If you are missing any of the following components, please contact Customer Service at 1-800/582-6480
(1) FPM Wall Bracket
(2) Wood Screw
BEFORE PROCEEDING, READ INSTALLATION INSTRUCTIONS COMPLETELY
CAUTION!
Interface Bracket Installation:
1. See installation procedures accompanying your mounting bracket.
Optional Latching Flag Placement:
1. Remove Phillips head screw, Nylock nut and latching flag (see Figure 2).
2. Reposition latching flag and secure using Phillips head screw, Nylock nut.
Remove screw
and nut
8803-000034 Rev. B
CHIEF MANUFACTURING INC. 1-800-582-6480, Fax: 1-877-894-6918, Email: chief@chiefmfg.com
INSTALLATION INSTRUCTIONS
FPM SERIES
SMALL FLAT PANEL DISPLAY
PITCH-ADJUSTABLE WALL MOUNT
Exclusive Q2™ Mounting System
Prior to assembly, unpack carton completely and verify contents.
Flat Panel Displays are Extremely Fragile.
If Monitor Uses a Screw Size Other Than M4 X 10mm (M4 X 20mm),
DO NOT USE M4 Screws Provided. Monitor Damage Could Occur.
Move latch
Figure 1
(4) Drywall Anchor
(2) Washer, Flat, .25 ID X .56 OD
Figure 2
05/05
