• Side cabling: It is to lead out cable from housing of the camera.
Figure 2-6
Step 3
Align the screw hole on the pedestal with the mounting hole on the mounting
surface, and then twist the screws into the expansion bolts and lock them
firmly. Finally fix the enclosure on the pedestal and screw it firmly.
Note: Dome enclosure is related to waterproof function, make sure it is firmly
tightened after adjustment.
