    Quick Start Guide OSD2258P 10-PORT REDUNDANT RING GIGABIT ETHERNET SWITCH...
  • Page 3: Table Of Contents

    OPTICAL SYSTEMS DESIGN INDEX 1 INTRODUCTION ........................4 INSTALLATION........................4 LOCATION ..........................4 OSD2258P FRONT AND REAR PANELS ................5 FRONT PANEL ........................5 TOP P ..........................6 ANEL BOTTOM PANEL ........................6 POWER SUPPLY CONNECTIONS ..................7 ALARM CONNECTIONS ......................7 SWITCH CONFIGURATION ....................
  • Page 4: Introduction

    Protective eyewear should be worn in the vicinity of laser equipment. LOCATION As with any electric device, the OSD2258P should be placed where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference. Specifically, the site selected should meet the following requirements: •...
  • Page 5: Osd2258P Front And Rear Panels

    OPTICAL SYSTEMS DESIGN 3 OSD2258P FRONT AND REAR PANELS FRONT PANEL Power Ring LED Activity LED (x 8) Ports 1-4 RJ45 Copper Link LED Ports (x 10) PoE LED (x 8) Ports 5-8 RJ45 Copper Ports Ports 9-10 SFP Fiber...
  • Page 6: Top Panel

    Dual 1 LED 2 LED Output Redundant (1&2) Power Input FIGURE 2: TOP PANEL BOTTOM PANEL 8-Way Mini USB CLI USB Configuration Programming Console Switches Port Port FIGURE 3: BOTTOM PANEL DOC ID: 10118401 PAGE 6 OSD2258P QUICK START GUIDE...
  • Page 7: Power Supply Connections

    @ up to 500VA 5 Alarm Connections The OSD2258P has two monitoring alarm outputs: 1) Ring/Bus Alarm and 2) Temperature Alarm. The alarm connections and conditions for alarm outputs are as set out in Table 2. There are four pins on the 3.5mm terminal block used alarm output.
  • Page 8: Switch Configuration

    6 Switch Configuration The OSD2258P has an 8-way DIP switch located on the bottom of the unit to control a number of functions. Table 3 outlines the function of each switch. Default position of switch 1-8 is as shown on Figure 5 and Table 3.
  • Page 9: Led Indicators

    Removing SFP – Remove fiber connector. Pull the SFP lever down to unlock SFP from housing. Using the lever, gently pull the SFP out. Fiber SFP Inserting Removing FIGURE 6: FITTING/REMOVING SFP CONNECTORS DOC ID: 10118401 PAGE 9 OSD2258P QUICK START GUIDE...
  • Page 10: Cli Overview

    OPTICAL SYSTEMS DESIGN 9 CLI OVERVIEW CONNECT TO CLI The Silicon Laboratories CP210x VCP Drivers is needed to be installed on the PC before connecting the switch. DOC ID: 10118401 PAGE 10 OSD2258P QUICK START GUIDE...
  • Page 11 Baud Rate: 57600 • Data Bits: 8 • Parity: None • Stop Bits: 1 Flow Control: None • 3. Check the link by pressing <ENTER>. The line should jump to the next line. DOC ID: 10118401 PAGE 11 OSD2258P QUICK START GUIDE...
  • Page 12: Cli Command Sfor Ip Configuration

    OPTICAL SYSTEMS DESIGN CLI COMMANDS FOR IP CONFIGURATION Typing ? at the prompt will display all user CLI commands together with the input format DOC ID: 10118401 PAGE 12 OSD2258P QUICK START GUIDE...
  • Page 13: Gui Overview

    Using a web browser, enter the URL default 192.168.0.99 in the address bar • The GUI should now have access to the OSD2258P through the web browser • Configuration settings, Monitoring and Maintenance can all be accessed vis the drop down •...
  • Page 14: Ip Configuration

    CLI (see section 9) should be used. Note: All previous settings will be erased! default_setting Function: Reset configuration to default. Format: {ds} DOC ID: 10118401 PAGE 14 OSD2258P QUICK START GUIDE...
  • Page 15: Warranty

    For warranty period, please call your local OSD distributor. 12.2 REPAIRS Optical Systems Design reserves the right to repair or replace faulty modules/units. Please obtain a “Return Material Authorisation” (RMA) form and number before returning goods. Goods must be returned in adequate packing material to Optical Systems Design, Warriewood or its nominated authorised representative, for all repairs.
  • Page 16 Optical Systems Design Pty. Ltd. OPTIC L 7/1 Vuko Pl. Warriewood 2102 P.O. Box 891 Mona Vale N.S.W. Australia 2103 SYSTEMS Telephone: +61 2 9913 8540 Facsimile: +61 2 9913 8735 Email: sales@osd.com.au DESIGN Web Site: www.osd.com.au PTY LTD A.B.N. 83 003 020 504...
