- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Stackable Component Shelf Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCD100...
- Page 2 A WARNING alerts you to the possibility of installer’s responsibility to make sure the combined weight of serious injury or death if you do not follow the instructions. all components located on the FCD100 does not exceed 15 lbs (6.8 kg). LEGEND...
- Page 3 Installation Instructions FCD100 DIMENSIONS 13.28 18.00 2.63 11.38 5.65 11.50 DISTANCE BETWEEN USABLE SHELF DEPTH ABOVE SHELF 1.60...
- Page 4 FCD100 Installation Instructions TOOLS REQUIRED FOR INSTALLATION PARTS B (1) A (1) D (4) 10-24 x 1/2" C (4) 10-24 x 5/8"...
-
Page 5: Assembly And Installation
Attach FCD100 to the hanger bracket of shelf accessory using four 10-24 x 1/2" Phillips flat head screws (D). (See Figure 3) The FCD100 may be used along with a shelf accessory or a bracket accessory, such as a center speaker bracket. (See Figure 4) - Page 6 Figure 4 Attach shelf accessory or speaker bracket with FCD100 to Complete the installation following instructions included with upper hook bracket. (See Figure 5) the shelf accessory or speaker bracket to which the FCD100 is attached. Upper Hook Bracket Figure 5...
- Page 7 Installation Instructions FCD100...
- Page 8 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615 Chief Manufacturing, a products division Asia Pacific A Room 24F, Block D, Lily YinDu International Building of Milestone AV Technologies LuoGang, BuJi Town, Shenzhen, CHINA.
