Summary of Contents for NXP Semiconductors S12 MagniV

  • Page 1: Quick Start Guide

    Quick Start Guide S12 MagniV Mixed-signal MCUs S12ZVC Evaluation Board...
  • Page 2: Introduction And Default Settings

    Quick Start Introduction and default settings This guide shows how to quickly connect the board to a host PC and execute a demonstration application preloaded in to the flash memory. The S12ZVC MCU integrates: • S12Z CPU • Sensors • Power supply Temperature and humidity PNP external ballast transistor for Pressure sensor...
  • Page 3: Device Overview S12Zvc Family

    Device overview S12ZVC family The MC9S12ZVC family is a new member of the S12 MagniV product line integrating a battery level (12 V) voltage regulator, supply voltage monitoring, high voltage inputs, and a CAN physical interface. It’s primarily targeting at CAN nodes like sensors, switch panels, or small actuators.
  • Page 4: Jumper Default Configuration

    Quick Start Jumper default configuration This section describes about the jumper configuration. 12-bit CAN-PHY Temp Pierce Oscillator Analog-Digital Sense Converter MS-CAN Internal RC with Frequency Oscillator, 8-Bit Analog +/- 1.3% Modulationoption 2 x SCI Comparator Hi-Res-PWM 4ch 16-bit 2 SPI S12ZCPU 32 MHz Bus (25 MHZ @ >150°C Tj) Hi-Res-Timer 4ch 16-bit...
  • Page 5 nxp.com/S12MagniV PRIMARY SIDE Figure 2. Jumper configuration diagram...
  • Page 6 Quick Start Jumper default configuration The following table lists the jumper default configuration. Header Reference position Header Reference position 1, 2 1, 2 1, 2 1, 2 1-2, 3-4, 5-6, 7-8 1, 2 1- 2 1- 2 1-2, 3-4, 5-6, 7-8 1- 2 1- 2 1-2, 3-4, 5-6, 7-8, 9-10,...
  • Page 7 nxp.com/S12MagniV Software tools installation This section describes how to get started with the S12ZVC board by installing CodeWarrior development studio and testing the demo program that comes programmed with the board. Install CodeWarrior development studio NXP’s CodeWarrior for MCUs integrates the development tools for several architectures, including the S12Z architecture, into a single product based on the Eclipse open development platform.
  • Page 8 Quick Start Software tools installation (cont.) • Tilt the EVB to observe changes Launch the on the red and green LEDs. demo program • Rotate the potentiometer to The S12ZVC EVB board comes observe changes on the orange LED. preprogrammed with a small •...
  • Page 9: Jumper List And Description

    nxp.com/S12MagniV Jumper list and description Jumper Description HVI Circuit –Reference Voltage Selector Pin 1-2 SW1 is connected to VBAT level. This provides a HIGH voltage Closed level when switch SW1 is pressed. Pin 2-3 SW1 is connected to GND level. This provides a LOW voltage Closed level whenswitch SW1 is pressed.
  • Page 10 Quick Start Jumper list and description (cont.) Jumper Description VDDX External Ballast Transistor With this jumper closed, the VSUP Voltage is connected to PNP external transistor collector for the VDDX voltage regulation. VDDX External Ballast Transistor This jumper enables the signal control of the PNP external transistor collector for the VDDX voltage regulation.
  • Page 11 nxp.com/S12MagniV Jumper list and description (cont.) Jumper Description Power Supply Voltages – LEDs Indicators Pin 1-2 Enable VDDC - LED indicator Closed Pin 3-4 Enable VDDA - LED indicator Closed Pin 5-6 Enable VDDX - LED indicator Closed Pin 7-8 Enable VSUP - LED indicator Closed VDDX External Ballast Transistor - Output...
  • Page 12 Quick Start Jumper list and description (cont.) Jumper Description SENT Transmitter Interface Closing this header connects the SENT_TX line to SENT transmitter interface circuit. LIN Mode With this jumper, the user can configure the local and remote wake-up mode of MC33662 - LIN transceiver.
  • Page 13 nxp.com/S12MagniV Jumper list and description (cont.) Jumper Description VBAT Closing this jumper connects VBAT to all system. LIN and SENT Communication Pin 1-2 Closing this jumper connects PAD8 port to the potentiometer. Closed Pin 3-4 Closing this jumper connects PAD9 port to Press Sensor – Closed Output.
  • Page 14: Headers And Connectors List

    Quick Start Headers and connectors list The following table lists all of the connectors available in the S12ZVC evaluation board and their corresponding signals. Header / Connector Reference position Main power connector (up to 18 V) VBAT, VSUP, VDDX, VDDC, and VDDA are connected to this header. HVI Header –...
  • Page 15 nxp.com/S12MagniV Headers and connectors list (cont.) Header / Connector Reference position LIN Connector GPIO Header - Port AD GPIO Header - Port S CAN main connector CAN main connector OSBDM USB port for programming and debugging the main MCU. VDDX - PNP Ballast Transistor Terminals The header could be used for measurements/monitoring of all signals of the external PNP ballast transistor: Base, Collector, and Emitter.
  • Page 16: Peripheral List

    Quick Start Peripheral list The following table lists all the peripherals available in the S12ZVCevaluation board. Peripheral MCU PORT Description Potentiometer connected to Potentiometer PAD8 ADC channel 8 – VSUP LED indicator – VDDX LED indicator LED – Voltage Indicator –...
  • Page 17 nxp.com/S12MagniV Peripheral list (cont.) Peripheral MCU PORT Description Switch connected to PL1 (with 10 kΩ resistor) High Voltage Switch Switch connected to PL0 (with 10 kΩ resistor) Buzzer Buzzer controlled by PP7 Red LED connected to port PP6 Green LED connected to port PP5 LED –...
  • Page 18: Revision History

    References For further reference, the following documents are available at nxp.com • AN4851: Using the High Resolution Timer and PWM in the S12ZVC (AN4851) • AN4852: Using the SENT Transmitter Module in S12ZVC Devices (AN4852) Revision history Revision number Date Substantial changes 01/2014 Initial release...
  • Page 19 Information in this document is provided and all liability, including without limitation solely to enable system and software consequential or incidental damages. implementers to use NXP products. There “Typical” parameters that may be provided are no express or implied copyright licenses in NXP data sheets and/or specifications can granted hereunder to design or fabricate and do vary in different applications,...
  • Page 20: Get Started

    Get Started Download installation software and documentation under “Jump Start Your Design” at nxp.com/VLG-MC9S12ZVC. Support Visit nxp.com/support for a list of phone numbers within your region. Warranty Visit nxp.com/warranty for complete warranty information. For more information, visit nxp.com NXP, the NXP logo, and CodeWarrior are trademarks of NXP Semiconductor, Inc., Reg.
