General Information

The Thorlabs INT-MZI-xxx series MZI Clock Box is a subassembly to be used in swept
source OCT systems and other applications. It contains a fusion coupler network to
provide a Power Monitor signal as well as a k-Clock signal to monitor output power and
wavelength of a swept laser source. The used fusion couplers are optimized for flat
wavelength response and very low PDCR (polarization dependent coupling ratio change)
to make the Power Monitor signal nearly independent of input polarization changes.
The "Getting Started Quickly" section below gives an overview of how to set up the INT-
MZI-xxx series MZI Clock Box. Subsequent sections contain detailed information about
principle of operation, operating suggestions and technical specifications.

1.1 Safety

Attention
All statements regarding safety of operation and technical data in this instruction
manual will only apply when the unit is operated correctly as it was designed for.
Only with written consent from Thorlabs may changes to single components be
carried out or components not supplied by Thorlabs be used.
This precision device is only transportable if duly packed into the complete original
packaging. If necessary, ask for a replacement package.

1.2 Ordering Codes and Accessories

The following models of INT-MZI-xxx series are available:
INT-MZI-1300 MZI-Clock-Box, 1225-1375nm, FSR 103,3 GHz
INT-MZI-850
Different wavelength ranges can be ordered on request, as well as different Free Spectral
Ranges (FSR).
For the standard version, mounting holes are located on the small edges of the enclosure.
An alternative cover with four mounting holes as well as a customized cover can be
ordered on request.
Please refer to www.thorlabs.com
2

Getting Started

2.1 Parts List

Inspect the shipping container for damage. If the shipping container seems to be damaged,
keep it until you have inspected the contents and you have inspected the INT-MZI-xxx
mechanically and electrically.
Verify that you have received the following items within the package:
INT-MZI-xxx
-
LDS12B Power supply (12V, 250 mA), 100V, 120V, or 230V line voltage
-
Operation manual
-
© 2018 Thorlabs
MZI-Clock-Box, 780-900nm, FSR 103,3 GHz
for new models.
