Page 10: Introduction
FCA India Customer Relations reserves the right to make changes to the model described for technical and/or commercial reasons. For further information, contact an authorized dealer. When it comes to service, remember that authorized dealers know your Jeep® vehicle best, have factory-trained technicians, genuine Mopar® parts, and care about your satisfaction.
Page 11: Important Notice
INTRODUCTION IMPORTANT NOTICE FCAIO reserves the right to make changes in design and specifications, and/or to make additions to or improvements in its products without imposing any obligations upon itself to install them on products previously manufactured. ALL MATERIAL CONTAINED IN THIS PUBLICATION IS BASED ON THE LATEST INFORMATION AVAILABLE AT THE TIME OF PUBLICATION APPROVAL.
Page 12: Rollover Warning
INTRODUCTION ROLLOVER WARNING Utility vehicles have a significantly higher rollover rate than other types of vehicles. This vehicle has a higher ground clearance and a higher center of gravity than many passenger vehicles. It is capable of performing better in a wide variety of off-road applications.
Page 13: Vehicle Modifications/Alterations
INTRODUCTION VEHICLE MODIFICATIONS/ALTERATIONS Red Warning Lights WARNING! Brake Warning Light ð Any modifications or alterations to this vehicle could seriously affect its page 99 roadworthiness and safety and may lead to a collision resulting in serious injury or death. Battery Charge Warning Light ð...
Page 14 INTRODUCTION Red Warning Lights Red Warning Lights Engine Temperature Warning Light Speed Alert System Warning Light ð ð page 101 page 101 Hood Open Warning Light Speed Alert System Warning Light ð ð page 101 page 101 Liftgate Open Warning Light Transmission Fault Warning Light ð...
Page 15 INTRODUCTION Yellow Warning Lights Yellow Warning Lights Anti-Lock Brake System (ABS) Warning Light Low Fuel Warning Light ð ð page 102 page 103 Electronic Park Brake Warning Light Low Washer Fluid Warning Light ð ð page 102 page 103 Electronic Stability Control (ESC) Active Warning Light Engine Check/Malfunction Indicator (MIL) Warning Light ð...
Page 16 INTRODUCTION Yellow Warning Lights Yellow Indicator Lights Tire Pressure Monitoring System (TPMS) Warning Light Immobilizer Fail / VPS Electrical Alarm Indicator Light ð ð page 104 page 106 Diesel Particulate Filter (DPF) Cleaning In Progress Indicator Light — Towing Hook Breakdown Warning Light Diesel Versions With DPF Only ð...
Page 17 INTRODUCTION Green Indicator Lights Green Indicator Lights Active Speed Limiter SET Indicator Light Stop/Start Active Indicator Light ð ð page 107 page 108 Active Lane Management Indicator Light White Indicator Lights ð page 107 Active Speed Limiter SET Indicator Light Auto HOLD Indicator Light ð...
Page 18 INTRODUCTION Blue Indicator Lights High Beam Indicator Light ð page 109...
Page 19: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE GETTING TO KNOW YOUR VEHICLE KEYS NOTE: ● The key fob’s wireless signal may be blocked if the key fob is located next to a mobile phone, laptop, or other electronic device. This may result in poor performance.
Page 20 GETTING TO KNOW YOUR VEHICLE NOTE: When the doors are unlocked, the turn signals will flash and the illuminated entry system will be activated. In case the ignition switch does not change with the When the doors are locked, the turn signals will flash push of a button, the key fob may have a low or fully and the horn will chirp.
Page 21 GETTING TO KNOW YOUR VEHICLE Keyless Ignition Key Fob: the battery clip, located on the back cover. Avoid touching the new battery with your fingers. Skin Remove the emergency key (2) by sliding the oils may cause battery deterioration. If you touch a emergency key release (1) on the back of the key battery, clean it with rubbing alcohol.
Page 22 GETTING TO KNOW YOUR VEHICLE ● Remove the battery by turning the back cover over Only key fobs that are programmed to the vehicle WARNING! (battery facing downward) and tapping it lightly on electronics can be used to start and operate the vehicle.
Page 23: Sentry Key
GETTING TO KNOW YOUR VEHICLE SENTRY KEY electronics. Should this occur, have the vehicle serviced as soon as possible by an authorized dealer. The Sentry Key Immobilizer system prevents CAUTION! unauthorized vehicle operation by disabling the engine. The system does not need to be armed or activated. The Sentry Key Immobilizer system is not compatible Operation is automatic, regardless of whether the with some aftermarket Remote Start systems.
Page 24 GETTING TO KNOW YOUR VEHICLE ● All the electrical devices are available (e.g. climate WARNING! WARNING! controls, etc.). ● Do not leave children or animals inside parked ● Before exiting a vehicle, always come to START vehicles in hot weather. Interior heat buildup may a complete stop, then shift the automatic cause serious injury or death.
Page 25 GETTING TO KNOW YOUR VEHICLE — I position. In addition to the chime, the “Vehicle On” NTEGRATED ANUAL GNITION message will display in the cluster. ● The engine is stopped. QUIPPED — I ● The key can be removed from the ignition switch. LECTRONIC TEERING HEEL...
Page 26: To Arm The System
GETTING TO KNOW YOUR VEHICLE ● ● Perform one of the following methods to lock the Grab the Passive Entry door handle to unlock the The Vehicle Security Light in the instrument cluster ð vehicle: door page will flash ● NOTE: ●...
Page 27: Rearming Of The System
GETTING TO KNOW YOUR VEHICLE If the Vehicle Security system is armed and the battery ● The manual door locks will not lock or unlock the becomes disconnected, the Vehicle Security system will liftgate. remain armed when the battery is reconnected; the exterior lights will flash, and the horn will sound.
Page 28: Power Door Locks
GETTING TO KNOW YOUR VEHICLE If you push the power door lock switch while the ignition ● If wearing gloves, if it has been raining/snowing, WARNING! is in the ON/RUN position, and any door or the liftgate or there is salt/dirt covering the Passive Entry the ON/RUN position.
Page 29 GETTING TO KNOW YOUR VEHICLE There are three situations that trigger a FOBIK-Safe ● There is a valid Passive Entry key fob outside the search in any Passive Entry vehicle: vehicle and within 5 ft (1.5 m) of either Passive Entry door handle.
Page 30: Automatic Unlock Doors O N Exit
GETTING TO KNOW YOUR VEHICLE To Unlock/Enter The Liftgate The liftgate Passive Entry unlock feature is built into the electronic liftgate release handle. With a valid Passive Entry key fob within 5 ft (1.5 m) of the liftgate, push the electronic liftgate release handle to open.
Page 31: Automatic Door Locks - I Fequipped
GETTING TO KNOW YOUR VEHICLE The arming of the device is indicated by three flashes of outside door handle even if the inside door lock is in the For vehicles equipped with automatic the turn signals. unlocked position. transmissions, any door is opened. For vehicles equipped with manual transmissions, either of the NOTE: front doors are opened.
Page 32: Steering Wheel
GETTING TO KNOW YOUR VEHICLE ● STEERING WHEEL desired. To lock the steering column in position, push For emergency exit with the system engaged, rotate the control handle upward until fully engaged. the door lock button until the lock indicator is hidden (unlocked position), lower the window, and open the WARNING! ELESCOPING...
Page 33: Get Started
Voice Command. You can also say the vehicle “Wake Up” word and state your command. Some examples ● “Cancel” to stop a current voice session. of “Wake Up” words include “Hey Uconnect” or “Hey Jeep®”. ● “Help” to hear a list of suggested Voice Commands. ● ●...
Page 34: Programming The Memory Feature
GETTING TO KNOW YOUR VEHICLE DRIVER MEMORY SETTINGS — IF within five seconds. The instrument cluster display will indicate which memory position is being set. EQUIPPED NOTE: Memory profiles can be set without the vehicle in PARK, This feature allows the driver to store up to two different but the vehicle must be in PARK to recall a memory memory profiles for easy recall through a memory profile.
Page 35: Memory Position Recall
GETTING TO KNOW YOUR VEHICLE A recall can be canceled by pushing any of the ) — I Push and release the lock button on the key fob ANUAL DJUSTMENT RONT EATS memory buttons (S, 1, or 2) during a recall. When a within 10 seconds.
Page 36: Manual Seat Height Adjustment - If Equipped
GETTING TO KNOW YOUR VEHICLE pressure, move forward and rearward on the seat to be sure that the seat adjusters have latched. WARNING! ● Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death.
Page 37: 60/40 Split Folding Rear Seat With Fold-Flat Feature
GETTING TO KNOW YOUR VEHICLE 60/40 Split Folding Rear Seat With Fold- WARNING! Flat Feature Be certain that the seatback is securely locked into To provide additional storage area, each rear seat can position. If the seatback is not securely locked into be folded flat.
Page 38: Reclining The Seatback Forward Or Rearward
GETTING TO KNOW YOUR VEHICLE Tilt Adjustment lumbar support. Pushing upward or downward on the switch will raise and lower the position of the support. The angle of the seat cushion can be adjusted up or down. Pull upward or push downward on the front of the seat switch and the front of the seat cushion will move in the direction of the switch.
Page 39: Head Restraints
GETTING TO KNOW YOUR VEHICLE the control buttons through the climate screen or the 40/20/40 R — I RMREST ESTRAINTS controls screen. QUIPPED Head restraints are designed to reduce the risk of injury ● Press the ventilated seat button once to choose HI. by restricting head movement in the event of a rear The center part of the rear seat can also be used as a ●...
Page 40: Front Head Restraint Adjustment
GETTING TO KNOW YOUR VEHICLE Front Head Restraint Adjustment WARNING! Your vehicle is equipped with front two way driver and head restraints are placed in their proper positions passenger head restraints. in order to minimize the risk of neck injury in the event of a crash.
