To adjust the dash lamp brightness on a 2023 Jeep Compass, ensure that:

1. The parking lights or headlights are turned on.
2. The built-in light sensor detects low ambient light levels.

The instrument panel dimmer control will only work under these conditions. If the adjustment wheel is not working, check if the headlights or parking lights are on and if ambient light is low. If these conditions are met and it still does not work, the dimmer control may be faulty.

This answer is automatically generated

david lengyel

March 21, 2025

what is tonuge weight for 2023 jeep compass trailhawk

1 comments:

Mr. Anderson

March 21, 2025

The tongue weight for the 2023 Jeep Compass Trailhawk is 200 lb (90 kg).

This answer is automatically generated

Summary of Contents for Jeep Compass 2023

Page 1 2023 COM PASS | OW NER ’S M ANUAL...
Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this manual that are not on this vehicle.
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..........................7 GETTING TO KNOW YOUR VEHICLE ..................13 GETTING TO KNOW YOUR INSTRUMENT PANEL ............66 STARTING AND OPERATING ....................90 MULTIMEDIA ..........................144 SAFETY ............................165 IN CASE OF EMERGENCY ..................... 213 SERVICING AND MAINTENANCE ..................233 TECHNICAL SPECIFICATIONS .....................
Page 4 INTRODUCTION DOORS .................20 UCONNECT VOICE RECOGNITION QUICK Manual Door Locks............20 TIPS — IF EQUIPPED ............32 SYMBOLS KEY ............... 8 Power Door Locks............21 Introducing Voice Recognition........32 ROLLOVER WARNING ............8 Basic Voice Commands ..........32 Keyless Enter ‘n Go™ — Passive Entry .......21 VEHICLE MODIFICATIONS/ALTERATIONS ......
Page 5 GETTING TO KNOW YOUR EXTERIOR LIGHTS ..............38 INTERIOR STORAGE AND EQUIPMENT......52 Multifunction Lever ............ 38 Storage .................52 INSTRUMENT PANEL Headlight Switch ............38 USB Control..............52 Power Outlets — If Equipped........53 BASE / MIDLINE INSTRUMENT CLUSTER ....... 66 Daytime Running Lights (DRLs) — Base / Midline Instrument Cluster Descriptions..
Page 6 Towing Requirements ..........138 IF EQUIPPED ..............100 Enabling And Disabling ParkSense ......121 Towing Tips ...............140 Jeep® Active Drive............ 100 Service The ParkSense Park Assist System.... 121 RECREATIONAL TOWING (BEHIND MOTORHOME) ..141 SELEC-TERRAIN — IF EQUIPPED ........101 Cleaning The ParkSense System......121 Towing This Vehicle Behind Another Vehicle...141...
Page 7 MULTIMEDIA SAFETY TIPS ..............210 TOWING A DISABLED VEHICLE........230 Transporting Passengers ......... 210 Without The Key Fob ..........231 UCONNECT SYSTEMS ............. 144 Transporting Pets ............ 210 Front-Wheel Drive (FWD) Models — CYBERSECURITY ............. 144 Safety Checks You Should Make Inside With Key Fob..............231 UCONNECT SETTINGS .............
Page 8 CUSTOMER ASSISTANCE Exhaust System ............243 INTERIORS ............... 279 Cooling System............244 Seats And Fabric Parts..........279 SUGGESTIONS FOR OBTAINING SERVICE FOR Brake System ............246 Plastic And Coated Parts.......... 280 YOUR VEHICLE ..............286 Automatic Transmission ........... 247 Leather Surfaces ............280 Prepare For The Appointment ........286 Fuses .................
Page 9: Introduction
FCA US LLC reserves the right to make changes to the model described for technical and/or commercial reasons. For further information, contact an authorized dealer. When it comes to service, remember that authorized dealers know your Jeep® best, have factory-trained technicians and genuine Mopar® parts, and care about your satisfaction.
Page 10: Symbols Key
SYMBOLS KEY Do not attempt sharp turns, abrupt maneuvers, or other unsafe driving actions that can cause loss of vehicle control. Failure to operate this vehicle safely may result in a collision, rollover of the vehicle, and severe or fatal injury. Drive carefully. These statements apply to operating procedures that WARNING! could result in a collision, bodily injury and/or death.
Page 11: Symbol Glossary
SYMBOL GLOSSARY Red Warning Lights Some car components have colored labels with symbols indicating precautions to be Electronic Throttle Control (ETC) Warning Light observed when using this component. It is important to follow all warnings when operating page 82 Ú your vehicle.
Page 12 Red Warning Lights Yellow Warning Lights Transmission Temperature Warning Light Active Lane Management Warning Light page 83 page 84 Ú Ú Vehicle Security Warning Light Service Active Lane Management Warning Light Ú page 83 Ú page 84 Low Coolant Level Warning Light Yellow Warning Lights page 84 Ú...
Page 13 Yellow Warning Lights Yellow Indicator Lights Service Stop/Start System Warning Light Forward Collision Warning (FCW) OFF Indicator Light page 85 page 87 Ú Ú Tire Pressure Monitoring System (TPMS) Warning Light Immobilizer Fail/VPS Electrical Alarm Indicator Light page 85 page 87 Ú...
Page 14 Green Indicator Lights White Indicator Lights Cruise Control SET Indicator Light Cruise Control Ready Indicator Light page 87 page 88 Ú Ú Stop/Start Active Indicator Light Cruise Control SET Indicator Light Ú page 87 Ú page 88 Automatic High Beam Indicator Light Blue Indicator Lights page 88 Ú...
Page 15: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE KEYS NOTE: In case the ignition switch does not change with the push of a button, the key fob may have a low or fully depleted battery. A low key fob battery can be verified by referring to the instrument cluster, which will display directions to Your vehicle is equipped with a keyless ignition key fob.
Page 16 GETTING TO KNOW YOUR VEHICLE Key Left Vehicle Feature Key Fob: Remove the emergency key (2) by sliding the If a valid key fob is no longer detected inside the vehicle emergency key release (1) on the back of the key fob while the vehicle’s ignition system is in the ON/RUN or and pulling the emergency key out with your other START position, the message “Key Fob Has Left The...
Page 17: Sentry Key
GETTING TO KNOW YOUR VEHICLE To assemble the key fob case, snap the two halves that are programmed to the vehicle can be used to start WARNING! together. and operate the vehicle. The system cannot reprogram a key fob obtained from another vehicle. ...
Page 18: Ignition Switch
GETTING TO KNOW YOUR VEHICLE IGNITION SWITCH The push button ignition can be placed in the following modes: ‘ ™ I EYLESS NTER GNITION  The engine is stopped. This feature allows the driver to operate the ignition with  Some electrical devices (e.g. power locks, alarm, etc.) the push of a button as long as the key fob is in the are still available.
Page 19: Remote Start - If Equipped
GETTING TO KNOW YOUR VEHICLE REMOTE START — IF EQUIPPED EMOTE TART WARNING! Push and release the Remote Start button on the key fob This system uses the key fob to start the engine  Do not leave the key fob in or near the vehicle, or in twice within five seconds.
Page 20: To Exit Remote Start Mode
GETTING TO KNOW YOUR VEHICLE All of the following conditions must be met before the adjust the settings depending on ambient conditions. See EMOTE TART engine will remote start: “Remote Start Comfort Systems — If Equipped” in the next To drive the vehicle after starting the Remote Start section for detailed operation.
Page 21: Remote Start Windshield Wiper De-Icer Activation
GETTING TO KNOW YOUR VEHICLE For more information on ATC, MTC, and climate control  Remote Start Disabled — Start Vehicle To Reset  The Vehicle Security system does not monitor glass breakage or the movement of objects or people inside settings, see page 45.
Page 22: To Disarm The System
GETTING TO KNOW YOUR VEHICLE exterior lights will flash, and the horn will sound. If this To lock each door, rotate the door lock knob on each door ISARM YSTEM occurs, disarm the Vehicle Security system. trim panel forward until the lock indicator is shown. To The Vehicle Security system can be disarmed using any of unlock the front doors, pull the inside door handle to the EARMING...
Page 23: Power Door Locks
GETTING TO KNOW YOUR VEHICLE If you push the power door lock switch while the ignition is  The doors may unlock when water is sprayed on the WARNING! in the ON/RUN position, and any door or the liftgate is Passive Entry door handles, if the key fob is located open, the power locks will not operate.
Page 24 GETTING TO KNOW YOUR VEHICLE Frequency Operated Button Integrated Key (FOBIK-Safe)  The doors are manually locked using the door lock knobs. To minimize the possibility of unintentionally locking a Passive Entry key fob inside your vehicle, the Passive Entry ...
Page 25: Automatic Door Locks
GETTING TO KNOW YOUR VEHICLE To Unlock/Enter The Liftgate UTOMATIC NLOCK OORS The doors will unlock automatically on vehicles with power door locks if: The Automatic Unlock Doors On Exit feature is enabled. All doors are closed. The gear selector was not in PARK, then is placed in PARK.
Page 26: Steering Wheel
GETTING TO KNOW YOUR VEHICLE — EATED TEERING HEEL WARNING! QUIPPED Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from The steering wheel contains a heating element the outside when the Child-Protection locks are that helps warm your hands in cold weather.
Page 27: Driver Memory Settings - If Equipped
GETTING TO KNOW YOUR VEHICLE INKING NLINKING EMOTE WARNING! EYLESS NTRY EMORY  Do not place anything on the steering wheel that insulates against heat, such as a blanket or steering Your remote keyless entry key fob can be programmed to wheel covers of any type and material.
Page 28: Memory Position Recall
GETTING TO KNOW YOUR VEHICLE ) — EMORY OSITION ECALL ANUAL DJUSTMENT RONT EATS WARNING! QUIPPED NOTE:  Adjusting a seat while driving may be dangerous. The vehicle must be in PARK to recall memory positions. Moving a seat while driving could result in loss of Manual Front Seat Forward/Rearward If a recall is attempted when the vehicle is not in PARK, a control which could cause a collision and serious...
Page 29: Manual Adjustment (Rear Seats)
GETTING TO KNOW YOUR VEHICLE Manual Front Seat Recline Adjustment Fold-Forward Front Passenger Seat — ANUAL DJUSTMENT EATS If Equipped To adjust the seatback, lift the lever located on the outboard side of the seat, lean back to the desired WARNING! This feature allows for extended cargo space.
Page 30: Power Adjustment (Front Seats) - If Equipped
GETTING TO KNOW YOUR VEHICLE TO LOWER THE REAR SEAT TO RAISE THE REAR SEAT NOTE: Pull the seatback release lever located on either side of the upper outer edge of the seat. If interference from the cargo area prevents the seatback from fully locking, you will have difficulty returning the seat to its proper position.
Page 31: Heated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE — I Reclining The Seatback Forward Or Easy Entry/Exit Seat — If Equipped EATED EATS QUIPPED Rearward This feature provides automatic driver seat positioning to enhance driver mobility when entering and exiting the WARNING! The seatback can be reclined both forward and rearward. vehicle.
Page 32: Front Ventilated Seats
GETTING TO KNOW YOUR VEHICLE — If the HI level setting is selected, the system will RONT ENTILATED EATS ESTRAINTS automatically switch to LO level after approximately QUIPPED 60 minutes of continuous operation. At that time, the Head restraints are designed to reduce the risk of injury by display will change from HI to LO, indicating the change.
Page 33 GETTING TO KNOW YOUR VEHICLE Front Head Restraint Adjustment NOTE: The head restraints should only be removed by qualified Your vehicle is equipped with front two way driver and technicians, for service purposes only. If either of the head passenger head restraints. restraints require removal, see an authorized dealer.
Page 34: Uconnect Voice Recognition Quick
Call, And Send Or Receive A Text VR button or say the “Wake Up” word, wait until “Hey Uconnect” or “Hey Jeep®”. The factory default Wake 1 — For Vehicles Not Equipped With Navigation: Push The after the beep, then say your Voice Command.
Page 35: Mirrors
GETTING TO KNOW YOUR VEHICLE MIRRORS left and right, or tilted up and down. The mirror should be LLUMINATED ANITY IRRORS adjusted to center on the view through the rear window. To access an illuminated vanity mirror, flip down one of the This mirror automatically adjusts for headlight glare from NSIDE EARVIEW...
Page 36: Outside Mirrors
GETTING TO KNOW YOUR VEHICLE Power Folding — If Equipped UTSIDE IRRORS OWER DJUSTMENT IRRORS To fold the door mirrors in using the Power Folding Mirror The outside mirror(s) can be adjusted to the center of the The power mirror control switch is located on the driver's function, rotate the control switch to the power folding adjacent lane of traffic to achieve the optimal view.
Page 37: Heated Mirrors - If Equipped
