Summary of Contents for Optical Systems Design OSD2888

  • Page 1: Index

    Quick Start Guide OSD2888 MANAGED 12 x 10/100/1000BASE-T & 4 x 10G SFP ETHERNET SWITCH...
  • Page 3: Table Of Contents

    ESCRIPTION NS .......................... 4 PPLICATIO FEATURES AND BENEFITS ....................4 TECHNICAL SPECIFICATIONS ................... 5 INSTALLATION........................6 OSD2888 FRONT AND REAR PANELS................. 7 FRONT PANEL ........................7 REAR P ..........................7 ANEL POWER SUPPLY CONNECTIONS ..................7 LED INDICATORS ........................8 FITTING SFP CONNECTORS ....................
  • Page 4: Introduction

    Guide is designed to guide you through the installation and basic software functions. 2 TECHNICAL SUMMARY BRIEF DESCRIPTION The OSD2888 is a managed 12 port 10/100/1000BASE-T and 4 port 10G SFP Ethernet Switch. Please see OSD2888 datasheets for options available. APPLICATIONS ▲...
  • Page 5: Technical Specifications

    One IEC power inlet module for the standard AC powered version Two IEC power inlet modules for the optional redundant AC powered version Dimensions of Enclosure (mm) 443W x 300D x 44H Weight (kg) 102288802 DOC ID: 10118501 PAGE 5 OSD2888 QUICK START GUIDE...
  • Page 6: Installation

    OPTICAL OUTPUT OPERATION WARNING: Laser Safety: Class 1 Laser Product (SFP) per IEC 60825-1:2014 standard. Class 1 The OSD2888 is a Class 1 laser product when SFP are fitted PRECAUTIONS ▲...
  • Page 7: Osd2888 Front And Rear Panels

    13. PSU 1 Power Supply Input/Fuse/Switch 5 Power Supply Connections Connect the IEC Power connectors to PSU 1 located on the rear of the unit. The OSD2888 requires external 90 to 264V @ 40VA Max power. FIGURE 3: POWER CONNECTION...
  • Page 8: Led Indicators

    Off – No Connection • Fiber Port Status Duplex Mode: Green – Full Duplex • Off – No Connection • Status Mode: Green – Connection established • Off – No Connection • DOC ID: 10118501 PAGE 8 OSD2888 QUICK START GUIDE...
  • Page 9: Fitting Sfp Connectors

    Removing SFP – Remove fiber connector. Pull the SFP lever down to unlock SFP from housing. Using the lever, gently pull the SFP out. Fiber SFP Inserting Removing FIGURE 4: FITTING/REMOVING SFP CONNECTORS DOC ID: 10118501 PAGE 9 OSD2888 QUICK START GUIDE...
  • Page 10: Cli Overview

    OPTICAL SYSTEMS DESIGN 8 CLI OVERVIEW CONNECT TO CLI The Silicon Laboratories CP210x VCP Drivers is required to be installed on the PC before connecting the switch. DOC ID: 10118501 PAGE 10 OSD2888 QUICK START GUIDE...
  • Page 11: Cli Command For Ip Configuration

    The Command Line Interface (CLI) is a useful tool for checking link status and debugging link connections. To enable the use of CLI the OSD2888 must be connected to a PC with a USB port using a Mini-USB cable. Using a terminal emulation program such as Hyperterminal, a number of command...
  • Page 12 The configuration will be saved into Flash so that the desired configuration setup will be in effect at the next startup. PS: All configuration changes must be saved otherwise all the changes will be lost after rebooting! DOC ID: 10118501 PAGE 12 OSD2888 QUICK START GUIDE...
  • Page 13: Gui Overview

    This Quick Start Guide will only show a few main or important features to get the user running the OSD2888 successfully. On the top right hand of the GUI screen there are a few icons available to quickly navigate or obtain help for each GUI menu items.
  • Page 14: Ip Configuration

    If multiple IP addresses are required, click Add Interface to add more IP interfaces. Click Save to save the configuration. Use new IP address to access the switch. PS: All configuration changes must be saved otherwise all the changes will be lost after rebooting! DOC ID: 10118501 PAGE 14 OSD2888 QUICK START GUIDE...
  • Page 15: Users Authentication

    Click admin to change the current admin account setting. If multiple users are required, click Add New User PS: All configuration changes must be saved otherwise all the changes will be lost after rebooting! DOC ID: 10118501 PAGE 15 OSD2888 QUICK START GUIDE...
  • Page 16: Save Configuration To Start-Up

    Save startup-config Click Save Configuration to save the configuration on start-up. PORT SPEED SETTING The port speed settings for the OSD2888 is auto mode for copper port and 10G for SFP port. On the tree map below expand Configuration Ports.
  • Page 17: Warranty

    For warranty period, please call your local OSD distributor. REPAIRS Optical Systems Design reserves the right to repair or replace faulty modules/units. Please obtain a “Return Material Authorisation” (RMA) form and number before returning goods. Goods must be returned in adequate packing material to Optical Systems Design, Warriewood or its nominated authorised representative, for all repairs.
  • Page 18 OPTICAL SYSTEMS DESIGN DOC ID: 10118501 PAGE 18 OSD2888 QUICK START GUIDE...
  • Page 19 OPTICAL SYSTEMS DESIGN DOC ID: 10118501 PAGE 19 OSD2888 QUICK START GUIDE...
  • Page 20 OPTIC L Optical Systems Design Pty. Ltd. 7/1 Vuko Pl. Warriewood 2102 SYSTEMS P.O. Box 891 Mona Vale N.S.W. Australia 2103 Telephone: +61 2 9913 8540 Facsimile: +61 2 9913 8735 DESIGN Email: sales@osd.com.au Web Site: www.osd.com.au PTY LTD A.B.N. 83 003 020 504...