Page 41: Inside Rear View Mirror
GETTING TO KNOW YOUR VEHICLE NOTE: mirror should be adjusted while set in the day position NOTE: (toward the windshield). The head restraints should only be removed by qualified The Automatic Dimming Mirror feature is disabled when technicians, for service purposes only. If either of the the vehicle is in REVERSE to improve the driver’s rear head restraints require removal, see an authorized view.
Page 42: Vanity Mirrors - I Fequipped
GETTING TO KNOW YOUR VEHICLE Sun Visor Slide-On-Rod Feature — If CAUTION! WARNING! Equipped To avoid damage to the mirror during cleaning, never Vehicles and other objects seen in the passenger spray any cleaning solution directly onto the mirror. The sun visor Slide-On-Rod feature allows for additional side convex mirror will look smaller and farther flexibility in positioning the sun visor to block out the Apply the solution onto a clean cloth and wipe the...
Page 43: Power Adjustment Mirrors
GETTING TO KNOW YOUR VEHICLE or neutral position will return the mirrors to the driving position. If the power mirror control switch is moved again during door mirror folding (from closed to open position and vice versa), the movement direction is reversed. Power mirror position can be saved as part of the Driver ð...
Page 44: Exterior Lights
GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS ● After exiting the vehicle, close the doors then push the lock button on the key fob. ● After exiting the vehicle, close the doors then touch ULTIFUNCTION EVER the lock icon on the Passive Entry door handle. If the exterior mirrors were folded automatically, they will unfold when the ignition is placed in the ON/RUN position.
Page 45: High/Low Beam Switch
GETTING TO KNOW YOUR VEHICLE (DRL ) — I can be turned on or off through Uconnect Settings AYTIME UNNING IGHTS WITCH ð page 153. QUIPPED To activate the high beam headlights, push the ● Broken, muddy, or obstructed headlights and multifunction lever forward (toward the front of the taillights of vehicles in the field of view will cause The Daytime Running Lights will turn on when the...
Page 46: Headlight Time Delay
GETTING TO KNOW YOUR VEHICLE NOTE: no need to turn the headlight switch to off to activate Headlight Delay. The engine must be running before the headlights will come on in the automatic mode. — I IGHTS EMINDER QUIPPED EADLIGHT ELAY If the headlights or parking lights are on after the ignition is in the OFF position, a chime will sound to...
Page 47: Turn Signals
GETTING TO KNOW YOUR VEHICLE NOTE: — I To operate, rotate the control switch until the HANGE SSIST QUIPPED appropriate number, which corresponds to the load To turn on the rear fog lights, the low beam headlights listed on the chart, aligns with the indicator line on the Push the multifunction lever up or down, without or front fog lights must first be active.
Page 48: Interior Courtesy Lights
GETTING TO KNOW YOUR VEHICLE lights were switched on manually or are on because a Rotating the instrument panel dimmer up or down door is open. will adjust the brightness of the instrument panel lights ONLY when the parking lights or headlights are INTERIOR LIGHTS turned on, AND ONLY if the built-in cluster light sensor determines that the ambient light levels are low enough...
Page 49: Illuminated Entry - If Equipped
GETTING TO KNOW YOUR VEHICLE — I wiper interval is 10 seconds. The second intermittent LLUMINATED NTRY QUIPPED CAUTION! wipe interval is based on vehicle speed. Rotate to the third detent for low wiper operation and the fourth The Illuminated Entry feature allows you to activate the Always remove any buildup of snow that prevents the detent for high wiper operation.
Page 50: Rain Sensing Wipers - If Equipped
GETTING TO KNOW YOUR VEHICLE The sensitivity of the system can be adjusted with the ● Transmission In NEUTRAL Position — The Rain WARNING! multifunction lever. Wiper delay position one is the least Sensing system will not operate if the NEUTRAL gear sensitive, and wiper delay position two is the most Sudden loss of visibility through the windshield is selected at speeds of 3 mph (5 km/h) or less...
Page 51: Climate Controls
GETTING TO KNOW YOUR VEHICLE To use the washer, push the lever forward UTOMATIC LIMATE ONTROLS and hold while spray is desired. If the lever ESCRIPTIONS UNCTIONS is pushed while the wiper is in the off position, the wiper will operate for several wipe cycles, then turn off.
Page 52: Recirculation Button
GETTING TO KNOW YOUR VEHICLE NOTE: The Recirculation indicator and the A/C indicator AUTO Button illuminate when the Recirculation button is pressed. The MAX A/C button is only available on the Press and release this button on the Recirculation can be used when outside conditions touchscreen.
Page 53: Sync Button
GETTING TO KNOW YOUR VEHICLE Rear Defrost Button Sync Button CAUTION! Press and release the button on the ● Press the Sync button on the touchscreen Do not use scrapers, sharp instruments, or touchscreen, or push and release the to toggle the Sync feature on/off. The Sync abrasive window cleaners on the interior surface button on the faceplate, to turn on the indicator is illuminated when Sync is on.
Page 54 GETTING TO KNOW YOUR VEHICLE Touchscreen to side to regulate airflow direction. There is a shut-off front defrost mode button, the Climate Control system wheel located below the air vanes to shut off or adjust will return to the previous setting. Use the small blower icon to reduce the blower setting the amount of airflow from these outlets.
Page 55 GETTING TO KNOW YOUR VEHICLE A/C Button odors, dust, or humidity are present. Recirculation can ANUAL LIMATE ONTROLS ESCRIPTIONS be used in all modes except for Defrost. Recirculation Push the A/C button to engage the UNCTIONS may be unavailable if conditions exist that could create Air Conditioning (A/C).
Page 56: Temperature Control
GETTING TO KNOW YOUR VEHICLE automatic climate controls to change to manual mode. Push the blue button on the faceplate CAUTION! The blower speed increases to full (all LEDs on) when or touchscreen or press and slide the MAX Defrost mode is selected, the air conditioning temperature bar towards the blue arrow Failure to follow these cautions can cause damage to compressor is turned on (LED on), both driver and...
Page 57: Automatic Temperature Control (Atc)
GETTING TO KNOW YOUR VEHICLE Panel Mode Defrost Mode (ATC) UTOMATIC EMPERATURE ONTROL Air comes from the outlets in the instrument Air comes from the windshield and side Automatic Operation panel. Each of these outlets can be window demist outlets. When the defrost individually adjusted to direct the flow of button is selected, the blower level may Push the AUTO button on the faceplate, or the...
Page 58: Operating Tips
GETTING TO KNOW YOUR VEHICLE low until the engine warms up. The blower will increase Window Fogging PERATING in speed and transition into Auto mode. Vehicle windows tend to fog on the inside in mild, rainy, Refer to the chart at the end of this section Manual Operation Override and/or humid weather.
Page 59: Operating Tips Chart
GETTING TO KNOW YOUR VEHICLE Operating Tips Chart WEATHER CONTROL SETTINGS WEATHER CONTROL SETTINGS Cold Weather Set the mode control to (Floor Mode). If wind- Hot Weather And Vehicle Set the mode control to shield fogging starts to Interior Is Very Hot (Panel Mode), occur, move the control (A/C) on, and blower on...
Page 60: Console Storage Compartment
GETTING TO KNOW YOUR VEHICLE Rear Door Storage USB C ONTROL WARNING! Storage areas are located in the door trim panels. Plugging in a smartphone device to a USB port may Do not operate this vehicle with a console Console Storage Compartment activate Android Auto™...
Page 61: Power Outlet - I Fequipped
GETTING TO KNOW YOUR VEHICLE an external USB device to the vehicle’s USB Type A or If equipped, there may also be another Type A and Type USB Type C connector port. C USB ports located on the back of the center console. Charge Only USB Port The Second Row USB Type A Charging port can be used Type A And Type C USB Ports...
Page 62 GETTING TO KNOW YOUR VEHICLE how the outlet is powered. Power outlets labeled with WARNING! a key symbol are powered when the ignition is in ● the ON/RUN position, while the outlets labeled with a Close the lid when not in use and while driving the battery symbol are connected directly to the battery and vehicle.
Page 63: Wireless Charging Pad - I Fequipped
GETTING TO KNOW YOUR VEHICLE — I Please see your phone’s Owner’s Manual for further ● The ignition must be in the ON/RUN position in order IRELESS HARGING QUIPPED information. for the phone to charge. The wireless charging pad is equipped with an anti-slip ●...
Page 64: Power Window Controls
GETTING TO KNOW YOUR VEHICLE coils of the system. Movement of the phone during ● With a compatible device placed on the charging charging may prevent or slow the rate of charge. pad, and the ignition is cycled to the OFF position, a reminder message may appear on the instrument ●...
Page 65: Reset Auto -U P
GETTING TO KNOW YOUR VEHICLE To stop the window from going all the way up during the ESET WARNING! Auto-Up operation, push down on the switch briefly. Should the Auto-Up feature stop working, the window Never leave children unattended in a vehicle. Do To close the window part way, lift the window switch may need to be reset.
Page 66: Wind Buffeting
GETTING TO KNOW YOUR VEHICLE POWER SUNROOF WITH POWER SHADE WARNING! — IF EQUIPPED ● Never leave children unattended in a vehicle, or with access to an unlocked vehicle. Never leave the key fob in or near the vehicle, or in a The power sunroof switches are located between the location accessible to children.
Page 67: Opening And Closing The Sunroof
GETTING TO KNOW YOUR VEHICLE and the sunroof will open to the full open position then PENING LOSING UNROOF PENING LOSING OWER automatically stop. UNSHADE The sunroof has two programmed open positions, Pull and hold the switch to completely close the sunroof comfort stop position and full open position.
Page 68: Sunroof Maintenance
GETTING TO KNOW YOUR VEHICLE HOOD Manual Open/Close NOTE: If three consecutive sunroof close attempts result in Push and hold the sunshade switch to open. The Pinch Protect reversals, Pinch Protect will disable and sunshade will open to the half open position and stop PENING the sunroof must be closed in Manual Mode.