GETTING TO KNOW YOUR VEHICLE — I ®  The HomeLink® buttons that are located in the over- EATED IRRORS QUIPPED RASING head console or sunvisor designate the three different HANNELS These mirrors are heated to melt frost or ice. HomeLink®...
Page 38: Programming Homelink® To A Garage Door
GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: WARNING! The “LEARN” or “TRAIN” button is not the button you Make sure the garage door opener motor is plugged in normally use to operate the device. before moving on to the rolling code/non-rolling code final ...
Page 39: Reprogramming A Single Homelink® Button
GETTING TO KNOW YOUR VEHICLE It may be helpful to unplug the device during the cycling Push and hold the programmed HomeLink® button EPROGRAMMING INGLE process to prevent possible overheating of the garage and observe the indicator light. ® B UTTON door or gate motor.
Page 40: Security
GETTING TO KNOW YOUR VEHICLE ECURITY EADLIGHT WITCH WARNING! It is advised to erase all channels before you sell or turn in The headlight switch is located on the left side of the  Your motorized door or gate will open and close while your vehicle.
Page 41: Daytime Running Lights (Drls)
GETTING TO KNOW YOUR VEHICLE Rotate the headlight switch clockwise to the first detent WITCH for parking lights and instrument panel lights operation. Rotate the headlight switch to the second detent for Push the multifunction lever toward the instrument panel headlights, parking lights and instrument panel lights to switch the headlights to high beams.
Page 42: Automatic Headlights - If Equipped
GETTING TO KNOW YOUR VEHICLE — I NOTE: UTOMATIC EADLIGHTS QUIPPED  The lights must be turned off within 45 seconds of This system automatically turns the headlights on or off placing the ignition in the OFF position to activate this according to ambient light levels.
Page 43: Turn Signals
GETTING TO KNOW YOUR VEHICLE Cornering Lights HANGE SSIST The cornering lights are a feature to improve visibility at Lightly push the multifunction lever up or down, without night while turning the vehicle. When activated, a light moving beyond the detent, and the turn signal will flash incorporated in the front fog light will illuminate on the five times then automatically turn off.
Page 44 GETTING TO KNOW YOUR VEHICLE Instrument Panel Dimmer Control The instrument panel dimmer control is part of the headlight switch and is located on the driver’s side of the instrument panel. Rotating the instrument panel dimmer up or down will adjust the brightness of the instrument panel lights ONLY when the parking lights or headlights are turned on, AND ONLY if the built in light sensor determines that the...
Page 45: Windshield Wipers And Washers
GETTING TO KNOW YOUR VEHICLE Illuminated Entry — If Equipped INDSHIELD IPER PERATION CAUTION! The Illuminated Entry feature allows you to activate the Rotate the end of the lever to one of the first two detent Always remove any buildup of snow that prevents the low beam, parking lights, and side marker lights for positions for intermittent settings.
Page 46: Rain Sensing Wipers - If Equipped
GETTING TO KNOW YOUR VEHICLE Mist The Rain Sensing system has protection features for the The rear wiper/washer controls are located on the wiper blades and arms, and will not operate under the windshield wiper/washer lever on the right side of the Push the lever upward to the MIST position and release for following conditions: steering column.
Page 47: Windshield Wiper De-Icer
GETTING TO KNOW YOUR VEHICLE — A/C Button INDSHIELD IPER UTOMATIC LIMATE ONTROL Press and release the A/C button on the QUIPPED ESCRIPTIONS UNCTIONS touchscreen, or push the button on the Your vehicle may be equipped with a Windshield Wiper faceplate to change the current setting.
Page 48 GETTING TO KNOW YOUR VEHICLE Driver And Passenger Temperature NOTE: performance. When toggling the front defrost mode button, the Climate Control system will return to the Control Buttons  After 25 minutes of continuous use, Recirculation previous setting. mode will automatically shut off for two minutes to These buttons provide the driver and passenger with Rear Defrost Button allow fresh air intake inside the cabin to maintain suffi-...
Page 49 GETTING TO KNOW YOUR VEHICLE Blower Control Defrost Mode Touchscreen Press one of the MODE buttons to change the airflow Blower Control is used to regulate the amount Air comes from the windshield and side window distribution mode. of air forced through the Climate Control demist outlets.
Page 50: Manual Climate Control Descriptions And
GETTING TO KNOW YOUR VEHICLE NOTE: On systems with Manual Climate Controls, if equipped, the ANUAL LIMATE ONTROL Recirculation mode is not allowed in Defrost mode to  For Manual Climate Controls, if the system is in Mix, ESCRIPTIONS UNCTIONS improve window clearing operation.
Page 51 GETTING TO KNOW YOUR VEHICLE Blower Control Panel Mode CAUTION! Blower Control regulates the amount of air Air comes from the outlets in the instrument Failure to follow these cautions can cause damage to forced through the Climate Control system. panel.
Page 52: Automatic Temperature Control (Atc)
GETTING TO KNOW YOUR VEHICLE Defrost Mode Manual Operation Override UTOMATIC EMPERATURE ONTROL (ATC) Air comes from the windshield and side window This system offers a full complement of manual override demist outlets. When the defrost button is features. The AUTO symbol in the front ATC display will be Automatic Operation selected, the blower level may increase.
Page 53 GETTING TO KNOW YOUR VEHICLE Winter Operation Stop/Start System — If Equipped Operating Tips Chart To ensure the best possible heater and defroster While in an Autostop, the Climate Control system may WEATHER CONTROL SETTINGS performance, make sure the engine cooling system is automatically adjust airflow to maintain cabin comfort.
Page 54: Interior Storage And Equipment
GETTING TO KNOW YOUR VEHICLE INTERIOR STORAGE AND EQUIPMENT USB C Console Storage Compartment ONTROL To open, pull up on the latch and lift the cover. This feature allows an external USB device to be plugged TORAGE into one of the USB ports, located in the center stack of the instrument panel.
Page 55: Power Outlets - If Equipped
GETTING TO KNOW YOUR VEHICLE For example, if a device is plugged into the Type A USB port The second row USB ports can be used to charge an NOTE: and another device is plugged into the Type C USB port, a external device.
Page 56: Wireless Charging Pad
GETTING TO KNOW YOUR VEHICLE — If equipped, a power outlet is located in the rear cargo IRELESS HARGING WARNING! area. QUIPPED  Close the lid when not in use and while driving the vehicle.  If this outlet is mishandled, it may cause an electric shock and failure.
Page 57 GETTING TO KNOW YOUR VEHICLE The wireless charging pad is equipped with an anti-slip  iPhone® 12 (including iPod®) is equipped with NOTE: mat to hold your mobile phone in place, and an LED software to protect the device from overheating. When ...
Page 58: Windows
GETTING TO KNOW YOUR VEHICLE WINDOWS The timing is programmable within Uconnect Settings If the window runs into any obstacle during auto-closure, it will reverse direction and then go back down. Remove the page 145. Ú obstacle and use the window switch again to close the OWER INDOW ONTROLS...
Page 59: Window Lockout Switch
GETTING TO KNOW YOUR VEHICLE and can be minimized. If the buffeting occurs with the rear INDOW OCKOUT WITCH WARNING! windows open, open the front and rear windows together The window lockout switch on the driver's door trim panel to minimize the buffeting. If the buffeting occurs with the ...
Page 60: Opening And Closing The Sunroof
GETTING TO KNOW YOUR VEHICLE Any release of the switch during open or close operation Express Open/Close PENING LOSING UNROOF will stop the sunroof movement. The sunroof will remain in Push the sunshade switch to open and release it within The sunroof has two programmed open positions, comfort a partially opened position until the switch is operated and one-half second and the sunshade will open to the half...
Page 61: Pinch Protect Feature
GETTING TO KNOW YOUR VEHICLE Any release of the switch will stop the movement and the NOTE: sunshade will remain in a partially opened position until  Vehicle must be at a stop and the gear selector must the switch is pushed again. be in PARK.
Page 62: Liftgate
GETTING TO KNOW YOUR VEHICLE LIFTGATE — I OWER IFTGATE QUIPPED WARNING! The power liftgate may be opened by pushing Driving with the liftgate open can allow poisonous NLOCK IFTGATE the liftgate button on the key fob. Push the exhaust gases into your vehicle. You and your liftgate button on the key fob twice within five passengers could be injured by these fumes.
Page 63 GETTING TO KNOW YOUR VEHICLE — I NOTE:  If the electronic liftgate release handle is pushed a ANDS IFTGATE QUIPPED second time while the power liftgate is opening, the  Before closing the liftgate, make sure to be in posses- liftgate motor will disengage to allow manual operation.
Page 64: Cargo Area Features
GETTING TO KNOW YOUR VEHICLE NOTE:  The power liftgate will release, but not power open, in Gas props support the liftgate in the open position. temperatures below −12°F (−24°C). Be sure to However, because the gas pressure drops with ...
Page 65 GETTING TO KNOW YOUR VEHICLE To change the level of the load floor, pull upward on the Raising The Load Floor To fully raise the load floor, pull upward on the floor load floor handle, pull the floor outward, and place the handle, pull the floor outward, then position the floor To raise the load floor for access to the Tire Service Kit, or back of the floor into the desired position.
Page 66 GETTING TO KNOW YOUR VEHICLE Cargo Tie-Down Hooks And Loops Rear Storage Bins WARNING! The tie-downs located on the cargo area floor should be The rear storage bins are located in the rear of the vehicle The weight and position of cargo and passengers can used to secure loads safely when the vehicle is moving.
Page 67: Roof Luggage Rack - If Equipped
GETTING TO KNOW YOUR VEHICLE ROOF LUGGAGE RACK — IF EQUIPPED WARNING! CAUTION! The load carried on the roof, when equipped with a Cargo must be securely tied down before driving your  Travel at reduced speeds and turn corners carefully luggage rack, must not exceed 150 lb (68 kg), and it vehicle.
Page 68: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL BASE / MIDLINE INSTRUMENT CLUSTER...
Page 69 GETTING TO KNOW YOUR INSTRUMENT PANEL...
Page 70: Base / Midline Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL Use this QR code to access your digital IDLINE NSTRUMENT LUSTER WARNING! experience. ESCRIPTIONS A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. It is Tachometer recommended to call an authorized dealer for service if ...
Page 71: Premium Instrument Cluster
GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER...
Page 72: Premium Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL Tachometer working and give you warnings when they aren’t. The REMIUM NSTRUMENT LUSTER steering wheel mounted controls allow you to scroll  Indicates the engine speed in revolutions per ESCRIPTIONS through and enter the main menus and submenus. You minute (RPM x 1000).
Page 73 GETTING TO KNOW YOUR INSTRUMENT PANEL The systems allow the driver to select information by  Up Arrow Button  Down Arrow Button pushing the following buttons mounted on the steering Push and release the up arrow button to scroll Push and release the down arrow button to scroll wheel:...
Page 74 GETTING TO KNOW YOUR INSTRUMENT PANEL Custom Tile Configuration You can customize your Instrument Cluster Display with up  Vehicle Info to five tiles that may consist of the following:  Coolant Temp To customize the instrument cluster further, you are able to select up to five tiles to display information based on ...
Page 75: Oil Change Reset
GETTING TO KNOW YOUR INSTRUMENT PANEL The instrument cluster display is located in the center To reset the oil change indicator after performing the HANGE ESET portion of the cluster and consist of multiple sections: scheduled maintenance, refer to the following procedure: Use this QR code to access your digital ...
Page 76: Instrument Cluster Display Menu Items
GETTING TO KNOW YOUR INSTRUMENT PANEL Remote Start Canceled Door Open Remote Start Canceled Hood Open Remote Start Canceled Liftgate Open Remote Start Canceled Time Expired Remote Start Disabled Start To Reset Service Air Bag System Service Air Bag Warning Light Door(s) Open Service Transmission Liftgate Open...
Page 77 GETTING TO KNOW YOUR INSTRUMENT PANEL Main Menu VEHICLE INFO (CUSTOMER INFORMATION Transmission Temperature — Automatic Transmission Only FEATURES) DRIVER INFO— IF EQUIPPED Displays the actual transmission temperature. Push and release the up or down arrow button until Oil Temperature Base/Midline Cluster the Vehicle Info Menu item is displayed in the instrument Displays the level of oil temperature.
