TESCOM™
Safety, Installation, Operations & Service Manual
Installation Manual
This manual is available in multiple languages online at www.Emerson.com/Tescom
Do not attempt to select, install,
use or maintain this product until
you have read and fully understood
this manual.
Installation Manual
TR000238ENUS-01_12-20
December 2020
Advertisement
Table of Contents
Related Manuals for Emerson TESCOM
Summary of Contents for Emerson TESCOM
- Page 1 December 2020 TESCOM™ Safety, Installation, Operations & Service Manual Installation Manual This manual is available in multiple languages online at www.Emerson.com/Tescom Do not attempt to select, install, use or maintain this product until you have read and fully understood this manual.
- Page 2 Content Installation Manual December 2020 TR000238ENUS-01_12-20 TESCOM™ Safety, Installation, Operations & Service Manual...
- Page 3 3.4 Back Pressure Regulators - Piston-Sensed.................16 3.4.1 General........................16 3.4.2 Pressure Activation Methods...................17 3.4.3 Operation (Control Knob Adjustment)..............17 3.4.4 Maintenance......................17 3.4.5 Reassembly......................18 3.5 Valves - TESCOM Multi-Turn and Metering Valves.............19 3.5.1 General........................19 3.5.2 Actuation Types......................19 3.5.3 Operation (Control Knob Adjustment)..............19 3.5.4 Maintenance......................19 3.5.5 Reassembly......................20 3.6 Valves - TESCOM On-Off and Diverting Valves..............21...
-
Page 4: Regulators And Valves
Possible consequences include but are not limited to: • High velocity fluid (gas or liquid) discharge • Parts ejected at high speed • Contact with fluids that may be hot, cold, toxic or otherwise injurious • Explosion or burning of the fluid • Lines/hoses whipping dangerously • Damage or destruction to other components or equipment in the system TESCOM™ Safety, Installation, Operations & Service Manual... - Page 5 • Refer to product label (model specific) for maximum inlet pressures. If this rated pressure cannot be found, contact your local TESCOM representative for the rated pressure prior to installation and use. Verify the designed pressure rating of all equipment (e.g., supply lines, fittings, connections, filters, valves, gauges, etc.) in your system.
-
Page 6: Intended Use
Inspect the regulator, valve, and accessories for physical damage and contamination. Do not connect the regulator, valve, or accessory if you detect oil, grease, or damaged parts. If the regulator, valve, or accessory is damaged, contact your local TESCOM representative to have the regulator cleaned or repaired. -
Page 7: Repair Service
The user is responsible for assuring all safety and warning requirements of the application are met through his/her own analysis and testing. • TESCOM may suggest material for use with specific media upon request. TESCOM does NOT guarantee materials to be compatible with specific media -- This is the responsibility of the user! • Component function, adequate ratings, proper installation, operation, and maintenance are the responsibilities of the system user. - Page 8 Assembly/Installation Drawings & Bills Of Material drawings and parts lists for your product may be obtained by contacting TESCOM. Tescom will provide these by email, fax or mail. Your local Tescom representative can provide additional assistance. Be sure to have your complete model number ready.
-
Page 9: Maintenance
Final adjustments should be made in the direction of increasing pressure to obtain the most accurate set point. TESCOM regulators will operate with any liquid or gaseous media compatible with the wetted materials. Some series/modifications come with an internal filter designed to stop random contamination resulting from the installation of the regulator. - Page 10 Please reference the Bill of Material and Assembly Drawing for the correct location of replacement parts and correct torque specifications: 1. Inspect all parts and replace those worn or damaged with TESCOM replacement parts. 2. All parts should be cleaned to the cleanliness level required for safe operation with the media and system they will be used in. All parts in the flow stream must be free of...
- Page 11 3.2.2 Pressure Activation Methods TESCOM uses four basic types of activation methods. The activation method provides the means by which the operator can set the force that determines the outlet pressure of a regulator. Control Knob: Delivery pressure is increased by turning the control knob. The control knob applies a load through a spring to the piston.