Page 69: Closing The Hood
GETTING TO KNOW YOUR VEHICLE ● Move to the outside of the vehicle. The safety latch Button on overhead console (if equipped with power LOSING release lever is located behind the front edge of liftgate) the hood at the center. Reach in at the center WARNING! The overhead console switch and key fob (if equipped) of the hood with a palm facing the ground.
Page 70: Power Liftgate - If Equipped
GETTING TO KNOW YOUR VEHICLE — I OWER IFTGATE QUIPPED WARNING! The power liftgate may be opened by Driving with the liftgate open can allow poisonous pushing the liftgate button on the key fob. exhaust gases into your vehicle. You and your Push the liftgate button on the key fob twice passengers could be injured by these fumes.
Page 71 GETTING TO KNOW YOUR VEHICLE ð be heard (if enabled in the Uconnect Settings page when the liftgate is opening, the liftgate will fully ● If your liftgate is power closing and you put the close. 153). vehicle in gear, the liftgate will continue to power ●...
Page 72: Cargo Area Features
GETTING TO KNOW YOUR VEHICLE ARGO EATURES Removable Rear Shelf — If Equipped CAUTION! ● Do not place heavy objects on the Rear Shelf. Doing so may damage the shelf. ● If any objects are placed on the Rear Shelf, disconnect the eyelets to prevent damage when the liftgate is opened.
Page 73: Cargo Load Floor
GETTING TO KNOW YOUR VEHICLE To change the level of the load floor, pull upward on the Do not raise the floor beyond the point of resistance. In load floor handle, pull the floor outward, and place the vehicles equipped with a power liftgate, forcing the floor back of the floor into the desired position.
Page 74: Cargo Tie-Down Hooks And Loops
GETTING TO KNOW YOUR VEHICLE WARNING! WARNING! weight over or behind the rear axle can cause the ● Cargo tie-downs are not safe anchors for a child vehicle to sway. seat tether strap. In a sudden stop or accident, a ●...
Page 75: Roof Luggage Rack - If Equipped
GETTING TO KNOW YOUR VEHICLE ROOF LUGGAGE RACK — IF EQUIPPED CAUTION! ● To avoid damage to the roof rack and vehicle, do The load carried on the roof, when equipped with a not exceed the maximum roof rack load capacity. luggage rack, must not exceed 150 lb (68 kg), and it Always distribute heavy loads as evenly as possible should be uniformly distributed over the cargo area.
Page 76: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL GETTING TO KNOW YOUR INSTRUMENT PANEL BASE / MIDLINE INSTRUMENT CLUSTER...
Page 77 GETTING TO KNOW YOUR INSTRUMENT PANEL...
Page 78: Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL ● The gauge pointer will likely indicate a higher NSTRUMENT LUSTER ESCRIPTIONS CAUTION! temperature when driving in hot weather or up conditioner turned off until the pointer drops Tachometer mountain grades. It should not be allowed to back into the normal range.
Page 79: Premium Instrument Cluster
GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER...
Page 80 GETTING TO KNOW YOUR INSTRUMENT PANEL Speedometer NSTRUMENT LUSTER ESCRIPTIONS WARNING! ● boiling coolant. It is recommended to call an Indicates vehicle speed. Temperature Gauge authorized dealer for service if your vehicle Fuel Gauge ● The temperature gauge shows engine coolant overheats.
Page 81 GETTING TO KNOW YOUR INSTRUMENT PANEL BASE / MIDLINE INSTRUMENT CLUSTER — DIESEL...
Page 82 GETTING TO KNOW YOUR INSTRUMENT PANEL...
Page 83 GETTING TO KNOW YOUR INSTRUMENT PANEL ● The gauge pointer will likely indicate a higher NSTRUMENT LUSTER ESCRIPTIONS CAUTION! temperature when driving in hot weather or up vehicle. Idle the vehicle with the air Tachometer mountain grades. It should not be allowed to conditioner turned off until the pointer drops exceed the upper limits of the normal operating ●...
Page 84 GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER — DIESEL Premium Diesel Instrument Cluster...
Page 85 GETTING TO KNOW YOUR INSTRUMENT PANEL Tachometer NSTRUMENT LUSTER ESCRIPTIONS WARNING! ● boiling coolant. It is recommended to call an Indicates the engine speed in revolutions per Temperature Gauge authorized dealer for service if your vehicle minute (RPM x 1000). ●...
Page 86: Instrument Cluster Display
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DISPLAY The systems allow the driver to select information by pushing the following buttons mounted on the steering wheel: Your vehicle may be equipped with an instrument cluster display, which offers useful information to the driver.
Page 87 GETTING TO KNOW YOUR INSTRUMENT PANEL screen. Most of the messages of this type are ● ● OK Button Main Screen — The inner ring of the display will then stored (as long as the condition that activated illuminate in gray under normal conditions, yellow for Push the OK button to access/select the information it remains active) and can be reviewed from the non critical warnings, red for critical warnings, and...
Page 88: Oil Change Reset - I Fequipped
GETTING TO KNOW YOUR INSTRUMENT PANEL — I NOTE: HANGE ESET QUIPPED If the indicator message illuminates when you start the Cruise Ready Cruise Set To XXX mph or km/h ● Your vehicle may be equipped with an engine oil vehicle, the oil change indicator system did not reset.
Page 89: Instrument Cluster Display Menu Items
GETTING TO KNOW YOUR INSTRUMENT PANEL (GSI) — I NOTE: HIFT NDICATOR The instrument cluster display menu items display in Door Open Remote Start Canceled Hood QUIPPED the center of the instrument cluster. Menu items may Open vary depending on your vehicle features. The GSI system is enabled on vehicles with a manual Service Air Bag Sys- Remote Start Canceled Door...
Page 90: Vehicle Info (Customer Information Features)
GETTING TO KNOW YOUR INSTRUMENT PANEL the instrument cluster display. Push and release the Vehicle Info (Customer Information ○ Oil Temp OK button to toggle units (mph or km/h) of the Features) ○ Oil Pressure speedometer. Hold the OK button to toggle between ○...
Page 91: Fuel Economy
GETTING TO KNOW YOUR INSTRUMENT PANEL Adding a significant amount of fuel to the vehicle will Tire Pressure — If Equipped Battery Voltage turn off the “LOW” message and a new Range value Displays the actual battery voltage. ● If tire pressure is OK for all tires a vehicle ICON will display.
Page 92: Navigation - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL Screen Setup ● ○ Elapsed Time – Shows the total elapsed time of Sway Bar Status travel since Trip A or Trip B has been reset. ○ Axle Lock Status Push and release the up or down arrow button Hold the OK button to reset feature information.
Page 93: Vehicle Settings - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL Premium Cluster Upper Left or Upper Right Favorites Upper Left or Upper Right Range To Empty Average Econo- Current Econo- Settings None Range To Empty Date Defaults Outside Temp Current Econo- Ignition State Center ●...
Page 94 GETTING TO KNOW YOUR INSTRUMENT PANEL Display remain visualized until the driver turns the Speed will display dashes (- -) until the compass is calibrated. Warning off. If the driver exceeded the set speed, a You may also calibrate the compass by completing one By selecting Display, the following settings can be single chime will sound along with a pop up message or more 360 degree turns (in an area free from large...
Page 95 GETTING TO KNOW YOUR INSTRUMENT PANEL Compass Variance Map...
Page 96: Diesel Particulate Filter (Dpf)
GETTING TO KNOW YOUR INSTRUMENT PANEL — I catalyst to trap and burn Particulate Matter (PM) ● Exhaust Filter Nearing Full Safely Drive at Consistent IESEL ISPLAYS QUIPPED pollutants, with no input or interaction on your part. Speeds to Clear — This message will be displayed When the appropriate conditions exist, the following if the exhaust particulate filter reaches 80% of WARNING!
Page 97: Fuel System Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL damage to the after-treatment system. If this ● Exhaust System Service Required — See Dealer CAUTION! condition is not corrected and a dealer service is — This messages indicates regeneration has been not performed, extensive exhaust after-treatment disabled due to a system malfunction.
Page 98 GETTING TO KNOW YOUR INSTRUMENT PANEL Diesel Emissions Additive AdBlue® (UREA) Warning Messages: MESSAGE DESCRIPTION The first low level warning will be given at around a 1,490 miles (2,400 km) range, and is determined according to the current consumption rate. The UREA Low Level warning light and message will display on the instrument panel. The UREA low level warning light will remains lit until the AdBlue®...
Page 99 GETTING TO KNOW YOUR INSTRUMENT PANEL Diesel Emissions Additive AdBlue® (UREA) Fault Warning Messages: MESSAGE DESCRIPTION This message will display if AdBlue® (UREA) system issue detected is not serviced during the allowed period. Your engine will not Engine Will Not Restart Service AdBlue® restart unless your vehicle is serviced by an authorized dealer.
Page 100: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: ○ overloaded power outlets +12 Volts, 150W, USB Check what may be plugged in to power outlets ● The charging system is independent from load ports) during certain driving conditions (city driving, +12 Volts, 150W, USB ports reduction.
Page 101: Red Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Brake Warning Light NOTE: cases. Always refer to the information in this chapter in the event of a failure indication. All active telltales will The light may flash momentarily during sharp cornering This warning light monitors various brake display first if applicable.
Page 102 GETTING TO KNOW YOUR INSTRUMENT PANEL The light also will turn on when the parking brake is Drowsiness Detected Warning — If Electronic Throttle Control (ETC) Warning applied with the ignition switch in the ON/RUN position. Equipped Light NOTE: Driver drowsiness detection helps to avoid This warning light will illuminate to indicate This light shows only that the parking brake is applied.