Page 78 GETTING TO KNOW YOUR INSTRUMENT PANEL  Tire Pressure Adaptive Cruise Control Off The instrument cluster display displays the current Active Lane Management system settings. The information  If tire pressure is OK for all tires a vehicle ICON is When ACC is deactivated, the display will read “Adaptive displayed depends on Active Lane Management system displayed with tire pressure values in each corner...
Page 79 GETTING TO KNOW YOUR INSTRUMENT PANEL TRIP INFO STOP/START – IF EQUIPPED SCREEN SETUP Push and release the up or down arrow button until Push and release the up or down arrow button until Push and release the up or down arrow button the Trip menu title is displayed in the instrument cluster the Stop/Start menu title is displayed in the instrument...
Page 80 GETTING TO KNOW YOUR INSTRUMENT PANEL  Safety and Assistance Security (Base/Midline Cluster Only) Center  Hill Start Assist Passenger Air Bag Disable (PAD): a selection of Passenger None Range to Empty Date Air Bag Disable (ON/OFF) may be made if a child restraint NOTE: Average must be installed in the front seat.
Page 81 GETTING TO KNOW YOUR INSTRUMENT PANEL  Buzzer Volume: There are 4 options: Off, Low, Medium, Doors And Locks Calibration (If Equipped) Loud By selecting Doors and Locks, the following adjustments This compass is self-calibrating, which eliminates the  Brake Service (If Equipped): activation of the procedure can be made: need to set the compass manually.
Page 82: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL The electrical loads that may be switched off (if equipped),  The battery was discharged by an electrical load left on ATTERY AVER ATTERY AVER and vehicle functions which can be effected by load when the vehicle was parked.
Page 83: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES Brake Warning Light If brake failure is indicated, immediate repair is necessary. This warning light monitors various brake WARNING! The warning/indicator lights will illuminate in the functions, including brake fluid level and instrument panel together with a dedicated message and/ parking brake application.
Page 84 GETTING TO KNOW YOUR INSTRUMENT PANEL Battery Charge Warning Light Engine Temperature Warning Light WARNING! This warning light will illuminate when the This warning light will illuminate to warn of an Continued operation with reduced assist could pose a battery is not charging properly. If it stays on overheated engine condition.
Page 85: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Oil Pressure Warning Light Transmission Fault Warning Light Vehicle Security Warning Light — If Equipped This warning light will illuminate to indicate low This light will illuminate (together with a engine oil pressure. If the light turns on while message in the instrument cluster display and This light will flash at a fast rate for driving, stop the vehicle, shut off the engine as...
Page 86 GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Stability Control (ESC) Active Fuel Cutoff Warning Light — If Equipped Low Fuel Warning Light Warning Light — If Equipped This warning light will illuminate after an Depending on whether the tank size is 13.5 gal accident has occurred, and the system has (51 L) or 15.8 gal (60 L), the Low Fuel Indicator This warning light will indicate when the...
Page 87 GETTING TO KNOW YOUR INSTRUMENT PANEL Service 4WD Warning Light — If Equipped Tire Pressure Monitoring System (TPMS) When the engine is running, the MIL may flash to alert serious conditions that could lead to immediate loss of Warning Light — If Equipped This warning light will illuminate to signal a fault power or severe catalytic converter damage.
Page 88: Yellow Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Towing Hook Breakdown Warning Light — Each tire, including the spare (if provided), should be Your vehicle has also been equipped with a TPMS checked monthly when cold and inflated to the inflation malfunction indicator to indicate when the system is not If Equipped pressure recommended by the vehicle manufacturer on operating properly.
Page 89: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Active Speed Limiter Fault Indicator Turn Signal Indicator Lights REEN NDICATOR IGHTS Light — If Equipped When the left or right turn signal is activated, Auto HOLD Indicator Light — If Equipped the turn signal indicator will flash This warning light will illuminate to signal when Auto HOLD keeps your vehicle at a complete independently and the corresponding exterior...
Page 90: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Automatic High Beam Indicator Light — Cruise Control Ready Indicator Light — NDICATOR IGHTS If Equipped If Equipped With A Premium Instrument Cruise Control Ready Indicator Light — Cluster This indicator shows that the automatic high If Equipped With Base Instrument Cluster beam headlights are on page 38.
Page 91: Onboard Diagnostic System (Obd Ii)
GETTING TO KNOW YOUR INSTRUMENT PANEL As soon as you cycle the ignition switch to the ON CAUTION! WARNING! position, you will see the Malfunction Indicator Light (MIL) symbol come on as part of a normal bulb check.  If the MIL is flashing while the vehicle is running, ...
Page 92: Starting And Operating
STARTING AND OPERATING STARTING THE ENGINE Start the engine with the gear selector in the NEUTRAL or CAUTION! PARK position. Apply the brake before shifting to any driving range. Before starting your vehicle, adjust your seat, adjust both Damage to the transmission may occur if the following inside and outside mirrors, and fasten your seat belts.
Page 93: Cold Weather Operation (Below -22°F Or −30°C)
STARTING AND OPERATING Keyless Enter ’n Go™ — With Driver’s Foot Off The Brake If the engine fails to start within 10 seconds, place CAUTION! Pedal (In PARK Or NEUTRAL Position) the ignition in the OFF position, wait 10 to 15 seconds to allow the starter to cool, then repeat the To prevent damage to the starter, do not continuously The Keyless Enter ’n Go™...
Page 94: Stopping The Engine
STARTING AND OPERATING While cruising, brief full-throttle acceleration within the You can engage the parking brake in two ways: TOPPING NGINE limits of local traffic laws contributes to a good break-in.  Manually, by applying the EPB switch. Vehicles Equipped With Electronic Key Wide-open throttle acceleration in low gear can be ...
Page 95 STARTING AND OPERATING NOTE: WARNING! WARNING! The EPB Warning Light will illuminate if the EPB switch is held for longer than 60 seconds in either the released or  Do not rely on the parking brake to operate effec-  Always fully apply the parking brake when leaving applied position.
Page 96 STARTING AND OPERATING SafeHold the vehicle at a stop until the driver applies the accelerator WARNING! pedal. Auto Hold can be activated or deactivated by SafeHold is a safety feature of the EPB system that will pushing the HOLD button located on the switch bank. Driving the vehicle with the parking brake engaged, or engage the parking brake automatically if the vehicle is repeated use of the parking brake to slow the vehicle,...
Page 97: Automatic Transmission
STARTING AND OPERATING Brake Service Mode When brake service work is complete, the following steps WARNING! must be followed to reset the parking brake system to We recommend having your brakes serviced by an normal operation:  Your vehicle could move and injure you and others if authorized dealer.
Page 98: Ignition Park Interlock
STARTING AND OPERATING NOTE: GNITION NTERLOCK WARNING!  The transmission electronics are self-calibrating; This vehicle is equipped with an Ignition Park Interlock  Never leave children alone in a vehicle, or with therefore, the first few shifts on a new vehicle may be which requires the transmission to be in PARK (P) before access to an unlocked vehicle.
Page 99 STARTING AND OPERATING Gear Ranges The transmission gear selector provides PARK, REVERSE, NOTE: NEUTRAL, DRIVE, and AutoStick (+/-) shift positions. Block the wheels with a wedge or a stone if the vehicle is Do not press the accelerator pedal when shifting out of Manual shifts can be made using the AutoStick shift parked on a steep slope.
Page 100 STARTING AND OPERATING CAUTION! WARNING! WARNING!  Before moving the transmission gear selector out of Do not coast in NEUTRAL and never turn off the ignition  Unintended movement of a vehicle could injure PARK, you must turn the ignition to the ON/RUN posi- to coast down a hill.
Page 101 STARTING AND OPERATING If the transmission temperature exceeds normal operating Operation  The system will ignore attempts to upshift at too low of limits, the transmission controller may modify the a vehicle speed. When the gear selector is in the AutoStick position (beside transmission shift schedule, reduce engine torque, and/or the DRIVE (D) position), it can be moved forward and ...
Page 102: Four-Wheel Drive Operation - If Equipped
STARTING AND OPERATING Four-Wheel Drive (4x4) In the event of a momentary problem, the transmission NOTE: can be reset to regain all forward gears by performing the The torque converter clutch will not engage until the The four-wheel drive (4WD) is fully automatic in normal following steps: engine and/or transmission is warm (usually after 1 to driving mode.
Page 103: Selec-Terrain - If Equipped
STARTING AND OPERATING SELEC-TERRAIN — IF EQUIPPED Active Drive Control — If Equipped on certain operating conditions), the transmission may use SECOND gear (rather than FIRST gear) during The Power Transfer Unit (PTU) is locked to ensure launches, to minimize wheel slippage. Selec-Terrain combines the capabilities of the vehicle immediate availability of torque to the rear drive axles.
Page 104: Stop/Start System - If Equipped
STARTING AND OPERATING If the “SERVICE POWER STEERING” or “POWER STEERING This vehicle has been upgraded with a heavy-duty starter,  Driver’s seat belt is not buckled. ASSIST OFF - SERVICE SYSTEM” message and a steering enhanced battery, and other upgraded engine parts, to ...
Page 105: To Start The Engine While In Autostop Mode
STARTING AND OPERATING Conditions That Force An Application Of The Electric Park Push the Stop/Start OFF switch (located on the switch TART NGINE HILE Brake While In Autostop Mode: bank). The light on the switch will illuminate. The “STOP/ UTOSTOP START OFF”...
Page 106: Cruise Control Systems - If Equipped
STARTING AND OPERATING CRUISE CONTROL SYSTEMS — IF EQUIPPED To Activate Push the on/off button to activate the Cruise Control. Your vehicle may be equipped with the Cruise Control “CRUISE CONTROL READY” will appear in the instrument system, or the Adaptive Cruise Control (ACC) system: cluster display to indicate the Cruise Control is on.
Page 107: Adaptive Cruise Control (Acc)
STARTING AND OPERATING To Vary The Speed Setting USING CRUISE CONTROL ON HILLS  Gear selector is moved out of DRIVE  Engine overspeed occurs To Increase Or Decrease The Set Speed The transmission may downshift on hills to maintain the vehicle set speed.
Page 108 STARTING AND OPERATING 1 — Distance Increase Button WARNING! WARNING! 2 — Adaptive Cruise Control (ACC) On/Off  Adaptive Cruise Control (ACC) is a convenience You should turn the ACC system off: 3 — CANC/Cancel system. It is not a substitute for active driver involve- 4 —...
Page 109 STARTING AND OPERATING To Set A Desired Speed The ACC screen may display once again if any of the  When the brakes are overheated following ACC activity occurs:  When the driver’s door is open at low speeds When the vehicle reaches the speed desired, push the ...
Page 110 STARTING AND OPERATING If either system is set when the vehicle speed is above The following conditions will only cancel the ACC system:  ACC cannot be resumed if there is a stationary vehicle 20 mph (32 km/h), the set speed shall be the current in front of your vehicle in close proximity.
Page 111 STARTING AND OPERATING Setting The Following Distance In ACC Metric Speed (km/h) To decrease the distance setting, push the Distance Decrease button and release. Each time the button is  Pushing the SET (+), or SET (-) button once will result in The specified following distance for ACC can be set by pushed, the distance setting decreases by one bar a 1 km/h speed adjustment.
Page 112 STARTING AND OPERATING NOTE: While ACC is holding your vehicle at a standstill, if the This message can sometimes be displayed while driving in driver seat belt is unbuckled or the driver door is opened, highly reflective areas (i.e. ice and snow, or tunnels with The “BRAKE!”...
Page 113 STARTING AND OPERATING OFFSET DRIVING When the condition that deactivated the system is no When the condition that created limited functionality is no longer present, the system will return to the “Adaptive longer present, the system will return to full functionality. ACC may not detect a vehicle in the same lane that is Cruise Control Off”...
