- Page 1 Quick Start Guide S12ZVM-EWP Reference Design Board A-sample PMSM Electrical Water Pump ECU hardware and software powered by the S12 MagniV S12ZVM ® microcontrollers...
- Page 2 Quick Start Guide GET TO KNOW THE S12ZVM-EWP BOARD VBAT PWM/LIN BDM and SCI N-MOSFET Debug Port BUK7Y7R6-40E Integrated MCU S12ZVML64 Dual Shunt 10mohm/2W N-MOSFET BUK7K6R2-40E PMSM/BLDC Connector Figure 1: Front side of S12ZVM-EWP...
- Page 3 Figure 2: Back side of S12ZVM-EWP...
- Page 4 Quick Start Guide S12ZVM-EWP FEATURES STEP-BY-STEP INSTRUCTIONS • PMSM sensorless FOC algorithm Firstly, install CodeWarrior Development supported Studio V11 or newer version for S12Z based MagniV device. • Software over-current, stall detection, under-voltage, over-voltage, over- Secondly, install FreeMASTER Run-time temperature protection debugging tool which is used to tune the motor.
-
Page 5: Power Supply
DC power supply. Set the voltage projects. Power up the board. Open at 12 V, current limit to 7.0 A. Check and the FreeMASTER in the S12ZVM-EWP make sure all connections are right. Software Quick Start Package; Configure... -
Page 6: Headers And Connectors List
Quick Start Guide HEADERS AND CONNECTORS LIST CONNECTOR DESCRIPTION For BDM, PIN1-BKGD, PIN2-GND, PIN4-RESET, PIN6- VDDX For FreeMASTER, PIN3-RX, PIN5-TX... - Page 7 www.nxp.com...
-
Page 8: Warranty
WARRANTY under “Jump Start Your Design” Visit www.nxp.com/warranty for at nxp.com/S12ZVM-EWP. complete warranty information. nxp.com/S12ZVM-EWP NXP and the NXP logo are trademarks of NXP B.V. All other product or service names are the property of their respective owners. © 2019 NXP B.V.
