Lytx SF Series Installation Instructions Manual

Event recorder
Hide thumbs Also See for SF Series:
Table of Contents

Advertisement

Quick Links

Lytx
Installation Instructions
(North America Edition)
Last updated: 4/1/2019
THE DEVICE SHOULD BE INSTALLED AND MAINTAINED BY QUALIFIED TECHNICIANS. Only a properly qualified technician
should install and maintain the SF-Series device. Any electrical work should be performed only by an ASE (minimum T6
& L2), MECP or equivalent certified technician with an expertise in installing and troubleshooting advanced vehicle
onboard components including multiplexed circuits. Lytx, Inc. disclaims all responsibility for any damages arising from
improper installation and maintenance of the SF-Series device.
This guide is protected as confidential and proprietary information of Lytx, Inc. Copying and use of this guide for any
purpose other than installing SF-Series in vehicles of Lytx, Inc.'s customers is expressly prohibited. Information
contained in this guide was in effect as of the date set forth above and is subject to change without notice or liability.
Lytx, Inc. reserves the right to revise the information presented or to discontinue the production of parts described at any
time.
©2019 Lytx, Inc. - Confidential & Proprietary.
®
SF-Series Event Recorder
Page 1 of 51
(North America Edition)
