  • Page 1 HAK-C-100 Connection Kit for Division 1 Hazardous Locations Installation Instructions...
  • Page 2: Tools Required

    DESCRIPTION The nVent RAYCHEM HAK-C-100 is a connection kit designed for use in Division 1 hazardous locations with the RAYCHEM industrial heating cables listed on page 2 of these instructions. The kit contains materials for sealing one heating cable entry when making a power, splice, tee, or end termination.
  • Page 3 • Thread nipple into sealing fitting until tight. Inserts • Mount box on bracket. • Measure flex tube and cut to length from gland to pipe. • Thread male half of union into box entry. • Assemble union halves together. nVent.com | 3...
  • Page 4 • Cut heating cable 15 in. (38 cm) from the indentation (bus wire connection). • Lightly score outer jacket as shown. • Bend heating cable to break jacket at score, then peel off jacket. Go to step 7. nVent.com | 4...
  • Page 5 • Remove any remaining core material. • Score between bus wires at inner jacket. For LBTV2-CT go to Step A on page 11. For all other heating cables go to step 10. • Bend and snap core. nVent.com | 5...
  • Page 6 Step 10. • If needed, retwist and straighten bus wires. • Note: Extra force may be required for • Insert bus wires into guide tubes as shown. larger cables. • Make sure all strands go into tubes. Tubes nVent.com | 6...
  • Page 7 (as braid may contact sealing fitting or junction box), see illustration in Post-Thermal-Insulation Heating Cable Test 2, Step 21, page 8. •  R ecordtheTestBinsulationresistancevaluesinthe “Heating Cable Test 1” section of the FM Required Division 1 Installation Record on page 14. nVent.com | 7...
  • Page 8 • Tighten compression gland screws, being • Center heating cable as shown. careful not to change position of heating cable in sealing fitting (see Step 18). • Install flex tubing onto compression gland. • Tighten tubing clamp. Center nVent.com | 8...
  • Page 9 (25 mm) sealer is fully installed over the end of the heating cable. IMPORTANT: Make sure the CS-100 core seal remains in position when pulling the heating cable braid wire out through the hub of the junction box. nVent.com | 9...
  • Page 10 • Discard small loose screw packaged with Green screw grounding bar. Use larger green screw and and washer washer supplied with HAK-JB3-100 junction box. • Connect braid to grounding bar. • Connect grounding bar to junction box. nVent.com | 10...
  • Page 11 (not supplied “floating” in the junction box). 18 in. by Raychem). (45 cm) • Inspect each core seal for proper placement. • Stow wires in box. • Install cover and gasket. • Tighten cover set screw. nVent.com | 11...
  • Page 12 • Slide on black heat-shrinkable tubes. and hold for 5 seconds to create a seal. • Use heat gun or minitorch with soft yellow flame to • Go to step 15 and continue with installation. gently heat tubes until they shrink. nVent.com | 12...
  • Page 13: Troubleshooting Guide

    RAYCHEM splice kit. have been permanently damaged by excessive current and may need to be replaced. Excessive moisture in Dry out and reseal connections and splices. Using a connection boxes or megohmmeter, test per installation instructions. splices. nVent.com | 13...
  • Page 14 2. Power the heating cable and allow it to stabilize for 10 minutes, then measure current and voltage at the junction box. 3. Calculate the power (watts/ft) of the heating cable by multiplying the current by the voltage and dividing by the actual circuit length. Current (A) x Voltage (Vac) Power (watts/ft) = Length (ft) nVent.com | 14...
  • Page 15: Installation Instructions

    FM REQUIRED DIVISION 1 INSTALLATION RECORD To complete the FM approval process, fill out this form and return it to the nVent Customer Service Center (fax number (650) 361-6711). Company Name Purchase Order No. Reference Drawing(s) Circuit ID No. Initials...
  • Page 16 North America Tel +1.800.545.6258 Fax +1.800.527.5703 thermal.info@nvent.com Europe, Middle East, Africa Tel +32.16.213.511 Fax +32.16.213.603 thermal.info@nvent.com Asia Pacific Tel +86.21.5426.2937 Fax +86.21.2412.1688 cn.thermal.info@nvent.com Latin America Tel +1.713.868.4800 Fax +1.713.868.2333 thermal.info@nvent.com nVent.com ©2018nVent.AllnVentmarksandlogosareownedorlicensedbynVentServicesGmbHoritsaffiliates.Allothertrademarks arethepropertyoftheirrespectiveowners.nVentreservestherighttochangespecificationswithoutnotice. Raychem-IM-H56573-HAKC100-EN-1805...