Page 103 GETTING TO KNOW YOUR INSTRUMENT PANEL Engine Temperature Warning Light NOTE: Seat Belt Reminder Warning Light If the vehicle is moving, there will also be a single This warning light will illuminate to warn This warning light indicates when the driver chime.
Page 104: Transmission Temperature Warning Light
GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: WARNING! ELLOW ARNING IGHTS The speed alert system warning signal cannot be illuminated you could cause the fluid to boil stopped by any other means other than the driver Anti-Lock Brake System (ABS) Warning over, come in contact with hot engine or exhaust controlling the speed.
Page 105 GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Stability Control (ESC) Active Electronic Stability Control (ESC) OFF Low Washer Fluid Warning Light — If Warning Light — If Equipped Warning Light — If Equipped Equipped This warning light will indicate when the This warning light indicates the ESC is off.
Page 106: Service Stop/Start System Warning Light - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL should be serviced by an authorized dealer as soon as is inserted, or if an average consumption of AdBlue® properly and service is required. Contact an authorized possible if this occurs. (UREA) over 50% is detected. Contact an authorized dealer for service.
Page 107: Yellow Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL If your vehicle has tires of a different size than the will continue upon subsequent vehicle start-ups as Towing Hook Breakdown Warning Light — size indicated on the vehicle placard or tire inflation long as the malfunction exists. When the malfunction If Equipped pressure label, you should determine the proper tire indicator is illuminated, the system may not be able...
Page 108 GETTING TO KNOW YOUR INSTRUMENT PANEL Auto HOLD! Fault Indicator Light — If Diesel Particulate Filter (DPF) Cleaning CAUTION! Equipped In Progress Indicator Light — Diesel Vehicle travel speed should always be adapted to Versions With DPF Only — If Equipped The Auto HOLD! Fault Indicator light will the traffic and weather conditions, and must always illuminate If a fault is detected, it will...
Page 109: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Rear Fog Indicator Light— If Equipped Wait To Start Indicator Light — If green “HOLD” indicator will appear in the Instrument Cluster Display. Equipped This indicator light will illuminate when the Active Lane Management Indicator Light rear fog lights are on.
Page 110: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Turn Signal Indicator Lights Automatic High Beam Indicator Light — If Hill Descent Control (HDC) Indicator Light Equipped — If Equipped When the left or right turn signal is activated, the turn signal indicator will This indicator shows that the automatic high This indicator shows when the HDC feature flash independently and the corresponding...
Page 111: Blue Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL ONBOARD DIAGNOSTIC SYSTEM — OBD II The number “55” is only an example of a speed that CAUTION! can be set. ● Prolonged driving with the MIL on could cause Your vehicle is equipped with a sophisticated Onboard NDICATOR IGHTS further damage to the emission control system.
Page 112 GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING! ● ONLY an authorized service technician should connect equipment to the OBD II connection port in order to read the VIN, diagnose, or service your vehicle. ● If unauthorized equipment is connected to the OBD II connection port, such as a driver-behavior tracking device, it may: ○...
Page 113: Starting And Operating
STARTING AND OPERATING STARTING AND OPERATING STARTING THE ENGINE Place the ignition to the START position and release WARNING! when the engine starts. The starter should not be Keyless Enter ‘n Go™ in the ACC or ON/RUN operated for more than 25 second intervals. Waiting Before starting your vehicle, adjust your seat, adjust position.
Page 114: Tip Start Feature
STARTING AND OPERATING the engine Wait to Start telltale goes off, the engine is WARNING! CAUTION! available to be started. ● Do not leave the key fob in or near the vehicle, Damage to the transmission may occur if the Tip Start Feature or in a location accessible to children, and do following precautions are not observed:...
Page 115: Manual Transmission
STARTING AND OPERATING Keyless Ignition Functions — With Driver’s Foot Off battery blankets will greatly increase starting capability The system takes over and attempts to start the The Brake Pedal/Clutch Pedal (In PARK Or NEUTRAL at low temperatures. Suitable battery blankets are vehicle.
Page 116: Engine Warm Up
STARTING AND OPERATING — W The system will automatically engage the starter XTENDED TARTING FTER TARTING ARMING to crank the engine. If the vehicle fails to start, NGINE NOTE: the starter will disengage automatically after 25 seconds. Extended Park condition occurs when the vehicle has The idle speed is controlled automatically and it will not been started or driven for at least 30 days.
Page 117: Engine Break-In Recommendations
STARTING AND OPERATING will shut down, and the ignition will be placed in the in. Wide-open throttle acceleration in low gear can be You can engage the parking brake in two ways: ON/RUN position. detrimental and should be avoided. ● Manually, by applying the EPB switch.
Page 118 STARTING AND OPERATING even when the ignition switch is OFF but the Brake instrument cluster and the LED indicator on the switch WARNING! Warning Light will not illuminate; however, it can only will extinguish. to be in a vehicle unattended is dangerous for be released when the ignition switch is in the ON/RUN NOTE: a number of reasons.
Page 119: Auto Park Brake
STARTING AND OPERATING flashing. In this event, urgent service of the EPB system ● There is no attempt to press the brake pedal or CAUTION! is required. Do not rely on the parking brake to hold the accelerator pedal. malfunction is indicated. Have the brake system vehicle stationary.
Page 120: Brake Service Mode
STARTING AND OPERATING AUTOMATIC TRANSMISSION vehicle has come to a stop. The vehicle must be ● Forward gear is selected held at a standstill for a predetermined amount of ● Adaptive Cruise Control (ACC) is not engaged time by hydraulic braking. The EPB will then engage You must press and hold the brake pedal while shifting and continue to hold the vehicle at a stop until the ●...
Page 121: Ignition Park Interlock
STARTING AND OPERATING helps the driver avoid inadvertently leaving the vehicle WARNING! WARNING! without placing the transmission in PARK. This system ● ● also locks the transmission in PARK whenever the The vehicle may not engage a newly selected gear Do not leave the key fob in or near the vehicle (or when shifting between PARK, REVERSE, or DRIVE in a location accessible to children), and do not...
Page 122: Transmission - I Fequipped
STARTING AND OPERATING continuously until the selector is returned to the selector into the AutoStick (+/-) position (beside the PEED PEED UTOMATIC proper position, or the requested shift can be DRIVE position) activates AutoStick mode, providing — I RANSMISSION QUIPPED completed.
Page 123: Gear Ranges
STARTING AND OPERATING is in motion. Apply the parking brake when exiting the WARNING! vehicle in this range. fully when exiting the vehicle to guard against When parking on a hill, apply the parking brake before vehicle movement and possible injury or damage. shifting the transmission to PARK, otherwise the load ●...
Page 124 STARTING AND OPERATING NEUTRAL (N) WARNING! CAUTION! Use this range when the vehicle is standing for and remove the key fob. When the ignition is in the ● Before moving the transmission gear selector prolonged periods with the engine running. The engine OFF (key removal) position (or, with push button out of PARK, you must turn the ignition to the may be started in this range.
Page 125 STARTING AND OPERATING and downshifts, and the best fuel economy. The to achieve maximum efficiency. Engagement of the condition would result. It will remain in the selected transmission automatically upshifts through all forward torque converter clutch (and, for the 9-speed, shifts gear until another upshift or downshift is chosen, gears.
Page 126: Transmission Limp Home Mode
STARTING AND OPERATING In the event of a momentary problem, the transmission vehicle. A clutch within the torque converter engages ● The system may revert to automatic shift mode if a can be reset to regain all forward gears by performing automatically at calibrated speeds.
Page 127: Recommended Vehicle Shift Speeds
STARTING AND OPERATING CAUTION! ● Never drive with your foot resting on the clutch pedal, or attempt to hold the vehicle on a hill with the clutch pedal partially engaged, as this will cause abnormal wear on the clutch. ● Do not drive with your hand resting on the gear selector as the force exerted, even if slight, could lead over time to premature wear of the gearbox...
Page 128: Maximum Recommended Downshift Speeds
STARTING AND OPERATING the vehicle speeds listed for acceleration. When heavily OWNSHIFTING CAUTION! loaded or pulling a trailer, these recommended up-shift damage, and/or clutch damage, even if the clutch speeds may not apply. Moving from a high gear down to a lower gear is pedal is pressed.
Page 129: Jeep ® Active Drive
STARTING AND OPERATING FOUR-WHEEL DRIVE OPERATION — IF ARKING Manual Transmission Downshift Speeds in MPH EQUIPPED When parking and leaving the vehicle, proceed as (KM/H) follows: Gear ● ® A Engage a gear (FIRST gear if facing uphill or CTIVE RIVE Selec- 6 to 5...
Page 130: Selec-Terrain - If Equipped
STARTING AND OPERATING Four-Wheel Drive (4x4) NOTE: ● 4WD LOCK ● Both LOCK and LOW LED lights will blink and then ● 4WD LOW — (Trailhawk models only) The four-wheel drive (4WD) is fully automatic in normal become active on the buttons until the shift is driving mode.
Page 131: Power Steering
STARTING AND OPERATING ● SNOW: This mode allows you to have greater stability WARNING! under conditions of bad weather. For use on and off- road on surfaces with poor traction, such as roads Continued operation with reduced assist could pose a covered with snow.
Page 132: Stop/Start System - If Equipped
STARTING AND OPERATING increase in steering effort, especially at low speeds If the vehicle does not start after pressing the clutch, CAUTION! and during parking maneuvers. place the gear selector in NEUTRAL and repeat the procedure. If the problem persists, contact an ●...
Page 133: T O Start The Engine While I N Autostop
STARTING AND OPERATING It may be possible for the vehicle to be driven several Conditions That Force An Application Of The Electric ● Battery temperature is too warm or cold. Park Brake While In Autostop Mode: times without the Stop/Start system going into a STOP/ ●...
Page 134 STARTING AND OPERATING malfunction occurs during an autostop, the vehicle may NOTE: not auto start and will need a key start. The Cruise Control (if equipped) will be deactivated when the Active Speed Limiter is turned to standby To activate/deactivate the system manually, push the mode.
