MECHANICAL AND ELECTRICAL INFORMATION

MATRIX SERIES-MECHANICAL
Specification
Overall Bed Length (with boards and wallsaver)
Sleep Deck Width
Bed Width Including Boards
Maximum Height (floor to top of mattress support deck) 27"
Minimum Height (floor to top of mattress support deck) 8.95"
Maximum Head / Back Deck Angle
Maximum Knee / Foot Deck Angle
Maximum Trendelenburg / Reverse Trendelenburg Angle 12°
Maximum Safe Working Load WITH WEIGHT EVENLY
DISTRIBUTED - includes bedding, resident / patient,
support surface, and accessories
Bed Mass (without assist devices or boards)
MATRIX SERIES-ELECTRICAL (ALL MODELS)
Power / Frequency
Output Rating
Maximum Amperage
Classification
Power (Electrical) Cord
Mode of Operations
Battery Pack and Charger can be purchased separately as accessories.
TYPICAL MATRIX SERIES BED IDENTIFICATION LABELS
GF Health Products, Inc. - www.grahamfield.com
4100 (35")
76" 81.2"
80" 83.1"
35"
36"
68°
25°
450 lb
(204.1 kg)
150 lb
(68.0 kg)
120 Volt / 50/60 Hz
24Vdc
4.0 Amps
Class 1, Type B
#18 AWG 3 Conductor Type SJT
10% Max. Duty Cycle (2 minutes on / 18 minutes off)
with Grounded Electrical Cable
MATRIX SERIES
NOTE: All dimensions are ±0.25 inches
4100 (42")
81.2"
83.1"
42"
42"
27"
8.95"
68°
25°
12°
450 lb
(204.1 kg)
157 lb
(71.2 kg)
Bed labels are an important part of identifying the bed's
make and model when ordering replacement parts. The
Serial Number is essential if you are claiming parts or
service under warranty. These helpful labels can be
located on the main frame rails, immediately below the
sleep decks on either side of the bed.
Have this IMPORTANT information ready when calling
our Customer Service or Technical Support staff at
1.770.368.4700; it will allow us to better assist you and
quickly answer your questions and concerns.
WARNING: Do not modify this equipment without
!
authorization from GF Health Products, Inc.
NOTE: For Matrix Series Service Parts, Technical
Assistance, and Information, call our Customer
Service Department at 1.770.368.4700. For a
list of Matrix Series bed service parts, visit
www.grahamfield.com.
Matrix Series Instructions for Use 999.0908-190C
5100 (35") 6100 (35")
82.7" 81.2"
83.9" 83.1"
35" 35"
36" 36"
27" 27"
8.95" 8.95"
68° 68°
25° 25°
13° 12°
450 lb 450 lb
(204.1 kg) (204.1 kg)
157 lb 157 lb
(71.2 kg) (71.2 kg)
