Flow Curves (Air) - Emerson TESCOM WegaMed Compact Series Instructions For Use Manual

temperature
Storage:
GB
-40°C
Weight: 800 g (varies according to model)
Subject to design changes.
7.2

Flow curves (air)

6
5
4
3
Outlet pressure 3.5 bar
2
1
0
0
The curve shown relates to operation with an outlet connection. Running both outlet connec-
tions at the same time significantly reduces the outlet pressure at each outlet connection.
70°C
-20°C
Outlet pressure 4.5 bar
40 80 120
Operation:
60°C
160 200
Flow Q [l/min]
40
Inlet pressure 10 bar
Inlet pressure 200 bar
240 280 320 360