Page 135: Exceeding The Set Speed
STARTING AND OPERATING Activate The Active Speed Limiter (When Speed Setting SET- button is pressed and held down, the speed limit indicator light will flash, and a message will appear in Is Memorized) will change in the increments by 5 mph (5 km/h). the instrument cluster display.
Page 136: To Vary The Speed Setting
STARTING AND OPERATING The Cruise Control buttons are located on the right side To Set A Desired Speed WARNING! of the steering wheel. control and have an accident. Do not use Cruise Turn the Cruise Control on. When the vehicle has Control in heavy traffic or on roads that are winding, reached the desired speed, push and release the SET icy, snow-covered or slippery.
Page 137 STARTING AND OPERATING ● Metric Speed (km/h) Engine overspeed occurs WARNING! ● Pushing the SET (+), or SET (-) button once will result Pushing the on/off button or placing the ignition in the Cruise Control can be dangerous where the system in a 1 km/h speed adjustment.
Page 138: Parksense Sensors
STARTING AND OPERATING Programmable Features section of the Uconnect system If an obstacle is detected in the center rear region, the ENSE ENSORS ð page 153. display will show a single solid arc in the center rear region. As the vehicle moves closer to the obstacle, the The four ParkSense sensors, located in the rear fascia/ The ParkSense Warning screen is located within the display will show the single arc moving closer to the...
Page 139 STARTING AND OPERATING Rear ParkSense Arcs 1 — Continuous Tone/Flashing Arc 4 — Slow Tone/Solid Arc 2 — Fast Tone/Flashing Arc 5 — Slow Tone/Solid Arc 3 — Fast Tone/Flashing Arc 6 — Slow Tone/Solid Arc The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle.
Page 140: Enabling And Disabling Parksense
STARTING AND OPERATING WARNING ALERTS Rear Distance (in- Greater than 79 in- 79-59 inches 59-47 inches 47-39 inches 39-25 inches 25-12 inches (65-30 Less than 12 in- ches/cm) ches (200 cm) (200-150 cm) (150-120 cm) (120-100 cm) (100-65 cm) ches (30 cm) Arcs —...
Page 141: Cleaning The Parksense System
STARTING AND OPERATING chime, once per ignition cycle, and it will display the “PARKSENSE UNAVAILABLE SENSORS BLOCKED” ENSE YSTEM SAGE RECAUTIONS “PARKSENSE UNAVAILABLE WIPE REAR SENSORS” or message to be displayed in the instrument cluster the “PARKSENSE UNAVAILABLE SERVICE REQUIRED” ●...
Page 142 STARTING AND OPERATING Manual Activation Of The Rear View Camera to a hitch/receiver. Different colored zones indicate the CAUTION! distance to the rear of the vehicle. The following table Press the Vehicle button located on the Uconnect above or below the sensors will not be detected shows the approximate distances for each zone: display.
Page 143 STARTING AND OPERATING When Zoom View is selected while the vehicle is in a different view is selected through the touchscreen CAUTION! REVERSE, then shifted to DRIVE or NEUTRAL, the buttons. The Top View of the vehicle will show which camera will display the standard Back Up Camera view.
Page 144 STARTING AND OPERATING When the vehicle is shifted out of REVERSE with Top View ● Open liftgate will cancel rear image while in Top camera delay turned off, the Surround View Camera View. The Top View will show in the Uconnect system with mode is exited and the last known screen appears Rear View and Front View in a split screen display.
Page 145: Zoom View
STARTING AND OPERATING Back Up Camera View NOTE: CAUTION! ● If snow, ice, mud, or any foreign substance builds up Pressing the Back Up Camera button will ● on the camera lenses, clean the lenses, rinse with To avoid vehicle damage, the vehicle must be provide a full screen rear view with Zoom water, and dry with a soft cloth.
Page 146 STARTING AND OPERATING returned to REVERSE gear from DRIVE or NEUTRAL, the Unlock the fuel filler door by pushing the unlock Zoom View selection will automatically resume. button on the key fob or the unlock button on the driver-side door trim panel. Shifting to NEUTRAL from any gear will maintain the selected view (Zoom or Standard) as long as the vehicle Open the fuel filler door by pushing on the rear...
Page 147 STARTING AND OPERATING ADBLUE® (UREA) — IF EQUIPPED ® (UREA) S WARNING! TORAGE ● Never add fuel when the engine is running. This is AdBlue® (UREA) is considered a very stable product The vehicle is equipped with an UREA injection system in violation of most countries regulations and may with a long shelf life.
Page 148 STARTING AND OPERATING ® (UREA) Proceed as follows: DDING ● Insert the AdBlue® (UREA) nozzle in the filler, start Preliminary Conditions refilling and stop refilling at the first shut-off (the AdBlue® (UREA) freezes at temperatures lower than shut-off indicates that the AdBlue® (UREA) tank is 12°F (-11°C).
Page 149: Vehicle Loading
STARTING AND OPERATING VEHICLE LOADING Operations After Refilling the maximum level because if the UREA freezes the system can be damaged. Follow the instructions in Proceed as follows: this section. EIGHTS ABEL ● ● Fit the cap back on the AdBlue® (UREA) filler by If the AdBlue®...
Page 150: Inflation Pressure
STARTING AND OPERATING Payload Rim Size the vehicle should then be determined separately to be sure that the load is properly distributed over the The payload of a vehicle is defined as the allowable This is the rim size that is appropriate for the tire size front and rear axle.
Page 151: Recreational Towing (Behind Motorhome)
STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME) OWING EHICLE EHIND NOTHER EHICLE Towing Condition Wheels Off The Ground Front Wheel Drive (FWD) Four-Wheel Drive (4WD) Flat Tow NONE NOT ALLOWED NOT ALLOWED REAR NOT ALLOWED NOT ALLOWED Dolly Tow FRONT NOT ALLOWED On Trailer BEST METHOD...
Page 152: On-Road Driving Tips
STARTING AND OPERATING Turn the ignition to the ON/RUN position, but do CAUTION! RIVING not start the engine. Towing this vehicle with ANY of its wheels on When To Use 4WD LOW Press and hold the brake pedal. the ground can cause severe transmission and/or Release the Electric Park Brake (EPB).
Page 153: Driving In Snow, Mud And Sand
STARTING AND OPERATING Driving through water more than a few inches/ maintain headway. Over-revving the engine can spin the CAUTION! centimeters deep will require extra caution to ensure wheels and traction will be lost. safety and prevent damage to your vehicle. If you must Do not drive the vehicle in waterlogged, standing, Avoid abrupt downshifts on icy or slippery roads drive through water, try to determine the depth and the...
Page 154: Traction Downhill
STARTING AND OPERATING Avoid repeated heavy braking by downshifting the WARNING! WARNING! transmission whenever possible. If the engine stalls or you lose headway or cannot Abrasive material in any part of the braking After Driving Off-Road make it to the top of a steep hill or grade, never system may cause excessive wear or unpredictable attempt to turn around.
Page 155: Multimedia
MULTIMEDIA MULTIMEDIA UCONNECT SYSTEMS always, if you experience unusual behavior, contact an buttons allow you to access and change Programmable ð authorized dealer immediately or page 310. Features. Many features can vary by vehicle and packages. For detailed information about your Uconnect 5 With The risk of unauthorized and unlawful access to your 8.4-inch Display or Uconnect 5/5 NAV With 10.1- Buttons on the faceplate are located below and/or...
Page 156: Customer Programmable Features
MULTIMEDIA 1 — Uconnect Buttons On The Touchscreen When making a selection, press the button on the USTOMER ROGRAMMABLE EATURES touchscreen to enter the desired menu. Once in the 2 — Uconnect Buttons On The Faceplate desired menu, press and release the preferred setting Press the Vehicle button, then press the Settings option until a check mark appears next to the setting, tab on the top of the touchscreen.
Page 157 MULTIMEDIA Setting Name Description Seat Belt Buzzer This setting will allow you to activate or deactivate the seat belt reminder buzzer. Display When the Display button is pressed on the touchscreen, the system will display the options related to the theme (if equipped), brightness, and color of the touchscreen. The available settings are: NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 158 MULTIMEDIA Setting Name Description Display Brightness With Headlights ON This setting will allow you to set the brightness when the headlights are on. To access this setting, Display Mode must be set to “Manual”. The “+” setting will increase the brightness;...
Page 159 MULTIMEDIA My Profile When the My Profile button is pressed on the touchscreen, the system displays options related to the vehicle’s profiles. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Language This setting will change the language of the Uconnect system. The available languages are UK English, North American English, Australian English, Indian English, French, Spanish, German, Italian, Dutch, Português Brasileiro, Brazilian, Polish, Turkish, and Russian (Cyrillic).
Page 160 MULTIMEDIA Setting Name Description Units This setting will adjust the units in the vehicle. The available options are “Speed” (MPH or km/h), “Distance” (mi or km), “Fuel Consumption” (MPG [US], MPG [UK], L/100 km, or km/L), “Pressure” (psi, kPa, or bar), and “Temperature” (°C or °F) units of measurement.
Page 161 MULTIMEDIA Setting Name Description Show Command List This setting will allow the command list to be shown on or off. App Drawer Favoriting Pop-ups This setting will allow you to favorite app drawer pop-ups with “On” and “Off” options. This setting will allow you to unfavorite app drawer pop-ups with “On” and “Off” App Drawer Unfavoritings Pop-ups options.
Page 162: Safety/Driving Assistance
MULTIMEDIA Setting Name Description Restore Settings to Default This setting will return all the previously changed settings to their factory defaults. More Profile Options This setting will give access to more profile options. Safety/Driving Assistance When the Safety/Driving Assistance button is pressed on the touchscreen, the system displays the options related to the vehicle’s safety settings. These options will differ depending on the features equipped on the vehicle.
