General Information

The TSP01 is a device in the size of a USB thumb drive that can be plugged to any free USB
port for reading up to three different temperature values and relative humidity.
The combined humidity and temperature sensor is embedded into the USB stick, a second
NTC temperature sensor is included and can be connected to the housing. A third optional
temperature sensor can be plugged to the USB housing. External temperature sensors can be
Thorlabs TSP-TH or any other NTC type sensors. The software allows to enter individual NTC
parameters, such as R0 (reference resistance), T0 (reference temperature) and the B
coefficient.
The data can be displayed in the GUI or can be embedded into existing software, e.g. Thorlabs
Beam Profiler Software.
1.1

Safety

Attention
All statements regarding safety of operation and technical data in this instruction
manual will only apply when the unit is operated correctly as it was designed for.
All modules must only be operated with proper shielded connection cables.
Only with written consent from Thorlabs may changes to single components be carried
out or components not supplied by Thorlabs be used.
This precision device is only serviceable if properly packed into the complete original
packaging including the plastic foam sleeves. If necessary, ask for a replacement
package.
1.2

Ordering Codes and Accessories

TSP01 Temperature and Humidity USB Sensor Probe with external temperature sensor
TSP-TH External temperature probe for TSP01
1.3

Requirements

1.3.1 Hardware Requirements

CPU: 1 GHz or higher
RAM: 512 MB or more
Graphic card with at least 32 MB memory
Hard disc with at least 100 MB free storage space
Free USB2.0 port

1.3.2 Software Requirements

The TSP01 software is compatible with the following operating systems:
Windows ® XP (32-bit) SP3
Windows ® Vista (32-bit, 64-bit)
Windows ® 7 (32-bit, 64-bit)
For operation of the TSP01, also an NI-VISA (version 5.1 or higher) is required. This NI-VISA
engines comes with the Thorlabs TSP01 installation CD, but can be downloaded also from
National Instruments' website www.ni.com.