Page 114 STARTING AND OPERATING USING ACC ON HILLS STATIONARY OBJECTS AND VEHICLES ACC performance may be limited when driving on hills. ACC does not react to stationary objects or vehicles. For ACC may not detect a vehicle in your lane depending on example, ACC will not react in situations where the vehicle the speed, vehicle load, traffic conditions, and the you are following exits your lane and the vehicle ahead is...
Page 115: Traffic Sign Assist System
STARTING AND OPERATING TRAFFIC SIGN ASSIST SYSTEM — NOTE: NDICATIONS ISPLAY Even if the system is OFF, the speed limit sign will be IF EQUIPPED Detected traffic signs are shown in the instrument cluster displayed when the driver selects it in the HOME screen. display, and can display any combination of signs at one RAFFIC SSIST...
Page 116: Highway Assist System - If Equipped
STARTING AND OPERATING Supplemental Information NOTE: CAUTION! Supplemental information may be displayed along with a  The driver should always obey traffic laws and speed newly detected speed limit, indicating special  The system may have limited operation or not work at limits.
Page 117: Turning Highway Assist On Or Off
STARTING AND OPERATING If ACC was not active before pushing the HAS on/off URNING IGHWAY SSIST WARNING! button, push the SET (+) button or the SET (-) button and release when the desired driving speed is shown The Highway Assist system is a convenience system. in the instrument cluster display.
Page 118: Indications On The Display
STARTING AND OPERATING System Engagement Conditions System Deactivation NDICATIONS ISPLAY The following conditions must be met after enabling the The system will be deactivated in any of the following The Highway Assist system status can always be viewed in Highway Assist system before the system will engage: situations: the instrument cluster display, and status changes are ...
Page 119: System Status
STARTING AND OPERATING Highway Assist Indicators Are Red  Two haptic brake jerk warnings will be issued WARNING! (red warning light is being issued).  Driver inattentiveness is still being detected, or driver  Maintain a safe distance from other vehicles and pay take-over is being requested, warning the driver to ...
Page 120: Parksense Front/Rear Park Assist
STARTING AND OPERATING The Highway Assist system may have limited or reduced ParkSense will retain the last system state (enabled or ENSE ARNING ISPLAY functionality when one of the following conditions occur: disabled) from the last ignition cycle when the ignition is changed to the ON/RUN position.
Page 121 STARTING AND OPERATING Front/Rear/Side ParkSense Arcs 1 — No Tone/Solid Arc 7 — Fast Tone/Flashing Arc 2 — No Tone/Flashing Arc 8 — Slow Tone/Solid Arc 3 — Fast Tone/Flashing Arc 9 — Slow Tone/Solid Arc 4 — Continuous Tone/Flashing Arc 10 —...
Page 122 STARTING AND OPERATING The vehicle is close to the obstacle when the instrument cluster display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS FOR REAR Rear Distance Greater than 79-59 inches...
Page 123: Enabling And Disabling Parksense
STARTING AND OPERATING Front Park Assist Audible Alerts ERVICE ENSE SSIST ENSE YSTEM SAGE ParkSense will turn off the Front Park Assist audible alert YSTEM RECAUTIONS (chime) after approximately three seconds when an obstacle has been detected, the vehicle is stationary, and During vehicle start up, when the ParkSense System has NOTE: brake pedal is applied.
Page 124: Side Distance Warning (Sdw) System
STARTING AND OPERATING NOTE: WARNING ALERTS CAUTION! If any objects are attached to the bumper within a 6.5 ft Less than (2 m) field of view, they will interfere and cause false alerts  ParkSense is only a parking aid and it is unable to Distance 30 –...
Page 125 STARTING AND OPERATING ParkSense Usage Precautions  The presence of a tow hook without a trailer may inter- fere with the correct operation of the parking sensors. Some conditions may influence the performance of the Before using the ParkSense system, it is recom- Side Distance Warning system: mended to remove the removable tow hook ball NOTE:...
Page 126: Parksense Active Park Assist
STARTING AND OPERATING NOTE: To enable or disable the ParkSense Active Park Assist CAUTION! system, push the ParkSense Active Park Assist switch  The driver is always responsible for controlling the once (LED turns on). Pushing the switch a second time will ...
Page 127: Parallel/Perpendicular Parking Space Assistance Operation
STARTING AND OPERATING The ParkSense Active Park Assist system will only operate cluster display. You may select perpendicular, parallel, or  When searching for a parking space, the driver should and search for a parking space when the following parallel park exit. The arrow buttons on the left side of the drive as parallel or perpendicular (depending on the conditions are present: steering wheel can be used to switch parking maneuvers.
Page 128 STARTING AND OPERATING The system may then instruct the driver to wait for steering The system may instruct several more gear shifts (DRIVE provide a warning to the driver at 3 mph (5 km/h) that to complete before then instructing to check surroundings and REVERSE), with hands off of the steering wheel, tells them to slow down.
Page 129: Exiting The Parking Space
STARTING AND OPERATING or accelerator pedals while the system handles the End Of Maneuver CAUTION! steering automatically for exiting the parking space. If the The semi-automatic maneuver ends when the display driver continues to carry out a voluntary or involuntary ...
Page 130: Active Lane Management System
STARTING AND OPERATING  The use of wheels and tires that are different size to the NOTE: If the driver crosses the lane marking, the system will original equipment could affect the operation of the either guide the vehicle back to the center of the lane, ...
Page 131: Turning Active Lane Management On Or Off
STARTING AND OPERATING If the driver continues to drift out of the lane, the system  When the system senses the lane line has been CTIVE ANAGEMENT ARNING provides a flashing visual warning through the instrument approached (but not crossed), the left lane line will ESSAGE cluster display as well as a haptic steering wheel vibration change to solid yellow and the system will provide a...
Page 132: Changing Active Lane Management Status
STARTING AND OPERATING Left Lane Departure — Both Lanes Detected NOTE:  When the system is on, the lane lines turn from gray to  The Active Lane Management system operates with green to indicate that both of the lane markings have similar behavior for a right lane departure.
Page 133: Parkview Rear Back Up Camera
STARTING AND OPERATING  The Blind Spot Monitoring system will be forced on image will continue to be displayed for up to 10 seconds CAUTION! when the ALM system is enabled. unless the following conditions occur: The vehicle speed exceeds 8 mph (13 km/h), the vehicle is shifted into ...
Page 134: Surround View Camera System - If Equipped
STARTING AND OPERATING If the vehicle is in PARK, Zoom View is available until the When the vehicle is shifted into REVERSE, the Rear View Modes Of Operation gear selector is placed in DRIVE or REVERSE and speeds and Top View is the default view of the system. Manual activation of the Surround View Camera is are at or above 8 mph (13 km/h).
Page 135: Zoom View
STARTING AND OPERATING Rear View Plus Top View If the Back Up Camera was manually activated through the CAUTION! Controls menu of the Uconnect system, exiting out of the This is the default view of the system in display screen will return to the Controls menu. ...
Page 136: Refueling The Vehicle
STARTING AND OPERATING Shifting to NEUTRAL from any gear will maintain the WARNING! selected view (Zoom or Standard) as long as the vehicle speed is below 8 mph (13 km/h).  A fire may result if fuel is pumped into a portable container that is inside of a vehicle.
Page 137: Trailer Towing
STARTING AND OPERATING TRAILER TOWING Payload values are determined by weighing your vehicle on a commercial scale before any occupants or cargo are The payload of a vehicle is defined as the allowable load added. In this section you will find safety tips and information on weight a truck can carry, including the weight of the driver, limits to the type of towing you can reasonably do with your Loading...
Page 138 STARTING AND OPERATING Gross Axle Weight Rating (GAWR) Trailer Frontal Area Weight-Distributing Hitch The GAWR is the maximum capacity of the front and rear The frontal area is the maximum height multiplied by the A Weight-Distributing system works by applying leverage axles.
Page 139: Trailer Towing Weights (Maximum Trailer Weight Ratings)
STARTING AND OPERATING RAILER OWING EIGHTS AXIMUM RAILER EIGHT ATINGS Engine/Transmission Model Maximum GTW Maximum Trailer TW 2.0L / 8-Speed Auto 2,000 lb (907 kg) 200 lb (90 kg) When towing a trailer, the technically permissible laden weight may be exceeded by not more than 10% or 220 lb (100 kg), whichever is lower provided that the operating speed is restricted to 62 mph (100 km/h) or less.
Page 140: Towing Requirements
STARTING AND OPERATING OWING EQUIREMENTS WARNING! WARNING! To promote proper break-in of your new vehicle drivetrain  Make certain that the load is secured in the trailer  Total weight must be distributed between the tow components, the following guidelines are recommended. and will not shift during travel.
Page 141 STARTING AND OPERATING Towing Requirements — Trailer Brakes The electrical connections are all complete to the vehicle CAUTION! but you must mate the harness to a trailer connector.  Do not interconnect the hydraulic brake system or Refer to the following illustrations. If the trailer weighs more than 1,000 lb (453 kg) vacuum system of your vehicle with that of the trailer.
Page 142: Towing Tips
STARTING AND OPERATING Cruise Control — If Equipped OWING  Do not use on hilly terrain or with heavy loads. Before towing, practice turning, stopping, and backing up  When using the Cruise Control, if you experience speed the trailer in an area located away from heavy traffic. drops greater than 10 mph (16 km/h), disengage until Automatic Transmission you can get back to cruising speed.
Page 143: Recreational Towing (Behind Motorhome)
STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME) OWING EHICLE EHIND NOTHER EHICLE TOWING CONDITION WHEELS OFF THE GROUND FRONT-WHEEL DRIVE (FWD) FOUR-WHEEL DRIVE (4WD) Flat Tow NONE NOT ALLOWED NOT ALLOWED REAR NOT ALLOWED NOT ALLOWED Dolly Tow FRONT NOT ALLOWED On Trailer BEST METHOD —...
Page 144: Recreational Towing - 4X4 Models
STARTING AND OPERATING — Flowing Water ECREATIONAL OWING RIVING If the water is swift flowing and rising (as in storm run-off) 4X4 M ODELS When To Use 4WD LOW Range avoid crossing until the water level recedes and/or the flow rate is reduced. If you must cross flowing-water, avoid Recreational towing (with all four wheels on the ground, or When off-road driving, shift to 4WD LOW for additional depths in excess of 9 inches (22 cm).
Page 145 STARTING AND OPERATING Over-revving the engine can spin the wheels and traction NOTE:  Check threaded fasteners for looseness, particularly will be lost. on the chassis, drivetrain components, steering, and Remember, never drive diagonally across a hill - drive suspension. Retighten them, if required, and torque to straight up or down.
Page 146: Multimedia
MULTIMEDIA UCONNECT SYSTEMS Your vehicle may be equipped with certain security WARNING! features to reduce the risk of unauthorized and unlawful access to vehicle systems and wireless communications. For detailed information about your Uconnect 5/5 NAV  ONLY insert trusted devices/components into your Vehicle software technology continues to evolve over time With 10.1-inch Display, refer to your Uconnect Radio vehicle.
Page 147: Uconnect Settings
MULTIMEDIA UCONNECT SETTINGS Press the Vehicle button, then press the Settings tab on USTOMER ROGRAMMABLE EATURES the top of the touchscreen. In this menu, the Uconnect system allows you to access all of the available The Uconnect system uses a combination of buttons on programmable features.
Page 148 MULTIMEDIA My Profile When the My Profile button is pressed on the touchscreen, the system displays options related to the vehicle’s profiles. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will change the language of the Uconnect system and Instrument Cluster Language Display.
Page 149 This setting will allow you to change the voice options for the radio to “Male” or “Female”. This setting will allow you to set the system “Wake Up” word. The available options are Wake Up Word “Off”, “Hey, Uconnect”, and “Hey, Jeep®”. Voice Barge-in This setting will allow Voice Barge-in to be turned on or off.
Page 150 MULTIMEDIA Setting Name Description This setting will allow you to have pop-up notifications for Navigation. Setting options are Navigation Pop-ups “On” and “Off”. Reset App Drawer to Default Order This setting will reset the app drawer to its factory default layout. Restore Settings to Default This setting will return all the previously changed settings to their factory defaults.