Page 163 MULTIMEDIA Setting Name Description Forward Collision Warning Sensitivity — Located In Automatic Emergency Braking Sub- This setting will change the distance at which the Forward Collision Warning alert menu sounds. The “Medium” setting will have the FCW system signal when an object is in view, and the possibility of a collision is detected.
Page 164 MULTIMEDIA Setting Name Description Sync Time With GPS This setting will sync the time to the GPS receiver in the system. The system will control the time via the GPS location. Time Format This setting will allow you to set the time format (AM/PM). Sync Time With GPS must be off for this setting to be available.
Page 165 MULTIMEDIA Phone/Bluetooth® When the Phone/Bluetooth® button is pressed on the touchscreen, the system displays the options related to Bluetooth® connectivity from an external audio device or smartphone. The list of paired audio devices or smartphones can be accessed from this menu. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 166 This setting will allow you to turn the voice recognition “Wake Up” word on or off. The available “Wake Up” words are “Hey Uconnect” and “Hey Jeep®”. This setting will allow you to change the voice options for the radio to “Male” or Voice Options “Female”.
Page 167 MULTIMEDIA Camera When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description ParkView Backup Camera Delay This setting will add a delay to the ParkView Backup Camera when shifting out of REVERSE.
Page 168 MULTIMEDIA Setting Name Description Rain Sensing Auto Wipers This setting will turn the Rain Sensing Auto Wipers on or off. Auto Folding Side Mirrors This setting will automatically fold and unfold the side-view mirrors when the vehicle is turned off, the doors are locked, or the key fob button is pushed. The available options are “On”...
Page 169 MULTIMEDIA Setting Name Description Headlight Sensitivity This setting will allow you to set the sensitivity of the headlights dependent on the amount of visible light. The greater the sensitivity set, the less the external light variation required to turn on the lights (e.g. with a setting on level 3 at sunset, the headlights turn on earlier than in levels 1 and 2).
Page 170: Doors And Locks
MULTIMEDIA Brakes After pressing the Brakes button on the touchscreen, the following setting will be available: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Auto Park Brake This setting will turn the Auto Park Brake on or off. Doors &...
Page 171 MULTIMEDIA Setting Name Description Sound Horn With Lock This setting will sound the horn when the Lock button is pushed on the key fob. The “Off” setting will not sound the horn when the Lock button is pushed. The “1st Press” setting will sound the horn when the Lock button is pushed once.
Page 172 MULTIMEDIA Seats & Comfort When the Seats & Comfort button is pressed on the touchscreen, the system displays the option related to the vehicle’s comfort systems when remote start has been activated or the vehicle has been started. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Auto-On Driver Heated/Ventilated Seat &...
Page 173 MULTIMEDIA Setting Name Description Radio Off Delay This setting will keep the radio running after the engine is turned off. When any door is opened, the electronics will deactivate. The available settings are “0 min” and “20 min”. Radio Off With Door This setting will shut the radio off when the door is opened.
Page 174 MULTIMEDIA Setting Name Description Equalizer This setting will adjust the “Bass”, “Mid”, and “Treble” ranges of the audio. Speed Adjusted Volume This setting will adjust audio volume as speeds increase. At a higher setting, the volume will increase more as the vehicle speeds up. The available settings are “Off”, “1”, “2”, and “3”.
Page 175 MULTIMEDIA Notifications When the Notifications button is pressed on the touchscreen, the system displays the options related to Notifications for the system. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description App Drawer Favoriting Pop-ups This setting turns the “App Favorited” pop-up on or off. App Drawer Unfavoriting Pop-ups This setting turns the “App Unfavorited”...
Page 176: Radio Setup
MULTIMEDIA Radio Setup When the Radio Setup button is pressed on the touchscreen, the system will provide selectable options related to the regional setup of the radio. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Regional This setting will automatically switch between network stations depending on the region.
Page 177: Steering Wheel Audio Controls
MULTIMEDIA Setting Name Description Restore Settings This setting will return all the previously changed settings to their factory defaults. Reset App Drawer This setting will reset the app drawer to its factory default layout. Clear Personal Data This setting will display a pop-up that gives you the option to clear all personal data from the system, including Bluetooth®...
Page 178: Media Mode
176 MULTIMEDIA RADIO OPERATION AND MOBILE PHONES The following describes the left-hand control operation in each mode. Under certain conditions, the mobile phone being on in ADIO PERATION your vehicle can cause erratic or noisy performance from your radio. This condition may be lessened or Pushing the top of the switch will seek up for the next eliminated by repositioning the mobile phone within the listenable station, and pushing the bottom of the switch...
Page 179: Safety
SAFETY SAFETY SAFETY FEATURES ● Brake pedal pulsations WARNING! ● A slight drop of the brake pedal at the end of the ● The ABS cannot prevent the natural laws of (ABS) stop RAKE YSTEM physics from acting on the vehicle, nor can it increase braking or steering efficiency beyond that The ABS is designed to function with the Original The ABS provides increased vehicle stability and...
Page 180 SAFETY brake system is not functioning and that service is To Activate/Deactivate WARNING! required. However, the conventional brake system will DDD can be activated and deactivated through the continue to operate normally if the ABS Warning Light is ● Before exiting a vehicle, always come to Uconnect system by selecting the following in order: a complete stop, then shift the automatic transmission into PARK and apply the parking...
Page 181: Brake Assist System (Bas) - If Equipped
SAFETY If the driver does not acknowledge the warning provided (EBC) continuous braking pressure during the stopping LECTRONIC RAKE ONTROL by the system, the message will remain on the screen sequence (do not “pump” the brakes). Do not reduce YSTEM for one minute.
Page 182 SAFETY come on when the ignition is placed in the ON/RUN overslip of the rear wheels to avoid vehicle instability, WARNING! mode, have the light repaired as soon as possible. and to prevent the rear axle from entering ABS before in a reckless or dangerous manner which could the front axle.
Page 183: Esc Operating Modes
SAFETY counteract the these conditions. Engine power may WARNING! WARNING! also be reduced to help the vehicle maintain the effectiveness of the ESC system can increase the desired path. ● Electronic Stability Control (ESC) cannot prevent risk of loss of vehicle control, vehicle rollover, the natural laws of physics from acting on the ●...
Page 184: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
SAFETY momentarily push the ESC OFF button and the ESC OFF Full Off (Four-Wheel Drive Models Only) NOTE: Indicator Light will turn off. The “ESC Off” message will display and an audible This mode is intended for off-highway or off-road chime will sound when the gear selector is placed into NOTE: use when ESC stability features could inhibit vehicle...
Page 185: Hill Descent Control (Hdc) - If Equipped
SAFETY the vehicle has been driven several miles (kilometers) when ESC becomes inactive following the maneuver ● The Electric Park Brake (EPB) is released. at speeds greater than 30 mph (48 km/h), see an that caused the ESC activation. ● The driver’s door is closed.
Page 186: Hill Start Assist (Hsa)
SAFETY Disabling HDC ● The gear selection must match vehicle uphill WARNING! direction (i.e., vehicle facing uphill is in forward gear; HDC will be deactivated and disabled if any of the HDC is only intended to assist the driver in controlling vehicle backing uphill is in REVERSE gear).
Page 187: Auxiliary Driving Systems
SAFETY Disabling And Enabling HSA and/or reduce vehicle power to provide enhanced tire inflation pressure must not exceed the maximum acceleration and stability. A feature of the TCS, Brake inflation pressure molded into the tire sidewall. The tire This feature can be turned on or turned off. To change Limited Differential (BLD) functions similarly to a limited pressure will also increase as the vehicle is driven.
Page 188: Premium System
SAFETY The system will automatically update and the TPMS ● Driving on a significantly underinflated tire causes CAUTION! Warning Light will turn off once the system receives the tire to overheat and can lead to tire failure. same size, type, and/or style. The TPMS sensor the updated tire pressures.
Page 189: Service Tpms Warning
SAFETY The TPMS consists of the following components: the recommended cold placard pressure in order to turn the Tire Pressure Monitoring System Warning Light ● Receiver module off. ● Four Tire Pressure Monitoring System sensors The vehicle may need to be driven for up to 10 minutes ●...
Page 190: Tpms Deactivation - If Equipped
SAFETY the instrument cluster will display a “SERVICE when installing winter wheel and tire assemblies on ● Installing some form of aftermarket window tinting TPM SYSTEM” message for five seconds and then your vehicle. that affects radio wave signals. display dashes (- -) in place of the pressure value. To deactivate the TPMS, first replace all four wheel ●...
Page 191: Occupant Restraint Systems Features
SAFETY ð OCCUPANT RESTRAINT SYSTEMS possible and use the proper child restraint page 213. Some of the most important safety features in your Never allow children to slide the shoulder belt vehicle are the restraint systems: behind them or under their arm. You should read the instructions provided with your CCUPANT ESTRAINT...
Page 192: Enhanced Seat Belt Use Reminder System (Beltalert )
SAFETY This can happen far away from home or on your own Seat Belt Reminder Light will turn solid red and remain WARNING! street. red until the seat belt is buckled. The respective Seat Belt Reminder Light will turn solid green once the ●...
Page 193: Lap/Shoulder Belts
SAFETY Change Of Status solid green to blinking red. This will alert the driver to WARNING! stop the vehicle until the rear passenger buckles the If the driver or outboard front seat passenger unbuckles seat belt again. After the driver and outboard front seat ●...
Page 194 SAFETY WARNING! WARNING! WARNING! seating position to minimize the risk of severe seat belt is flat against your body, without twists. wear your shoulder belt. The lap and shoulder belt injury or death in the event of a crash. If you can’t straighten a seat belt in your vehicle, are meant to be used together.
