- Page 1 Zeus sauna heater guard rail optional Installation and operating instruction MADE IN GERMANY IPx4 print no. 29344847 en / 34.17...
-
Page 2: Table Of Contents
English Table of Contents Intended use ............................3 General notes ............................3 Important notes ............................4 Scope of delivery ...........................7 Specifications ............................7 Wiring diagrams ............................8 Connection examples ...........................9 Installation and Safety gaps ......................10 Heater guard rail installation ......................11 Replacement of heating elements ....................12 Sauna stones ............................ -
Page 3: Intended Use
General information Dear customer You have purchased a high-quality technical Please check whether the unit has arrived in per- device with which you will have years of sauna fect condition. Any transport damages should be fun. This sauna heater was designed and inspect- immediately reported to the freight forwarder ed according to the current European safety delivering the goods or you should contact the... -
Page 4: Important Notes
Important notes Please provide air intake and vent open- • ings in each sauna cabin. The air intakes Unprofessional installation may • must always be positioned behind the cause a fire hazard! Please read these in- sauna heater, approx. 5 to 10 cm above stallation instructions carefully. - Page 5 stallation or set-up in a niche, under a sauna heater and the floor. On heaters bench or under a sloping roof. with bases, this clearance is maintained via the base or legs of the device. Do not put the sauna heater into operation •...
-
Page 6: Electrical Connection
Electrical connection place any herbs into the vaporizer holder for essences/herbs. Fire hazard! Using the above-mentioned wiring diagram and the information on the wiring circuit ad- hered to the respective control system, your Never add more essences or vol- • electrician will be able to connect the system atile oils than advised on the packaging. -
Page 7: Scope Of Delivery
Scope of delivery The standard scope of delivery includes: • Sauna heater • Connection cable (consists of two separate cable lines with special connectors) • Installation and operation manual • sauna stones (approx. 130-140 kg) Specifications external Connection: external Connection: Connection: Electric Connection:... -
Page 8: Wiring Diagrams
Wiring diagrams zum Steuergerät zum Steuergerät 5 x 1,5 5 x 1,5 zum LSG 09 R zum LSG 09 R 5 x 1,5 5 x 1,5 12 kW 16 kW zum Steuergerät zum Steuergerät 5 x 1,5 5 x 1,5 zum LSG 18 zum LSG 18 5 x 4... -
Page 9: Connection Examples
Connection example 12+16 kW Sensor reserviert Saunaheizgerät / Sauna heater Saunasteuergerät / Control unit / Sensorbus Leistungsschaltgerät LSG 09R Boîtier de commande / Saunabus light S1 S1 N L1 L2 L3 N W V U N MAINS OVEN L N L N U1 V1 W1 N1 PE U V W N PE V N S1... -
Page 10: Installation And Safety Gaps
Sauna heaters maybe operated via remote control* only in combination with an approved safety system like EOS switch-off guard rail. *Remote control – means settings, switching, control and adjustment of the sauna control unit by means... -
Page 11: Heater Guard Rail Installation
Heater guard rail installation (optional) The round-shaped guard rail is optionally available. Please bear in mind that you will also need the set of mounting brackets as well. Lift the ring-shaped top cover Disconnect the connectors for both power supply lines (open clip and pull off ). -
Page 12: Replacement Of Heating Elements
Replacement of heating elements 1. Remove stones from the rock store. View from top 2. Loosen 4 securing screws (1) in the base plate of the heating block. 3. Lift up and take off the decoration ring (2). 4. Disconnect the plugs of the power sup- ply cables on the bottom of the heater through the side opening. -
Page 13: Sauna Stones
Sauna rocks Maintenance and care Sauna stones are a natural product. Check the All sauna heating units are made of low-corro- sauna stones at regular intervals. Aggressive sion material. To enjoy your sauna heating unit sauna essences can weaken the sauna stones for a long time you should ensure maintenance and cause them to break apart over time. - Page 14 For the installation of sauna heaters, please checked. pay attention to the DIN VDE 0100 part 703 or Installation of the sauna heater and control unit the corresponding national norms and legal must be undertaken only by an authorized and requirements, e.g.
-
Page 15: Service Address
Service Address: EOS Saunatechnik GmbH Schneiderstriesch 1 35759 Driedorf, Germany Tel: +49 (0)2775 82-514 Fax: +49 (0)2775 82-431 servicecenter@eos-sauna.de www.eos-sauna.de Equipment commissioning date: Please keep this address in a safe place togeth- er with the installation guide. Stamp and signature of the authorized elec-... -
Page 16: General Terms And Conditions Of Service (Asb)
General Terms and Conditions of Service shipments via parcel post. The manufacturer shall accept no liability for damage incurred as a result of improper I. Scope packaging in an individual shipment. Unless otherwise agreed in writing in a specific case, VI.
