CHIEF FPD-110 Installation Instructions Manual

Small flat panel dual swing arm pole mount
Hide thumbs Also See for FPD-110:

Advertisement

I N S T A L L A T I O N
Small Flat Panel
Dual Swing Arm Pole Mount (FPD-110)
The FPD is a sleek design providing a broad range of viewing
for Small Flat Panel Displays.
At only 2.18" deep in the closed position, the mount allows
side-to-side pivot adjustment up to 180 degrees in the closed
and the fully extended position. Displays up to 30" (max. 40
pounds) can be extended to 15.3" and can pivot 360 degrees.
The FPD accommodates all VESA® 75mm/100mm compliant
displays.
BEFORE YOU BEGIN
• Caution: To prevent damage to the FPD, which could affect or void the Factory warranty, and to the equip-
ment that will be attached to it, thoroughly study all instructions and illustrations before you begin the
installation. Pay particular attention to the "Important Warnings and Precautions" on Page 1.
• The maximum weight to be installed on the FPD is 40 pounds (18.1 Kg)
• The FPD is designed to be installed using a pole. The pole to which the FPD is anchored must be capable of sup-
porting five times the total weight of the mount and all attached equipment.
• If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480.
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY, STE. 700
SAVAGE, MINNESOTA 55378 USAA
I N S T R U C T I O N S
PART NO. 8832-000029 (Rev. B)
2004 Chief Manufacturing
www.chiefmfg.com
Printed in USA 03-05