Page 195 SAFETY The seat belt latch plate is above the back of the front seat, and next to your arm in the rear seat (for vehicles equipped with a rear seat). Grab the latch plate and pull out the seat belt. Slide the latch plate up the webbing as far as necessary to allow the seat belt to go around your lap.
Page 196: Lap/Shoulder Belt Untwisting Procedure
SAFETY Lap/Shoulder Belt Untwisting Procedure WARNING! Use the following procedure to untwist a twisted lap/ ● Wearing your seat belt incorrectly could make your shoulder belt. injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of the Position the latch plate as close as possible to the seat belt.
Page 197 SAFETY Grab the mini-latch plate and pull the seat belt over the seat. Inserting Mini-Latch Plate Into Mini-Buckle Inserting Latch Plate Into Buckle Sit back in seat. Slide the regular latch plate up the webbing as far as necessary to allow the seat belt Pulling Out The Latch Plate to go around your lap.
Page 198: Seat Belts And Pregnant Women
SAFETY the shoulder belt. To loosen the lap belt if it is too Seat Belts And Pregnant Women WARNING! tight, pull on the lap belt. A snug seat belt reduces the risk of sliding under the seat belt in a collision. ●...
Page 199: Seat Belt Pretensioner
SAFETY Seat Belt Pretensioner (SRS) ● Seat Belt Pretensioners UPPLEMENTAL ESTRAINT YSTEMS ● Seat Track Position Sensors The front outboard seat belt system is equipped with Some of the safety features described in this section pretensioning devices that are designed to remove may be standard equipment on some models, or may Air Bag Warning Light slack from the seat belt in the event of a collision.
Page 200: Redundant Air Bag Warning Light
SAFETY malfunction. While the air bag system is designed to the glove compartment. The words “SRS AIRBAG” or WARNING! be maintenance free, if any of the following occurs, “AIRBAG” are embossed on the air bag covers. on, stays on after you start the vehicle, or if it comes have an authorized dealer service the air bag system on as you drive, have an authorized dealer service immediately.
Page 201: Driver And Passenger Front Air Bag Features
SAFETY Driver And Passenger Front Air Bag WARNING! WARNING! Features arms to reach the steering wheel or instrument are designed to open only when the air bags are panel. inflating. The driver and passenger front air bag system is ● ●...
Page 202 SAFETY are not good indicators of whether or not an air bag According to crash statistics, children are safer when information on how to access the instrument cluster ð should have deployed. properly restrained in the rear seats rather than in the display, see page ð...
Page 203 SAFETY of the Passenger Advanced Front Air Bag. If any of the Advanced Front Air Bag is deactivated. The Passenger WARNING! following occurs, have an authorized dealer service the Air Bag DISABLE (OFF) Indicator Light on the center ● air bag system immediately:. stack will illuminate to show that the Passenger It is advisable to always carry children in a child...
Page 204 SAFETY DISABLING (OFF) the Passenger Advanced Front Air Bag To DISABLE (OFF) the Passenger Advanced Front Air Bag, access the instrument cluster display main menu located in the instrument cluster by pushing the Up or Down arrow button located on the steering wheel, then complete the following actions: Action Information Scroll Up or Down to “Vehicle Set-Up”...
Page 205 SAFETY Action Information A single chime will sound with the Passenger AIRBAG OFF indicator light illuminated for 4 to 5 seconds confirming the disabling of the Passenger Advanced Front Air Bag. The Passenger AIRBAG OFF indicator light will remain continuously illuminated in the center stack telling the driver and front passenger that the Passenger Advanced Front Air Bag is DISABLED (OFF).
Page 206 SAFETY Action Information Press the “OK” button on the steering wheel to select “Passenger AIRBAG” NOTE: Scroll Up or Down to Passenger AIRBAG ON “ ON” If the Passenger Advanced Front Air Bag was previously DISABLED (OFF) it will default to OFF and user will have to scroll down to select ON.
Page 207 SAFETY Knee Impact Bolster WARNING! The knee impact bolsters help protect the knees of ● NEVER use a rearward facing child restraint on a the driver and front passenger, and position the front seat protected by an ACTIVE AIRBAG in front of it, occupants for improved interaction with the front air DEATH or SERIOUS INJURY to the CHILD can occur.
Page 208 SAFETY The SABICs (if equipped with SABICs) may help reduce WARNING! the risk of partial or complete ejection of vehicle occupants through side windows in certain side impact Do not use accessory seat covers or place objects events. between you and the Side Air Bags; the performance could be adversely affected and/or objects could be WARNING! pushed into you, causing serious injury.
Page 209 SAFETY response to impact events. The system is calibrated WARNING! WARNING! to deploy the Side Air Bags on the impact side of inflate, even if they are in an infant or child deploy at all. Always wear your seat belt even the vehicle during impacts that require Side Air Bag restraint.
Page 210: Airbag System Components
SAFETY The SABICs may help reduce the risk of partial or If A Deployment Occurs particles settle on your clothing, follow the garment complete ejection of vehicle occupants through side manufacturer’s instructions for cleaning. The front air bags are designed to deflate immediately windows in certain rollover or side impact events.
Page 211: Enhanced Accident Response System Reset Procedure
SAFETY following the procedure described below. If you have ● ○ Cut off fuel to the engine (if equipped). Electric Motor (if equipped) any doubt, contact an authorized dealer. ● ○ Cut off battery power to the electric motor (if Electric power steering Enhanced Accident Response System equipped).
Page 212 SAFETY Customer Action Customer Will See NOTE: Each step MUST BE held for at least two seconds. 1. Turn ignition STOP/OFF/LOCK. (Turn Signal Switch Must be placed in Neutral State). 2. Turn ignition MAR/ON/RUN. Right turn light BLINKS. Left turn light is OFF. 3.
Page 213 SAFETY Customer Action Customer Will See NOTE: Each step MUST BE held for at least two seconds. 7. Turn right turn signal switch ON. Right turn light is ON SOLID. Left turn light BLINKS. 8. Place turn signal in neutral state. Right turn light is OFF.
Page 214: Maintaining Your Air Bag System
SAFETY If a reset procedure step is not completed within 60 ● How far (if at all) the driver was depressing the WARNING! seconds, then the turn signal lights will blink and the accelerator and/or brake pedal; and, air bag system service. If your seat, including your reset procedure must be performed again in order to be ●...
Page 215 SAFETY — C 2003/20/EC requires proper use of restraints in all EC HILD ESTRAINTS ARRYING HILDREN WARNING! countries. ● AFELY A deploying passenger front air bag can cause Children less than 1.5 m tall and 12 years or younger death or serious injury to a child 12 years or should ride properly buckled up in a rear seat, if younger, including a child in a rear-facing child available.
Page 216 SAFETY In Europe, children restraint systems are defined by regulation ECE-R44, which divides them into five weight groups: Group Weight Groups Size class / Fixing Group 0 Indicatively up to 9 months up to 10 kg ISO/L1 ISO/L2 ISO/R1 Group 0+ Indicatively up to 2 years up to 13 kg ISO/R1...
Page 217 These devices are passenger seat must also be positioned backward recommended having been speciﬁcally designed for as far as possible to avoid the child restraint system Jeep® vehicles. from coming into contact with the dashboard. WARNING! “Universal” Child Restraint Systems Fig.
Page 218 SAFETY in fig. B. This type of child restraint is for older children Group 3 WARNING! who are too big for a Group 0 or 0+ child restraint. ● Never place a rear-facing child restraint in front of Group 2 an active air bag.
Page 219 SAFETY Group 2 or Group 3 child restraint to improve the fit of WARNING! WARNING! the seat belt: ● Never allow a child to put the shoulder belt under an Improper installation can lead to failure of an Can the child sit all the way back against the back arm or behind their back.
Page 220: Locating The Isofix Anchorages
SAFETY two lower anchorages located at the back of the seat cushion where it meets the seatback and a top tether anchorage located behind the seating position. An example of a Universal ISOFIX child restraint system for weight group 1 is shown in fig. E. ISOFIX child restraints are also available in the other weight groups.
Page 221: Installing Child Restraints Using The Top Tether Anchorage
SAFETY fit. If the rear seat can be moved forward and WARNING! WARNING! rearward in the vehicle, you may wish to move it ● Follow the child restraint manufacturer’s directions to its rear-most position to make room for the child Never use the same lower anchorage to attach ð...
Page 222 SAFETY better safety conditions to carry children on board a Route the tether strap to provide the most direct WARNING! vehicle: path for the strap between the anchor and the child seat. If your vehicle is equipped with ● An incorrectly anchored tether strap could lead ●...
Page 223 SAFETY NOTE: Child Restraint Usage By Seating Position The vehicle seats, i-Size type-approved, are marked This table gives technical information specifically by the symbol shown in Figure XX. intended for child restraint system manufacturer and, as such, translation into national language is not required: Figure XX Seating Positions...
Page 224 SAFETY Seating Positions Seat Position Number Seat Suitable For Auxiliary Child Restraint Systems (B2/B3) *Suitable position for a child seat if the passenger airbag is disabled. When using a suitable seating position, adjust the seat to the rearmost position. When using a larger child seat, reposition the forward seat. SEATING POSITIONS: 4.
Page 225 SAFETY WARNING!
Page 226: Safety Tips
SAFETY SAFETY TIPS injured, or injure a passenger during panic braking or in AFETY HECKS HOULD NSIDE a collision. EHICLE Pets should be restrained in the rear seat (if equipped) RANSPORTING ASSENGERS in pet harnesses or pet carriers that are secured by Seat Belts seat belts.
Page 227: Floor Mat Safety Information
SAFETY Defroster WARNING! WARNING! Check operation by selecting the defrost mode and ● floor mat from the vehicle and place the floor mat ALWAYS securely attach your floor mat place the blower control on high speed. You should in your trunk. using the floor mat fasteners.