- Page 12 Final adjustments should be made in the direction of increasing pressure to obtain the most accurate set point. TESCOM regulators will operate with any liquid or gaseous media compatible with the wetted materials. Some series/modifications come with an internal filter that only are designed to stop random contamination resulting from the installation of the regulator.
- Page 13 The last item to be placed in the body of most all of TESCOM regulators is the piston sensor. Place all O-rings and back-up rings that are external to the piston sensor in the body before placing the sensor in place.
- Page 14 500 psig. Pressure Activation Methods 3.3.2 TESCOM uses three basic types of activation methods. The activation method provides the means by which the operator can set the force that determines the back pressure of a regulator. Control Knob: Back pressure is increased by turning the control knob. The control knob applies a load through a spring to the diaphragm.
- Page 15 TESCOM regulators will operate with any liquid or gaseous media compatible with the wetted materials. Some series/modifications come with an internal filter designed to stop random contamination resulting from the installation of the regulator. An auxiliary upstream filter is recommended for use in all but the cleanest media. Gaseous media...
- Page 16 Please reference the Bill of Material and Assembly Drawing for the correct location of replacement parts and correct torque specifications. 1. Inspect all parts and replace those worn or damaged with TESCOM replacement parts. 2. All parts should be cleaned to the cleanliness level required for safe operation with the media and system they will be used in. All parts in the flow stream must be free of...
- Page 17 December 2020 3.4.2 Pressure Activation Methods TESCOM uses four basic types of activation methods. The activation method provides the means by which the operator can set the force that determines the outlet pressure of a regulator. Control Knob: Delivery pressure is increased by turning the control knob. The control knob applies a load through a spring to the piston.
- Page 18 The last item to be placed in the body of the majority of TESCOM regulators, is the piston sensor. Place all O-rings and back-up rings that are external to the piston sensor in the body before placing the sensor in place.
- Page 19 The valve is closed by turning the hand knob clockwise and opened by turning the hand knob counterclockwise. The hand knob rotation changes the position of the valve stem in relation to the seat. TESCOM valves will operate with any liquid or gaseous media compatible with the wetted materials. A filter is recommended for use in all but the cleanest media. Gaseous media should be free of excessive moisture to prevent icing of the valve at high flow rates.
- Page 20 Please reference Bill of Materials and Assembly Drawing for the correct location of the replacement parts and correct torque specifications. 1. Inspect all parts and replace those worn or damaged with TESCOM replacement parts. 2. All parts should be cleaned to the cleanliness level required for safe operation with the media and system the valve will be used in. All parts in the flow stream must be...
- Page 21 VL, VM, VT, and VU valves require a minimum pressure of 80 psi for actuation pressure. Please check your drawings for the maximum actuation pressure. TESCOM valves will operate with any liquid or gaseous media compatible with the wetted materials. A filter is recommended for use in all but the cleanest media. Gaseous media should be free of excessive moisture to prevent icing of the valve at high flow rates.
- Page 22 Please reference Bill of Materials and Assembly Drawings for the correct location of the replacement parts and correct torque specifications. 1. Inspect all parts and replace those worn or damaged with TESCOM replacement parts. 2. All parts should be cleaned to the cleanliness level required for safe operation with the media and system the valve will be used in. All parts in the flow stream must be...
-
Page 23: Limited Warranty
TR000238ENUS-01_12-20 December 2020 Limited Warranty TESCOM™ Corporation (“Seller”) warrants that the licensed firmware embodied in the goods will execute the programming instructions provided by Seller, and that the goods manufactured or services provided by Seller will be free from defects in materials or workmanship under normal use and care until the expiration of the applicable warranty period. - Page 24 LinkedIn.com/company/Emerson-Automation-Solutions Twitter.com/EMR_Automation The Emerson logo is a trademark and service mark of Emerson Electric Co. Brand logotype are registered trademarks of one of the Emerson family of companies. All other marks are the property of their respective owners. © 2020 Emerson Electric Co. All rights reserved.
