End Seal Installation
1
• Score down and around outer
jacket 1 inch from the end.
• Remove the outer jacket.
• Do not cut or damage inner jacket.
2A
• Using wire cutters, cut away aluminum wrap close to
braid and outer jacket.
HWAT
2
• Remove exposed braid.
IceStop, XL-Trace, and RaySol
3
• Push end seal completely onto heating cable.
Note: The end seal can be
installed only once; it cannot be
removed from the heating cable.
Do not use until ready for final
installation.
nVent.com | 7