Page 151 MULTIMEDIA Setting Name Description This setting will allow you to adjust the brightness of your theme. Setting options are Theme Mode “Light”, “Dark” and “Auto”. Select to show themes in Light or Dark mode. “Auto” changes the theme with the headlights. This setting will allow you to change the units to “US”, “Metric”, or “Custom”.
Page 152 MULTIMEDIA Setting Name Description This setting will change the distance at which the Forward Collision Warning alert sounds. The “Medium” setting will have the FCW system signal when an object is in view, and the Forward Collision Warning Sensitivity — Located In Automatic Emergency Braking possibility of a collision is detected.
Page 153 MULTIMEDIA Setting Name Description This setting will provide braking assistance if the Rear ParkSense system senses a Rear ParkSense Braking Assist collision with an object. This setting will control Active ParkSense functionality between fully autonomous parking Active ParkSense Mode and semi-autonomous parking. The available options are “Full Auto” and “Steering Only”. This setting will turn the Active ParkSense Proximity Chimes on or off.
Page 154 MULTIMEDIA Clock & Date When the Clock & Date button is pressed on the touchscreen, the system displays the different options related to the vehicle’s internal clock. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will sync the time to the GPS receiver in the system.
Page 155 MULTIMEDIA Phone/Bluetooth® When the Phone/Bluetooth® button is pressed on the touchscreen, the system displays the options related to Bluetooth® connectivity from an external audio device or smartphone. The list of paired audio devices or smartphones can be accessed from this menu. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 156 This setting will allow you to set the system’s “Wake Up” word. The available options are Wake Up Word “Off”, “Hey, Uconnect”, and “Hey, Jeep®”. This setting allows you to respond to a Voice Response before the statement is Voice Barge-In completed by the system.
Page 157 MULTIMEDIA Camera When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description ParkView Backup Camera This setting will turn the ParkView Backup Camera on or off. This setting will add a delay to the ParkView Backup Camera when shifting out of ParkView Backup Camera Delay REVERSE.
Page 158 MULTIMEDIA Lights When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights. NOTE:  When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle purchase. ...
Page 159 MULTIMEDIA Brakes After pressing the Brakes button on the touchscreen, the following settings will be available: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Auto Park Brake This setting will turn the Auto Park Brake on or off. Brake Service This setting will allow you to retract the brakes for servicing.
Page 160 MULTIMEDIA Setting Name Description Passive Entry This setting will allow you to turn the Passive Entry feature (Keyless Enter ‘n Go™) on or off. This setting will chime an audible alert when the power liftgate is raising or lowering. Power Liftgate Alert Selectable options are “On”...
Page 161 MULTIMEDIA Key Off Options When the Key Off Options button is pressed on the touchscreen, the system displays the options related to vehicle shutoff. These settings will only activate when the ignition is set to OFF. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will keep the radio running after the engine is turned off.
Page 162 MULTIMEDIA Audio When the Audio button is pressed on the touchscreen, the system displays options related to the vehicle’s sound system. These settings can change the audio location within the vehicle, adjust the bass or treble levels, and auto-play settings from an audio device or smartphone. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 163 MULTIMEDIA Notifications When the Notifications button is pressed on the touchscreen, the system displays the options related to Notifications for the system. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will turn off the Notification chime that plays when a new notification is sent. Notification Sounds The options are “On”...
Page 164 MULTIMEDIA Software Updates When the Software Updates button is pressed on the touchscreen, the system will display the setting related to updating the Uconnect software. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will allow software updates to happen over Wi-Fi. Selectable options for the Software Downloads over Wi-Fi setting are “On”...
Page 165 MULTIMEDIA Reset When the Reset button is pressed on the touchscreen, the system displays the options related to resetting the Uconnect system back to its default settings. These settings can clear personal data and reset selected settings from other menus. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 166: Steering Wheel Audio Controls - If Equipped
MULTIMEDIA STEERING WHEEL AUDIO CONTROLS — The following describes the left-hand control operation in EGULATORY AFETY each mode: NFORMATION IF EQUIPPED ADIO PERATION US/CANADA The remote sound system controls are located on the rear Pushing the top of the switch will seek up for the next Exposure to Radio Frequency Radiation surface of the steering wheel at the three and nine o’clock available station and pushing the bottom of the switch will...
Page 167: Safety
SAFETY SAFETY FEATURES The ABS is designed to function optimally with the Original WARNING! Equipment Manufacturer (OEM) tires. Modification may result in degraded ABS performance. (ABS)  The capabilities of an ABS equipped vehicle must RAKE YSTEM never be exploited in a reckless or dangerous WARNING! manner that could jeopardize the user’s safety or the The ABS provides increased vehicle stability and braking...
Page 168: Rear Seat Reminder Alert (Rsra)
SAFETY (RSRA) (EBC) EMINDER LERT LECTRONIC RAKE ONTROL WARNING! YSTEM RSRA alerts you of the possible presence of an object, The Brake Assist System (BAS) cannot prevent the passenger, or pet in the rear seats through a visual and natural laws of physics from acting on the vehicle, nor Your vehicle is equipped with an advanced Electronic auditory notification.
Page 169 SAFETY The only notification the driver receives that the feature is active. If the ESC Activation/Malfunction Indicator Light WARNING! active is the torque applied to the steering wheel. begins to flash during acceleration, ease up on the accelerator and apply as little throttle as possible. Be sure Many factors, such as vehicle loading, road conditions NOTE: to adapt your speed and driving to the prevailing road...
Page 170 SAFETY ESC Operating Modes To turn ESC on again, momentarily push the ESC OFF WARNING! button. This will restore the “ESC On” mode of operation. Depending upon model and mode of operation, the ESC  When in “Partial Off” mode, the TCS functionality of NOTE: system may have multiple operating modes.
Page 171 SAFETY The ESC Activation/Malfunction Indicator Light starts to NOTE: Activating HDC flash as soon as the tires lose traction and the ESC system Once HDC is enabled, it will activate automatically if driven  A warning light will illuminate within the instrument becomes active.
Page 172 SAFETY DISABLING AND ENABLING HSA Feedback To The Driver: The following conditions must be met in order for HSA to activate: The instrument cluster has an HDC icon and the HDC This feature can be turned on or turned off. To change the switch has an LED, which offers feedback to the driver ...
Page 173: Auxiliary Driving Systems
SAFETY AUXILIARY DRIVING SYSTEMS Rain Brake Support (RBS) Trailer Sway Control (TSC) RBS may improve braking performance in wet conditions. TSC uses sensors in the vehicle to recognize an (BSM) — LIND ONITORING It will periodically apply a small amount of brake pressure excessively swaying trailer and will take the appropriate to remove any water buildup on the front brake rotors.
Page 174 SAFETY The BSM detection zone covers approximately one lane The BSM system can become blocked if snow, ice, mud, or The BSM system will provide a visual alert in the width, 12 ft (3.8 m), on both sides of the vehicle. other road contaminations accumulate on the rear fascia/ appropriate side view mirror based on a detected object The zone length starts at the outside mirror and extends...
Page 175 SAFETY Entering From The Side Overtaking Traffic The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foliage, Vehicles that move into your adjacent lanes from either If you pass another vehicle slowly with a relative speed berms, etc.
Page 176 SAFETY Rear Cross Path (RCP) NOTE: Blind Spot Alert Lights/Chime In a parking lot situation, oncoming vehicles can be When operating in Blind Spot Alert Lights/Chime mode, RCP is intended to aid the driver when backing out of blocked by vehicles parked on either side. If the sensors the BSM system will provide a visual alert in the parking spaces where their vision of oncoming vehicles are blocked by other structures or vehicles, the system will...
Page 177: Forward Collision Warning (Fcw) With Mitigation - If Equipped
SAFETY Blocked Sensor If the driver does not take action based upon these When the system determines a collision with the vehicle in progressive warnings, then the system will provide a front of you is no longer probable, the warning message If the system detects degraded performance due to limited level of active braking to help slow the vehicle and will be deactivated...
Page 178 SAFETY FCW Settings By changing the FCW status setting to "Far", the system  FCW may not react to irrelevant objects such as over- provides possible collision warnings on objects farther head objects, ground reflections, objects not in the The Forward Collision menu setting is located in the away.
Page 179: Tire Pressure Monitoring System (Tpms)
SAFETY Pedestrian Emergency Braking (PEB) — RESSURE ONITORING YSTEM WARNING! If Equipped (TPMS) Pedestrian Emergency Braking (PEB) is not intended to PEB is a subsystem of the Forward Collision Warning avoid a collision on its own, nor can PEB detect every The TPMS will warn the driver of a low tire pressure based (FCW) system which provides the driver with audible type of potential collision with a pedestrian.
Page 180 SAFETY The system will automatically update and the Tire  Driving on a significantly underinflated tire causes the CAUTION! Pressure Monitoring System Warning Light will turn off tire to overheat and can lead to tire failure. Underinfla- once the system receives the updated tire pressures. The tion also reduces fuel efficiency and tire tread life, and ...
Page 181 SAFETY Tire Pressure Monitoring System Low NOTE:  Using tire chains on the vehicle When filling warm tires, the tire pressure may need to be Pressure Warnings  Using wheels/tires not equipped with TPMS sensors increased up to an additional 4 psi (28 kPa) above the Vehicles With Compact Spare Or Non-Matching Full Size The Tire Pressure Monitoring System Warning recommended cold placard pressure in order to turn the...
Page 182: Occupant Restraint Systems
SAFETY Once you repair or replace the original road tire and To reactivate the TPMS, replace all four wheel and tire Here are some simple steps you can take to minimize the reinstall it on the vehicle in place of the compact assemblies (road tires) with tires equipped with TPMS risk of harm from a deploying air bag: spare or non-matching full size, the TPMS will update...
Page 183: Seat Belt Systems
SAFETY Enhanced Seat Belt Use Reminder System If the air bag system in this vehicle needs to be The BeltAlert warning sequence may repeat based on modified to accommodate a disabled person, see vehicle speed until the driver and occupied outboard front (BeltAlert) seat passenger seat belts are buckled.
Page 184 SAFETY Lap/Shoulder Belts WARNING! WARNING! All seating positions in your vehicle are equipped with lap/  Do not allow people to ride in any area of your vehicle  A twisted seat belt may not protect you properly. In a shoulder belts.
Page 185 SAFETY Position the lap belt so that it is snug and lies low WARNING! across your hips, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder  A frayed or torn seat belt could rip apart in a collision belt.
Page 186 SAFETY Lap/Shoulder Belt Untwisting Procedure Adjustable Upper Shoulder Belt Anchorage NOTE: The adjustable upper shoulder belt anchorage is equipped Use the following procedure to untwist a twisted lap/ In the driver and outboard front passenger seats, the top with an Easy Up feature. This feature allows the shoulder shoulder belt.
Page 187 SAFETY Second Row Center Seat Belt Operating Instructions The second row center seat belt may feature a seat belt with a mini-latch plate and buckle. The mini-latch plate and buckle (if equipped) should remain connected at all times. If the mini-latch plate and buckle become disconnected, they must be properly reconnected prior to the rear center seat belt being used by an occupant.
