removed. Screw the equipment into a 19” rack. Connect all cables. Do not supply power before the whole system is set up and connected properly. -
Page 8: Control Modes
Lite-4 Control Modes There are 7 modes: 1. Hold Dimmer 2. Hold Sound 3. Prog Sound 4. Prog Speed 5. Auto Speed 6. Auto Sound 7. Memory Press the MODE SELECT button (10) to choose the desired operating mode. Every time you press the MODE SELECT button, the corresponding LED indicators (05) will light up to show the currently selected operating mode. -
Page 9: Pr Mode (Program)
02) Wait 5 seconds, press and hold down the PROG SELECT button (11) and flick the power switch (02) to turn the Lite-4 on. The display will now show “I” (built-in microphone) or “E” (audio line input). 03) While still holding down the PROG SELECT button (11), press the MODE SELECT button (10). The audio signal source will change accordingly. -
Page 10: Maintenance
05) If all appears to be O.K., plug the unit in again. 06) If nothing happens after 30 seconds, unplug the device. 07) If you are unable to determine the cause of the problem, do not open the Lite-4, as this may damage the unit and the warranty will become void. - Page 11 Lite-4 Problem Probable cause(s) Remedy ● Check if power is switched on and One or more No power to the fixture cables are plugged in fixtures do not function at all Primary fuse blown ● Replace fuse Fixtures reset The controller is not connected ●...
-
Page 12: Product Specifications
Lite-4 Product Specifications Model: Lite-4 Power input: DC 15-20V, 400mA Dimensions: 483 x 133 x 40 mm (LxWxH) 19” x 3 HE Weight: 2,1 kg Operation and Programming Signal pin OUT: pin 1 earth, pin 2 (-), pin 3 (+) -
Page 13: Notes
Lite-4 Notes Ordercode: 50328... - Page 14 Lite-4 Ordercode: 50328...
- Page 15 Lite-4 Ordercode: 50328...
- Page 16 ©2018 Showtec...
