Lytx ER-SF1 Event Recorder
Installation Instructions
J1939 Network
Last Updated: March 10, 2017
Only a properly qualified technician should install and maintain the ER-SF1. Any electrical work should be performed only by an ASE (minimum T6
& L2), MECP or equivalent certified technician with an expertise in installing and troubleshooting advanced vehicle onboard components including
multiplexed circuits. Lytx, Inc. disclaims all responsibility for any damages arising from improper installation and maintenance of the ER-SF1.
© 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti's Use Only Re Beta ER-SF1 Installations
This guide is protected as confidential and proprietary information of Lytx, Inc. Copying and use of this guide for any purpose other than
installing ER-SF1 in vehicles of Lytx, Inc.'s customers is expressly prohibited. Information contained in this guide was in effect as of the date set
forth above and is subject to change without notice or liability. Lytx, Inc. reserves the right to revise the information presented or to discontinue
the production of parts described at any time.

Advertisement

Table of Contents
loading

Related Manuals for Lytx ER-SF1

Summary of Contents for Lytx ER-SF1

  • Page 1 This guide is protected as confidential and proprietary information of Lytx, Inc. Copying and use of this guide for any purpose other than installing ER-SF1 in vehicles of Lytx, Inc.’s customers is expressly prohibited. Information contained in this guide was in effect as of the date set forth above and is subject to change without notice or liability.

  • Page 2: Table Of Contents

    Clean and Dry the Windshield......................13 Mark the Mounting Location on the Glass ..................14 Attach the Bracket to the Windshield ....................14 © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 1 of 26...
  • Page 3 Test Wire Connections and Settings in the Lytx Installation Tool ........... 23 Complete Installation ..........................23 Final Checks ............................24 Troubleshooting & Maintenance......................... 25 Contact Technical Support ........................25 © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 2 of 26...

  • Page 4: Safety Instructions

    Seat belt warning: To reduce the potential danger of injuries, the driver and front passenger must always be correctly seated with seat belts correctly fastened when operating the vehicle. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 3 of 26...

  • Page 5: Adherence To Applicable Local, State And Federal Laws

    Lytx, Inc. does not accept responsibility for your failure to do so. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 4 of 26...

  • Page 6: Usa Federal Communications Commission (Fcc) Notice

    RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s website: http://www.hc-sc.gc.ca/ewh- semt/pubs/radiation/radio_guidelignes_direct/index-eng.php © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 5 of 26...

  • Page 7: Australia & New Zealand - Wireless Notice

    Hierbij verklaart Lytx, Inc. dat het toestel DriveCamIII in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 6 of 26...
  • Page 8 Portuguese Lytx, Inc. declara que este ER-SF1 está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 7 of 26...

  • Page 9: Suppliers Declaration Of Conformance

    ASE (minimum T6 & L2), MECP or equivalent certified technician with an expertise in installing and troubleshooting advanced vehicle onboard components including multiplexed © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 8 of 26...

  • Page 10: Before You Begin

    Two T-27 security torx screws fuses  T-8 security torx screw J1939 CAN Coupler   Alcohol wipe  © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 9 of 26...

  • Page 11: Required Tools

    Standard Power Cable J1939 CAN Coupler If you are missing any materials, contact the Lytx U.S. Technical Support Center at 866.910.0403 or email support@lytx.com to obtain the necessary materials before beginning installation. Supplementing or substituting shipped materials could impair suitability and performance.

  • Page 12: Optional Tools

    3. Mark the mounting location on the windshield. 4. Attach the bracket to the windshield. 5. Mount the ER to the bracket. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 11 of 26...

  • Page 13: Mounting Location Guidelines

    © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 12 of 26...

  • Page 14: Clean And Dry The Windshield

    (see below). 2. Dry the mounting area thoroughly with a clean, dry cloth. Thoroughly Clean and Dry the Glass © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 13 of 26...

  • Page 15: Mark The Mounting Location On The Glass

    Apply additional pressure to the bracket. b. Use a small pin to create an escape path for the air. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 14 of 26...

  • Page 16: Mount The Event Recorder In The Bracket

    2. Adjust the event recorder so it hangs vertically (plumb). See Figure C. 3. Secure the event recorder in the bracket using the two Torx screws. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 15 of 26...

  • Page 17: Connect Electrical Wiring

    Consult the vehicle manufacturer for the location of any airbag sensors and systems and restrictions that may apply. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 16 of 26...

  • Page 18: Electrical Connection Overview Diagram

    ER-SF1 Event Recorder with J1939 Network Instructions for Self Installation Electrical Connection Overview Diagram © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 17 of 26...

  • Page 19: Wiring And Wire Termination Suggestions

    ECM, ECU, or control module circuit fuse. ScotchLoc connectors Quick Slide connectors Do not tap wire as shown © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 18 of 26...

  • Page 20: Basic Event Recorder Electrical Connections

    A wire that reads 12V on a voltmeter may not necessarily be able to supply enough current to the existing circuit and the event © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 19 of 26...

  • Page 21: Connect To The J1939 Bus Interface

    Coupler. This device makes use of inductive technology to allow the ER to read the data on the J1939 network without requiring any puncture, cut, or splice into the vehicle cabling. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 20 of 26...

  • Page 22: Route The Er Cable

    3. Route the ER cable across the top of the windshield under the window trim or headliner to the ER device (see below). © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 21 of 26...
  • Page 23 5. Make sure the cable is clear of any sharp edges, moving parts, and cannot get pinched in the door jam. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 22 of 26...

  • Page 24: Run Testing And Complete Installation

    Ignition and the vehicle J1939 connection (via engine RPM) can be verified via the Lytx Installation Tool. Complete Installation The ER-SF1 event recorder is installed and ready to use. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 23 of 26...

  • Page 25: Final Checks

    10. Place the decal indicating the vehicle is equipped with a recording device on the driver’s seat. The customer is responsible for visibly displaying this decal. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 24 of 26...

  • Page 26: Troubleshooting & Maintenance

    The device may be in an area without reception. Bypass this for now by checking the "Known Issue Bypass" box. Re-test this connection when the device is in a location with better reception. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 25 of 26...
  • Page 27 SIM card is not seated properly. Reseat and see if the light changes to Green. If the status light stays Yellow, contact Lytx Technical Support. © 2017 Lytx, Inc. – Confidential & Proprietary – For Velociti’s Use Only Re Beta ER-SF1 Installations. Page 26 of 26...
