Rockwell Automation Allen-Bradley 2711-TBDC Installation Instructions

Removing and Installing the
Power Terminal Block
1
Power Terminal Block
(Catalog Number 2711-TBDC, 2711P-RVAC)
These document provides instructions on how to remove and install
the DC or AC Power Terminal Block in the following devices:
Cat. No. Power Type
2711-TBDC DC
2711P-RVAC AC
You can remove and re-install the power terminal block for ease of
installation, wiring and maintenance. A terminal block is pre-installed
on each device when shipped.
Explosion Hazard
WARNING
• Substitution of components may impair suitability
for hazardous locations.
!
• Do not disconnect equipment unless power has
been switched off and area is known to be
non-hazardous.
• Do not connect or disconnect components unless
power has been switched off.
• All wiring must comply with N.E.C. articles
501-4(b), 502-4(b), 503-3(b) as appropriate.
• Peripheral equipment must be suitable for the
location it is used in.
AC and DC terminal blocks are keyed and marked
ATTENTION
differently so be sure to follow the markings. Do not
force terminal blocks into connectors to prevent
!
potential damage to terminal.
The procedure for removing and installing the power terminal block is
similar for all terminals. Orientation of the power terminal block may
vary between the terminals.

Installation Instructions

Terminal Type
PanelView 300 Micro
PanelView 600 Touch only
PanelView Plus 400-600
PanelView Plus 400-600
Publication 2711-IN021B-EN-P