Page 188 SAFETY Seat Belt Extender Seat Belts And Pregnant Women To disengage the mini-latch plate from the mini-buckle, insert the regular latch plate into the If a seat belt is not long enough to fit properly, even when center red slot on the mini-buckle. the webbing is fully extended and the adjustable upper shoulder belt anchorage (if equipped) is in its lowest position, an authorized dealer can provide you with a Seat...
Page 189 SAFETY Seat Belt Pretensioner Switchable Automatic Locking Retractors In Automatic Locking Mode, the shoulder belt is automatically pre-locked. The seat belt will still retract to (ALR) The front outboard seat belt system is equipped with remove any slack in the shoulder belt. Use the Automatic pretensioning devices that are designed to remove slack The seat belts in the passenger seating positions are Locking Mode anytime a child restraint is installed in a...
Page 190: Supplemental Restraint Systems (Srs)
SAFETY How To Disengage The Automatic Locking Mode The air bag system must be ready to protect you in a The ORC contains a backup power supply system that may collision. The Occupant Restraint Controller (ORC) deploy the air bag system even if the battery loses power Unbuckle the combination lap/shoulder belt and allow it monitors the internal circuits and interconnecting wiring or it becomes disconnected prior to deployment.
Page 191 SAFETY WARNING! WARNING! Ignoring the Air Bag Warning Light in your instrument  Never install a rear-facing child restraint in the front panel could mean you won’t have the air bag system to seat of a vehicle. Only use a rear-facing child protect you in a collision.
Page 192 SAFETY Front Air Bag Operation Occupant Classification System (OCS) — This vehicle is equipped with a right front passenger Occupant Classification System (OCS) that is designed to Front Passenger Seat Front Air Bags are designed to provide additional provide Passenger Advanced Front Air Bag output protection by supplementing the seat belts.
Page 193 SAFETY The OCS will NOT prevent deployment of the Passenger The OCS determines the front passenger’s most probable Front Passenger Seat Front Passenger Advanced Front Air Bag. The OCS may reduce the inflation classification. The OCS estimates the seated weight on the Occupant Status Air Bag Output rate of the Passenger Advanced Front Air Bag if the OCS...
Page 194 SAFETY Lighter Weight Passengers (Including Small Adults)  The front passenger’s seatback is not in the full upright position. When a lighter weight passenger, including a small adult, occupies the front passenger seat, the OCS may reduce  The front passenger carries or holds an object while the inflation rate of the Passenger Advanced Front Air Bag.
Page 195 SAFETY The following requirements must be strictly followed: WARNING!  Do not modify the front passenger seat assembly or  Placing an object on the floor under the front components in any way. passenger seat may prevent the OCS from working ...
Page 196 SAFETY Knee Impact Bolsters Supplemental Side Air Bags When the SAB deploys, it opens the seam on the outboard side of the seatback’s trim cover. The inflating SAB The Knee Impact Bolsters help protect the knees of the Supplemental Seat-Mounted Side Air Bags (SABs) deploys through the seat seam into the space between the driver and front passenger, and position the front This vehicle is equipped with Supplemental Seat-Mounted...
Page 197 SAFETY The Side Air Bags will not deploy in all side collisions, WARNING! including some collisions at certain angles, or some side collisions that do not impact the area of the passenger  Do not mount equipment, or stack luggage or other compartment.
Page 198 SAFETY If A Deployment Occurs vehicle experiences a rollover or near rollover event, and WARNING! deployment is appropriate, the rollover sensing system will The front air bags are designed to deflate immediately deploy the side air bags and seat belt pretensioners on ...
Page 199 SAFETY Do not drive your vehicle after the air bags have deployed.  Cut off fuel to the engine (if equipped) NOTE: If you are involved in another collision, the air bags will not After an accident, remember to cycle the ignition to the ...
Page 200 SAFETY Enhanced Accident Response System Reset Procedure After the event occurs, when the system is active, a message regarding fuel cutoff is displayed. Turn the ignition switch from ignition AVV/START or MAR/ON/RUN to ignition STOP/OFF/LOCK. Carefully check the vehicle for fuel leaks in the engine compartment and on the ground near the engine compartment and fuel tank before resetting the system and starting the engine.
Page 201 SAFETY Customer Action Customer Will See NOTE: Each step MUST BE held for at least two seconds Right turn light is OFF. 8. Place turn signal in neutral state. Left turn light BLINKS. Right turn light is ON SOLID. 9. Turn left turn signal switch ON. Left turn light is ON SOLID.
Page 202: Child Restraints
SAFETY Maintaining Your Air Bag System Event Data Recorder (EDR) To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. This vehicle is equipped with an event data recorder In addition to the vehicle manufacturer, other parties, WARNING! (EDR).
Page 203 SAFETY There are different sizes and types of restraints for Before buying any restraint system, make sure that it has NOTE: children from newborn size to the child almost large a label certifying that it meets all applicable Safety  For additional information, refer to http:// enough for an adult safety belt.
Page 204 SAFETY Infant And Child Restraints Older Children And Child Restraints WARNING! Safety experts recommend that children ride rear-facing in Children who are two years old or who have outgrown their  Improper installation can lead to failure of an infant the vehicle until they are two years old or until they reach rear-facing convertible child seat can ride forward-facing or child restraint.
Page 205 SAFETY Children Too Large For Booster Seats Does the shoulder belt cross the child’s shoulder position. If the shoulder belt contacts the face or neck, between the neck and arm? move the child closer to the center of the vehicle, or use a Children who are large enough to wear the shoulder belt booster seat to position the seat belt on the child correctly.
Page 206 SAFETY Lower Anchors And Tethers For CHildren LATCH Positions For Installing Child Your vehicle is equipped with the child restraint anchorage system called LATCH, which stands for Lower Anchors and (LATCH) Restraint System Restraints In This Vehicle Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCH-equipped child seats.
Page 207 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the combined weight of What is the weight limit (child’s weight + weight of the child the child and the child restraint is 65 lb (29.5 kg). Use the seat restraint) for using the LATCH anchorage system to attach the 65 lb (29.5 kg) belt and tether anchor instead of the LATCH system once the...
Page 208 SAFETY Locating The LATCH Anchorages WARNING! The lower anchorages are round bars that are Never use the same lower anchorage to attach more found at the rear of the seat cushion where it than one child restraint. If you are installing meets the seatback, below the anchorage LATCH-compatible child restraints next to each other, symbols on the seatback.
Page 209 SAFETY How To Stow An Unused Switchable-ALR Installing Child Restraints Using The Place the child seat between the lower anchorages for that seating position. If the second row seat can (ALR) Seat Belt: Vehicle Seat Belt be reclined, you may recline the seat and/or raise the When using the LATCH attaching system to install a child Child restraint systems are designed to be secured in head restraint (if adjustable) to get a better fit.
Page 210 SAFETY Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle Automatic Locking Retractor (ALR) Locations ALR — Switchable Automatic Locking Retractor Top Tether Anchorage Symbol Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s weight + weight of the child Always use the tether anchor when using the seat belt to restraint) for using the Tether Anchor with the seat belt to Weight limit of the Child Restraint...
Page 211 SAFETY Installing A Child Restraint With A Installing Child Restraints Using The Top Pull on the webbing to make the lap portion tight against the child seat. Switchable Automatic Locking Retractor Tether Anchorage: To lock the seat belt, pull down on the shoulder part (ALR): of the belt until you have pulled all the seat belt WARNING!
Page 212: Safety Tips
SAFETY Look behind the seating position where you plan to WARNING! WARNING! install the child restraint to find the tether anchorage. You may need to move the seat forward  An incorrectly anchored tether strap could lead to  Do not allow people to ride in any area of your vehicle to provide better access to the tether anchorage.
Page 213 SAFETY Air Bag Warning Light WARNING! WARNING! The Air Bag Warning Light will turn on for four to An improperly attached, damaged, folded, or  ONLY use the driver’s side floor mat on the driver’s eight seconds as a bulb check when the stacked floor mat, or damaged floor mat fasteners may side floor area.
Page 214: Periodic Safety Checks You Should Make Outside The Vehicle
SAFETY Open seams or loose connections could permit exhaust ERIODIC AFETY HECKS HOULD XHAUST fumes to seep into the passenger compartment. In UTSIDE EHICLE addition, inspect the exhaust system each time the vehicle WARNING! is raised for lubrication or oil change. Replace as required. Tires Exhaust gases can injure or kill.
Page 215: In Case Of Emergency
IN CASE OF EMERGENCY HAZARD WARNING FLASHERS This is an emergency warning system and it should not be WARNING! used when the vehicle is in motion. Use it only when your vehicle is disabled or signaling a safety hazard warning for The Hazard Warning Flashers button is located in the ALWAYS obey traffic laws and pay attention to the road.
Page 216 IN CASE OF EMERGENCY SOS Call WARNING! WARNING! Press or hold the SOS Call button on the Rearview ALWAYS obey traffic laws and pay attention to the road.  If anyone in the vehicle could be in danger (e.g., fire Mirror.
Page 217 IN CASE OF EMERGENCY SOS Call System Limitations Even if the SOS Call system is fully functional, factors NOTE: beyond FCA US LLC’s control may prevent or stop the SOS Vehicles sold in Mexico DO NOT have SOS Call system ...
Page 218: Jacking And Tire Changing
IN CASE OF EMERGENCY JACKING AND TIRE CHANGING — Block both the front and rear of the wheel diagonally WARNING! opposite of the jacking position. For example, if the IF EQUIPPED driver’s front wheel is being changed, block the  The jack is designed to be used as a tool for changing passenger’s rear wheel.
Page 219: Jack Location/Spare Tire Stowage
IN CASE OF EMERGENCY Open the liftgate. Remove the fastener securing the spare tire, and OCATION PARE TOWAGE remove the spare wheel from the vehicle. The jack Lift the access cover using the load floor handle. If equipped, the jack and tools are located in the rear will be found beneath.
Page 220: Jacking Instructions
IN CASE OF EMERGENCY Before raising the vehicle, use the wheel bolt wrench ACKING NSTRUCTIONS WARNING! to loosen, but not remove, the wheel bolts on the wheel with the flat tire. Turn the wheel bolts counter-  If working on or near a roadway, be extremely careful WARNING! clockwise one turn while the wheel is still on the of motor traffic.
Page 221 IN CASE OF EMERGENCY Jack lifting points can be identified by a triangular Remove the wheel bolts and tire. symbol on the outer rocker panel. Place the jack Remove the alignment pin from the jack assembly underneath the lift area that is closest to the flat tire. and thread the pin into the wheel hub to assist in Turn the jack screw clockwise to firmly engage the mounting the spare tire.
Page 222: Tire Service Kit - If Equipped
IN CASE OF EMERGENCY TIRE SERVICE KIT — IF EQUIPPED Install and lightly tighten the wheel bolts. WARNING! Use this QR code to access your digital experience. To avoid the risk of forcing the vehicle off the jack, do Your vehicle may be equipped with a not tighten the wheel nuts fully until the vehicle has Tire Service Kit.
Page 223 IN CASE OF EMERGENCY  Using The Deflation Button 4 — Pressure Gauge Push the Deflation Button to reduce the air 5 — Deflation Button pressure in the tire if it becomes overin- 6 — Power Switch flated. 7 — Sealant Bottle 8 —...
Page 224 IN CASE OF EMERGENCY Place the transmission in PARK and cycle the ignition WARNING! WARNING! in the OFF position.  Do not attempt to seal a tire on the side of the  Take care not to allow the contents of Tire Service Kit Apply the parking brake.
Page 225 IN CASE OF EMERGENCY 3. After pushing the Power Button, the sealant 2. The pump will start to inject air into the tire Drive Vehicle: (white fluid) will flow from the Sealant Bottle immediately after the Sealant Bottle is empty. Immediately after injecting sealant and through the Sealant Hose and into the tire.
Page 226 IN CASE OF EMERGENCY 5. Uncoil the Hose and screw the fitting at the Have the tire inspected and repaired or replaced at Remove the bottle cover. end of the hose onto the valve stem. the earliest opportunity at an authorized dealer or tire service center.
Page 227: Jump Starting
IN CASE OF EMERGENCY Pull the bottle away from the Compressor. WARNING! Do not attempt jump starting if the battery is frozen. It could rupture or explode and cause personal injury. CAUTION! Do not use a portable battery booster pack or any other booster source with a system voltage greater than 12 Volts or damage to the battery, starter motor, alternator or electrical system may occur.
Page 228: Preparations For Jump Start
IN CASE OF EMERGENCY NOTE: REPARATIONS TART CAUTION! The positive (+) battery post is covered with a protective The battery in your vehicle is located in the engine cap. Lift up on the cap to gain access to the post. Failure to follow these procedures could result in compartment, behind the left headlight assembly.
Page 229: Refueling In Emergency
IN CASE OF EMERGENCY If frequent jump starting is required to start your vehicle, WARNING! WARNING! you should have the battery and charging system inspected at an authorized dealer. Do not connect the jumper cable to the negative (-) post ...
Page 230: If Your Engine Overheats
IN CASE OF EMERGENCY IF YOUR ENGINE OVERHEATS Emergency Gas Can Refueling  If your Air Conditioner (A/C) is on, turn it off. The A/C system adds heat to the engine cooling system and Most gas cans will not open the flapper doors. A funnel is turning the A/C off can help remove this heat.
Page 231: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY Move the gear selector to the NEUTRAL (N) position. NOTE: Push the ESC OFF button (if necessary), to place the Elec- The vehicle may then be started in NEUTRAL. tronic Stability Control (ESC) system in “Partial Off” mode, Reinstall the gear selector boot.
Page 232: Towing A Disabled Vehicle
IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. Towing Condition Wheels OFF The Ground FWD MODELS 4X4 MODELS Flat Tow NONE NOT ALLOWED NOT ALLOWED Rear NOT ALLOWED NOT ALLOWED Wheel Lift Or Dolly Tow...
Page 233: Without The Key Fob
IN CASE OF EMERGENCY (FWD) M — RONT HEEL RIVE ODELS ODELS CAUTION! FCA US LLC requires towing with all four wheels OFF the  Do not use sling-type equipment when towing. ground. Vehicle damage may occur. FCA US LLC recommends towing your vehicle with all four Acceptable methods are to tow the vehicle on a flatbed, or wheels OFF the ground using a flatbed.
Page 234: Emergency Tow Hooks - If Equipped
IN CASE OF EMERGENCY — MERGENCY OOKS CAUTION! QUIPPED Tow hooks are for emergency use only, to rescue a vehicle stranded off road. Do not use tow hooks for tow If your vehicle is equipped with tow hooks, there will be truck hookup or highway towing.
Page 235: Servicing And Maintenance
SERVICING AND MAINTENANCE SCHEDULED SERVICING An authorized dealer will reset the oil change indicator Once A Month Or Before A Long Trip: message after completing the scheduled oil change. If a  Check engine oil level. scheduled oil change is performed by someone other than Your vehicle is equipped with an automatic oil change ...
Page 236: Maintenance Plan
SERVICING AND MAINTENANCE AINTENANCE Refer to the Maintenance Plan for the required maintenance intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Change oil and filter. Rotate the tires at the first sign of irregular wear, even if it occurs before the oil indicator system turns on. Inspect battery and clean and tighten terminals as required.
Page 237 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First) Or Years: Or Kilometers: Inspect the CV/Universal joints. Inspect front accessory drive belt, tensioner, idler pulley, and replace if necessary. Replace engine air cleaner filter. Replace the cabin air filter. To be replaced every 12,000 miles (19,000 km).
Page 238: Engine Compartment
SERVICING AND MAINTENANCE ENGINE COMPARTMENT 2.0L E NGINE 1 — Intercooler Coolant Reservoir Cap 6 — Power Distribution Center (Fuses) 2 — Engine Oil Fill 7 — Engine Oil Dipstick 3 — Engine Air Cleaner Filter 8 — Engine Coolant Pressure Cap 4 —...
Page 239: Checking Oil Level
SERVICING AND MAINTENANCE HECKING EVEL DDING ASHER LUID WARNING! To ensure proper engine lubrication, the engine oil must The fluid reservoir is located in the front of the engine  Battery fluid is a corrosive acid solution and can burn be maintained at the correct level.
Page 240: Pressure Washing
SERVICING AND MAINTENANCE Materials Added To Engine Oil RESSURE ASHING NGINE The manufacturer strongly recommends against the Engine Oil Selection Cleaning the engine compartment with a high pressure addition of any additives (other than leak detection dyes) washer is not recommended. For engine oil selection page 284.
Page 241: Engine Air Cleaner Filter
SERVICING AND MAINTENANCE NGINE LEANER ILTER CAUTION! For the proper maintenance intervals Ú page 234. Do not overtighten the engine air cleaner filter cover lid screws or damage may result. WARNING! The air induction system (air cleaner, hoses, etc.) can ONDITIONER AINTENANCE provide a measure of protection in the case of engine...
Page 242: Body Lubrication
SERVICING AND MAINTENANCE Front Wiper Blade Removal/Installation Particular attention should also be given to hood latching CAUTION! components to ensure proper function. When performing other underhood services, the hood latch, release Do not use chemical flushes in your air conditioning CAUTION! mechanism and safety catch should be cleaned and system as the chemicals can damage your air...
Page 243 SERVICING AND MAINTENANCE To disengage the wiper blade from the wiper arm, flip up the locking tab. Wiper Disengaging Removing Wiper From Wiper Arm 1 — Locking Tab 1 — Wiper 2 — Wiper 2 — Locking Tab Wiper Locking Assembly 3 —...
Page 244 SERVICING AND MAINTENANCE Rear Wiper Blade Removal/Installation Lift the rear wiper arm pivot cap away from the glass to allow the rear wiper blade to be raised off of the glass. NOTE: The rear wiper arm cannot be fully raised off the glass unless the wiper arm pivot cap is unsnapped first.
Page 245: Exhaust System
SERVICING AND MAINTENANCE Insert the wiper blade pivot pin into the opening on Under normal operating conditions, the catalytic converter WARNING! the end of the wiper arm. Grab the bottom end of the will not require maintenance. However, it is important to wiper arm with one hand, and press the wiper blade keep the engine properly tuned to ensure proper catalyst ...
Page 246: Cooling System
SERVICING AND MAINTENANCE Cooling System — Drain, Flush And Refill  Do not use water alone or alcohol-based engine OOLING YSTEM coolant products. Do not use additional rust inhibitors Some vehicles require special tools to add coolant or anti-rust products, as they may not be compatible WARNING! properly.
Page 247 SERVICING AND MAINTENANCE Disposal Of Used Coolant Please review these recommendations for using OAT  Mixing engine coolant types is not recommended and engine coolant that meets the requirements of the can result in cooling system damage. If HOAT and OAT Used ethylene glycol-based coolant (antifreeze) is a manufacturer Material Standard MS.90032.
Page 248: Brake System
SERVICING AND MAINTENANCE With the engine OFF and cold, the level of the engine If an examination of your engine compartment shows no WARNING! coolant should be within the OK range between the evidence of radiator or hose leaks, the vehicle may be ADD and FULL range on the dipstick.
Page 249: Automatic Transmission
SERVICING AND MAINTENANCE Fluid And Filter Changes diagnosing fluid leaks in 8-speed transmissions. WARNING! Avoid using transmission sealers as they may adversely Under normal operating conditions, the fluid installed at affect seals.  To avoid contamination from foreign matter or mois- the factory will provide satisfactory lubrication for the life ture, use only new brake fluid or fluid that has been of the vehicle.
Page 250: Fuses
SERVICING AND MAINTENANCE Fuse Location The fuses protect electrical systems against excessive USES current. The fuses are grouped into controllers located in the General Information When a device does not work, you must check the fuse engine compartment. element inside the blade fuse for a break/melt. Power Distribution Center/Fuses WARNING! Also, please be aware that using power outlets for...
Page 251 SERVICING AND MAINTENANCE Underhood Power Distribution Location Cavity Cartridge Fuse Mini Fuse Description * If Equipped – – Spare – – Spare – – Spare...
Page 252 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description * If Equipped 30 Amp Tan – Rear Defroster (EBL)* – – Spare 40 Amp – TTM* 40 Amp – Smart Electric Oil Pump 20 Amp – SLM Feed LT* 30 Amp –...
Page 253 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description * If Equipped – 20 Amp LT HID Lamp Lumbar Adjust (Driver Seat Only) / Driver & Pass Front Heater Seat SW / Driver & Pass Rear – 20 Amp Heater Seat SW / BVP RLY Coil –...
Page 254 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description * If Equipped – 30 Amp Drivetrain Control Module (DTCM) AWD Power – 30 Amp Front Windshield Defrost* – – Spare – – Spare – 5 Amp Drivetrain Control Module (DTCM) ECU Power –...
Page 255 SERVICING AND MAINTENANCE Interior Fuses The interior fuse panel is located on the driver’s side under the instrument panel lower cover. Cavity Blade Fuse Description *If Equipped 7.5 Amp Brown Occupant Restraint Controller 20 Amp Yellow Window Motor Passenger 20 Amp Yellow Window Motor Driver Intrusion Module/Siren, Radio, UCI/USB Port, VSU, Climate Control, Electronic Steering 20 Amp Yellow...
Page 256 SERVICING AND MAINTENANCE Rear Cargo Fuse/Relay Distribution Unit -If The fuses may be contained in two units. Fuse Holder No. NOTE: 1 is located closest to the rear of the vehicle and Fuse The fuse may be contained in an In-line Fuse holder Equipped Holder No.
Page 257 SERVICING AND MAINTENANCE Rear Cargo Fuse Cavities 2 — Fuse Holder No. 2 1 — Fuse Holder No. 1...
Page 258 SERVICING AND MAINTENANCE Fuse Holder No. 2 Cavity Mini Fuse Description * If Equipped 10 Amp Red TTM IGN Feed * 15 Amp Blue Controller Exterior Lighting Lights (Driver’s Side) * 15 Amp Blue Controller Exterior Lighting Lights (Passenger Side) * 10 Amp Red TTM Jumper Battery Feed * Fuse Holder No.
Page 259: Bulb Replacement
SERVICING AND MAINTENANCE Cavity Maxi Fuse Description * If Equipped 30 Amp Green Power Liftgate* * If Equipped Cavity ATO / Uni-Val Fuse Description 25 Amp Clear HIFI Audio System* EPLACEMENT Replacement Bulbs, Names, And Part Numbers In the instance a bulb needs to be replaced, this section includes bulb description and replacement part numbers. NOTE: See an authorized dealer for LED bulb replacement.
Page 260 SERVICING AND MAINTENANCE Exterior Bulbs Lamps Bulb Number Low Beam Headlamps High Beam Headlamps Front Position/Daytime Running Lights (DRL)/Front Directional - Premium Front Direction Indicator & Position Lamps - Base 7442NA Side Marker Lamp Base:2825 Front Fog Lamps Base: H11LL/ Premium LED Side Indicators (Side View Mirror) Premium Tail Lights: LED Tail/Brake Lights...
Page 261 SERVICING AND MAINTENANCE Replacing Exterior Bulbs Rotate the bulb counterclockwise, and then replace To replace the bulbs proceed as follows: the bulb. Open the liftgate. WARNING! Using a suitable tool remove fasteners covering the screws. Carry out the operation of replacing lamps only with the engine off.
Page 262 SERVICING AND MAINTENANCE Reverse Side of Tail Lamp Body Side Tail Lamp Liftgate 1 — Direction Indicator Bulb / Stop Lamp Bulb 1 — Rear Body Side Tail Lamp 1 — Liftgate Access Covers 2 — Electrical Connector 2 — Ball Stud 3 —...
Page 263 SERVICING AND MAINTENANCE 3rd Stop Lamp Reassemble the bulb housing and courtesy light housing making sure that they are properly locked. The CHMSL is LED. See an authorized dealer for replacement. Install the front courtesy light, making sure that it is properly locked.
Page 264 SERVICING AND MAINTENANCE Dome Light Glove Compartment Dome Light To replace the bulb proceed as follows: To replace the bulbs proceed as follows: Open the glove compartment. Lower the handle in the direction shown; remove the dome light. Place your fingers inside the light assembly, pull the bulb to replace it.
Page 265 SERVICING AND MAINTENANCE Interior Cargo Lights WARNING! To replace the bulbs proceed as follows:  Modifications or repair of the electrical system Using thumb with slight pressure – push bulb holder performed incorrectly and without taking into to the side. account the technical characteristics can cause malfunctions with the risk of fire.
Page 266: Tires
SERVICING AND MAINTENANCE TIRES  European — Metric tire sizing is based on European 1 — US DOT Safety Standards design standards. Tires designed to this standard have Code (TIN) the tire size molded into the sidewall beginning with the AFETY NFORMATION section width.
Page 267 SERVICING AND MAINTENANCE TIRE SIZING CHART EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
Page 268 SERVICING AND MAINTENANCE EXAMPLE: Load Identification: Absence of the following load identification symbols on the sidewall of the tire indicates a Standard Load (SL) tire:  XL = Extra load (or reinforced) tire, or  LL = Light load tire or ...
Page 269 SERVICING AND MAINTENANCE EXAMPLE: 03 = Number representing the week in which the tire was manufactured (two digits)  03 means the 3rd week 01 = Number representing the year in which the tire was manufactured (two digits)  01 means the year 2001 ...
Page 270 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure This placard tells you important information about the: Number of people that can be carried in the vehicle. NOTE: The proper cold tire inflation pressure is listed on the Total weight your vehicle can carry. driver’s side B-pillar or the rear edge of the driver's side Tire size designed for your vehicle.
Page 271 SERVICING AND MAINTENANCE (5) Determine the combined weight of NOTE: Steps For Determining Correct Load Limit— luggage and cargo being loaded on the  If your vehicle will be towing a trailer, load from your (1) Locate the statement “The combined trailer will be transferred to your vehicle.
Page 272 SERVICING AND MAINTENANCE WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them.
Page 273: Tires - General Information
SERVICING AND MAINTENANCE — G Tire Inflation Pressures IRES ENERAL NFORMATION WARNING! The proper cold tire inflation pressure is listed on the Tire Pressure  Unequal tire pressures from one side of the vehicle driver's side B-pillar or rear edge of the driver's side door. to the other can cause the vehicle to drift to the Proper tire inflation pressure is essential to the safe and At least once a month:...
Page 274 SERVICING AND MAINTENANCE Radial Ply Tires Tire pressures change by approximately 1 psi (7 kPa) per Once a Run Flat tire reaches the Run Flat mode it has 12°F (7°C) of air temperature change. Keep this in mind limited driving capabilities and needs to be replaced when checking tire pressure inside a garage, especially in immediately.
Page 275 SERVICING AND MAINTENANCE Tread Wear Indicators Life Of Tire Replacement Tires Tread wear indicators are in the original equipment tires to The service life of a tire is dependent upon varying factors The tires on your new vehicle provide a balance of many help you in determining when your tires should be including, but not limited to: characteristics.
Page 276: Tire Types
SERVICING AND MAINTENANCE YPES WARNING! WARNING! All Season Tires — If Equipped  Do not use a tire, wheel size, load rating, or speed Do not use Summer tires in snow/ice conditions. You rating other than that specified for your vehicle. could lose vehicle control, resulting in severe injury or All Season tires provide traction for all seasons (Spring, Some combinations of unapproved tires and wheels...
Page 277: Spare Tires - If Equipped
SERVICING AND MAINTENANCE — I Compact spare tire descriptions begin with the spare tire needs to be replaced. Since it is not the same as PARE IRES QUIPPED letter “T” or “S” preceding the size designation. your original equipment tire, replace (or repair) the original NOTE: Example: T145/80D18 103M.
Page 278: Tire Rotation Recommendations
SERVICING AND MAINTENANCE OTATION ECOMMENDATIONS READWEAR CAUTION! The Treadwear grade is a comparative The tires on the front and rear of your vehicle operate at Proper operation of four-wheel drive vehicles depends different loads and perform different steering, handling, on tires of equal size, type and circumference on each rating, based on the wear rate of the tire and braking functions.
Page 279: Temperature Grades
SERVICING AND MAINTENANCE government test surfaces of asphalt and passenger vehicle tires must meet NOTE: When the vehicle has not been started or driven for at concrete. A tire marked C may have poor under the Federal Motor Vehicle Safety least 30 days, an “Extended Park Starting Procedure”...
Page 280: Body And Underbody Maintenance
SERVICING AND MAINTENANCE What Causes Corrosion? the water droplets from the brake components. This CAUTION! activity will remove the red rust on the brake rotors and Corrosion is the result of deterioration or removal of paint prevent vehicle vibration when braking. Avoid products or automatic car washes that use acidic and protective coatings from your vehicle.
Page 281: Preserving The Bodywork
SERVICING AND MAINTENANCE INTERIORS Special Care RESERVING ODYWORK  If you drive on salted or dusty roads or if you drive near Washing EATS ABRIC ARTS the ocean, hose off the undercarriage at least once a  Wash your vehicle regularly. Always wash your vehicle month.
Page 282: Plastic And Coated Parts
SERVICING AND MAINTENANCE Seat Belt Maintenance leather upholstery with any liquid. Please do not use CAUTION! polishes, oils, cleaning fluids, solvents, detergents, or Do not bleach, dye or clean the belts with chemical ammonia-based cleaners to clean your leather upholstery. ...
Page 283: Technical Specifications
TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER (VIN) If either of the two hydraulic systems lose normal ORQUE PECIFICATIONS capability, the remaining system will still function with some loss of overall braking effectiveness. This will be The VIN is found on the left front corner of the windshield Lug Nut/Bolt **Lug Nut/Bolt Lug Nut/Bolt...
Page 284: Fuel Requirements
TECHNICAL SPECIFICATIONS FUEL REQUIREMENTS Tighten the lug nuts/bolts in a star pattern until each nut/ The use of reformulated gasoline is recommended. bolt has been tightened twice. Ensure that the socket is Properly blended reformulated gasoline will provide fully engaged on the lug nut/bolt (do not insert it halfway). improved performance and durability of engine and fuel While operating on gasoline with the required octane system components.
Page 285: Usage In Non-Flex Fuel Vehicles
TECHNICAL SPECIFICATIONS E-85 U Indiscriminate use of fuel system cleaning agents should SAGE ETHYLCYCLOPENTADIENYL be avoided. Many of these materials intended for gum and (MMT) I EHICLES ANGANESE RICARBONYL varnish removal may contain active solvents or similar ingredients. These can harm fuel system gasket and ASOLINE Non-Flex Fuel Vehicles (FFV) are compatible with gasoline diaphragm materials.
Page 286: Fluid Capacities
TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) All Engines 13.5 gal 51 L Engine Oil With Filter 2.0L Engine 5 qt 4.7 L Cooling System* 2.0L Engine 9 qt 8.6 L * Includes heater and coolant recovery bottle filled to MAX level. ENGINE FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part...
Page 287: Chassis Fluids And Lubricants
TECHNICAL SPECIFICATIONS CHASSIS FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid, or equivalent. Automatic Transmission Failure to use the correct fluid may affect the function or performance of your transmission.
Page 288: Customer Assistance
CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE IF YOU NEED ASSISTANCE Any communication to FCA US LLC’s customer center should include the following information: FOR YOUR VEHICLE FCA US LLC and its authorized dealers are vitally  Owner's name and address interested in your satisfaction.
Page 289 Vehicle Identification Number service provider to use your vehicle’s temporary spare tire closest authorized Chrysler, Dodge, Jeep®, or Ram dealer. (VIN), and you obtain towing services on your own, you may (if equipped) as recommended in your Owner’s Manual.
Page 290: Fca Us Llc Customer Center
CUSTOMER ASSISTANCE FCA US LLC C FCA US LLC’s Service Contract National Customer Hotline USTOMER ENTER USTOMER SSISTANCE at 1-800-521-9922 (Canadian residents, call EARING PEECH MPAIRED P.O. Box 21–8004 (800) 465-2001 English / (800) 387-9983 French). (TDD/TTY) Auburn Hills, MI 48321–8004 FCA US LLC is not responsible for any service contract you may have purchased from another manufacturer.
Page 291: Warranty Information
CUSTOMER ASSISTANCE WARRANTY INFORMATION REPORTING SAFETY DEFECTS To contact NHTSA, you may call the Vehicle Safety Hotline toll free at See the Warranty Information for the terms and provisions 50 U NITED TATES 1-888-327-4236 (TTY: 1-800-424-9153); of FCA US LLC warranties applicable to this vehicle and , D.C.
Page 292: Publication Order Forms
CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS GENERAL INFORMATION Call Tech Authority toll free at:  1-800-890-4038 (US) To order the following manuals, you may use either the The following regulatory statement applies to all Radio Owner's Manuals, Radio Manuals and Warranty website or the phone numbers listed below.
Page 293 INDEX Alarm Automatic Transmission Limp Home Mode ....23 Arm The System............19 Auxiliary Electrical Outlet (Power Outlet) ...... 53 Active Lane Management System ......128 Disarm The System ........... 20 Axle Fluid............... 285 Adaptive Cruise Control (ACC) ........104 Security Alarm............
Page 294 Climate Control ............... 45 Dipsticks Automatic..............45 Oil (Engine) .............. 237 Camera, Rear ............131 Manual ............... 48 Disabled Vehicle Towing ..........230 Capacities, Fuel............284 Cold Weather Operation..........91 Disposal Caps, Filler Compact Spare Tire ............275 Antifreeze (Engine Coolant)........245 Fuel ................
Page 295 Engine ................236 Flash-To-Pass............38 Gasoline, Clean Air ............282 Air Cleaner............... 239 Flat Tire Changing..........264 Gasoline, Reformulated ..........282 Break-In Recommendations ........92 Flat Tire Stowage ..........264 Gear Ranges ..............97 Checking Oil Level ..........237 Flooded Engine Starting ..........91 Gear Selector Override..........
Page 296 Battery Saver............. 41 Brake Assist Warning..........168 Ignition ................16 Key Fob Brake Warning............81 Switch .................16 Arm The Alarm ............19 Bulb Replacement ..........257 Inside Rearview Mirror.......... 33 Disarm The Alarm............20 Cruise..............87 Instrument Cluster ......66 Programming Additional Key Fobs ......15 Daytime Running..........
Page 297 Low Washer Fluid ............84 Oil, Engine ............238 Malfunction Indicator (Check Engine) ......84 Capacity ..............284 Maintenance ..............59 Oil Pressure..............83 Checking..............237 Maintenance Free Battery ...........237 Oil Temperature ............83 Dipstick ..............237 Maintenance Schedule ..........233 Park ................87 Disposal ..............238 Malfunction Indicator Light (Check Engine)....
Page 298 Power Reminder, Lights On..........38 Seat Belts.............181 Door Locks ..............21 Reminder, Seat Belt .............181 Adjustable Shoulder Belt ........184 Liftgate ...............60 Remote Control Adjustable Upper Shoulder Anchorage....184 Outlet (Auxiliary Electrical Outlet) ......53 Starting System ............17 Adjustable Upper Shoulder Belt Anchorage..184 Sunroof...............57 Remote Keyless Entry ............13 Child Restraints............
Page 299 Security Alarm ............19 Storage ................52 Pressure Monitoring System (TPMS) ....85 Arm The System............19 Storage, Vehicle.............. 51 Quality Grading............276 Disarm The System............20 Stuck, Freeing ...............229 Radial............... 272 Security System...............19 Sun Roof..............57 Replacement ............273 Selection Of Coolant (Antifreeze)........ 284 Sun Visor .................
Page 300 Transaxle Windows................56 Automatic ..............95 Close ................56 Vanity Mirrors..............33 Operation..............95 Down ................56 Vehicle Loading........... 134 Transfer Case Open................56 Vehicle Maintenance............238 Fluid ................. 285 Power ................. 56 Vehicle Modifications/Alterations ........8 Transmission ..............96 Up................56 Vehicle Security Alarm............19 Automatic ............
Page 303 It is always the driver’s responsibility to comply with all local laws. This Owner’s Manual has been prepared to help you get acquainted with your new Jeep brand vehicle and to provide a convenient reference source for ®...
Page 304 ©2022 FCA US LLC. All Rights Reserved. Tous droits réservés. Jeep is a registered trademark of FCA US LLC. Jeep est une Second Edition marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

Jeep Compass 2023 Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jeep Compass 2023

Summary of Contents for Jeep Compass 2023