Page 228: Exhaust Gas
SAFETY suspected, the cause should be located and corrected The best protection against carbon monoxide entry ERIODIC AFETY HECKS HOULD immediately. into the vehicle body is a properly maintained engine UTSIDE EHICLE exhaust system. XHAUST Whenever a change is noticed in the sound of the Tires exhaust system, when exhaust fumes can be detected WARNING!
Page 229 SAFETY WARNING! the engine running for an extended period. If the vehicle is stopped in an open area with the engine running for more than a short period, adjust the ventilation system to force fresh, outside air into the vehicle. ●...
Page 230: In Case Of Emergency
IN CASE OF EMERGENCY IN CASE OF EMERGENCY HAZARD WARNING FLASHERS turn signals will flash on and off to warn oncoming HELP MIRROR — IF EQUIPPED traffic of an emergency. Push the button a second time to turn off the Hazard Warning Flashers. The Hazard Warning Flashers button is located in the lower center area of the instrument panel.
Page 231 IN CASE OF EMERGENCY The HELP function is activated: Manual HELP WARNING! ● Automatically in the event of a major collision Press or hold the HELP button on the rearview ALWAYS obey traffic laws and pay attention to recorded by the device aboard the vehicle. mirror.
Page 232 IN CASE OF EMERGENCY JACKING AND TIRE CHANGING — IF The HELP operator may attempt to contact WARNING! appropriate emergency responders and provide and GPS signal reception is required for the SOS EQUIPPED them with important vehicle information and GPS Call system to function properly.
Page 233: Preparations For Jacking
IN CASE OF EMERGENCY REPARATIONS ACKING Park the vehicle on a firm level surface as far from the edge of the roadway as possible. Place a warning triangle behind the rear of the vehicle as necessary. Avoid icy or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic.
Page 234 IN CASE OF EMERGENCY Locate the load floor handle, and pull up to remove. Spare Tire Fastener Jack And Tools Remove the alignment pin from the middle, rotate 1 — Wheel Bolt Wrench the jack counterclockwise, and lift it from the foam Load Floor Handle 2 —...
Page 235: Jacking Instructions
IN CASE OF EMERGENCY ACKING NSTRUCTIONS WARNING! ● If working on or near a roadway, be extremely WARNING! careful of motor traffic. ● Carefully follow these tire changing warnings to help To assure that spare tires, flat or inflated, are prevent personal injury or damage to your vehicle: securely stowed, spares must be stowed with the valve stem facing the ground.
Page 236 IN CASE OF EMERGENCY Before raising the vehicle, use the wheel bolt Place the jack underneath the lift area that wrench to loosen, but not remove, the wheel bolts is closest to the flat tire. Turn the jack screw on the wheel with the flat tire. Turn the wheel bolts clockwise to firmly engage the jack saddle with the counterclockwise one turn while the wheel is still lift area of the sill flange, centering the jack saddle...
Page 237 IN CASE OF EMERGENCY CAUTION! WARNING! Be sure to mount the spare tire with the valve To avoid the risk of forcing the vehicle off the stem facing outward. The vehicle could be jack, do not tighten the wheel nuts fully until the damaged if the spare tire is mounted incorrectly.
Page 238 IN CASE OF EMERGENCY 12. Lower the jack until it is free. Remove the wheel Manufacturer Detail WARNING! blocks. Reassemble the lug wrench to the jack Moonlight Tools Pvt. Ltd. assembly and stow it in the spare tire area. Secure A loose tire or jack thrown forward in a collision the assembly using the means provided.
Page 239 IN CASE OF EMERGENCY German Translation...
Page 240: Jack Usage Precautions
IN CASE OF EMERGENCY Maintenance SAGE RECAUTIONS CAUTION! ● Make sure grime does not build up on the crank the jack for loads higher than that specified on the WARNING! screw. label. Never start the engine with vehicle raised. If the vehicle is raised more than necessary, everything can ●...
Page 241: Tire Service Kit - If Equipped
IN CASE OF EMERGENCY TIRE SERVICE KIT — IF EQUIPPED Tire Service Kit And Components And Operation Your vehicle may be equipped with a Tire Service Kit. Small punctures up to 1/4 inch (6 mm) in the tire tread can be sealed with Tire Service Kit. Foreign objects (e.g., screws or nails) should not be removed from the tire.
Page 242 IN CASE OF EMERGENCY ● ● The Sealant Bottle is a one tire application use and WARNING! Selecting Air Mode needs to be replaced after each use. Always replace Push in the Mode Select Knob and turn these components immediately at your original ●...
Page 243 IN CASE OF EMERGENCY NOTE: Verify that the valve stem (on the wheel with the WARNING! Do not remove foreign objects (e.g., screws or nails) deflated tire) is in a position that is near to the these warnings can result in injuries that are from the tire.
Page 244 IN CASE OF EMERGENCY Mode position and not Air Mode. Push the Power opening. Check the tire pressure by looking at the Drive Vehicle: Button to turn the Tire Service Kit on. Pressure Gauge. Immediately after injecting sealant and inflating the tire, drive the vehicle 5 miles Connect the Power Plug to a different 12 Volt If the tire does not inflate to at least 26 psi (1.8 Bar) power outlet in your vehicle or another vehicle, if...
Page 245 IN CASE OF EMERGENCY to the recommended inflation pressure before Uncoil the power plug and insert the continuing. plug into the vehicle's 12 Volt power outlet. Disconnect the Tire Service Kit from the valve stem, reinstall the cap on the valve stem and Uncoil the Hose and screw the fitting unplug from 12 Volt outlet.
Page 246: Jump Starting
IN CASE OF EMERGENCY NOTE: Rotate the bottle up beyond vertical to release. WARNING! ● For sealant bottle installation, follow these steps in reverse order. As required by current regulations, the information ● on chemical substances for the protection of human The Sealant Bottle is a one tire application use and health and the environment and on the safe use needs to be replaced after each use.
Page 247: Preparations For Jump-Start
IN CASE OF EMERGENCY improperly, so please follow the procedures in this WARNING! section carefully. Do not allow vehicles to touch each other as NOTE: this could establish a ground connection and When using a portable battery booster pack, follow the personal injury could result.
Page 248: Jump-Starting Procedure
IN CASE OF EMERGENCY bracket or large bolt. The ground must be away Disconnecting The Jumper Cables TARTING ROCEDURE from the battery and the fuel injection system. Disconnect the negative (-) end of the jumper cable WARNING! from the engine ground of the vehicle with the discharged battery.
Page 249 IN CASE OF EMERGENCY REFUELING IN EMERGENCY — IF EQUIPPED The vehicle is equipped with an emergency refueling funnel for a Cap-Less Fuel System. The fuel funnel can be found in the rear cargo area under the load floor. If refueling is necessary, while using an approved gas can, insert the refueling funnel into the filler neck opening.
Page 250: If Your Engine Overheats
IN CASE OF EMERGENCY IF YOUR ENGINE OVERHEATS ● Ensure funnel is inserted fully to hold flapper doors If your Air Conditioner (A/C) is on, turn it off. The A/C open. system adds heat to the engine cooling system and turning the A/C off can help remove this heat.
Page 251: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY SECOND gear and REVERSE (for manual transmission) Grab the boot material rearward of the gear while gently pressing the accelerator. selector and pull up to carefully separate the gear selector bezel and boot assembly from the center NOTE: console.
Page 252: Towing A Disabled Vehicle
IN CASE OF EMERGENCY ð mode, before rocking the vehicle page 180. Once NOTE: ● You must ensure that the Auto Park Brake feature the vehicle has been freed, push the ESC OFF button Towing Wheels FWD MOD- 4X4 MOD- is disabled before towing this vehicle to avoid again to restore “ESC On”...
Page 253: Without The Key Fob
IN CASE OF EMERGENCY If flatbed equipment is not available, this vehicle must CAUTION! CAUTION! be towed with the front wheels OFF the ground (using a towing dolly, or wheel lift equipment with the front ● ● Do not use sling-type equipment when towing. Front or rear wheel lifts must not be used (if wheels raised).
Page 254 IN CASE OF EMERGENCY CAUTION! WARNING! ð ● ● Do not use the tow eye to free a stuck vehicle Do not use a tow strap with a tow eye. Tow straps may break or become disengaged, causing serious page 249.
Page 255 IN CASE OF EMERGENCY The tow eye must be securely seated to the attaching bracket through the lower front fascia/bumper. If the tow eye is not securely seated to the attaching bracket, the vehicle should not be moved. Front Tow Eye Installed Rear Tow Eye Access Door Rear Tow Eye The tow eye must be securely seated to the attaching...
Page 256: Enhanced Accident Response System
IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM Further turning counterclockwise will allow removal of the bottom to access the batteries. (EARS) Turning the bottom fully clockwise will turn off the flashing. This vehicle is equipped with an Enhanced Accident The light has a built in magnet on the bottom for Response System.
Page 257: Servicing And Maintenance
SERVICING AND MAINTENANCE SERVICING AND MAINTENANCE SCHEDULED SERVICING Refer to the “Service And Warranty Handbook” for scheduled servicing.
Page 258: Engine Compartment
SERVICING AND MAINTENANCE ENGINE COMPARTMENT 2.0L D IESEL NGINE 1 — Brake Fluid Reservoir Cap 5 — Engine Air Cleaner, Filter 2 — Engine Oil Fill 6 — Engine Oil Dipstick 3 — Battery 7 — Engine Coolant Pressure Cap 4 —...
Page 259: Checking Oil Level
SERVICING AND MAINTENANCE HECKING EVEL CAUTION! WARNING! To ensure proper engine lubrication, the engine oil must Overfilling or underfilling the crankcase will cause Commercially available windshield washer solvents be maintained at the correct level. Check the oil level at aeration or loss of oil pressure. This could damage are flammable.
Page 260: Pressure Washing
SERVICING AND MAINTENANCE information for your vehicle. Refer to these Service WARNING! CAUTION! Manuals before attempting any procedure yourself. ● positive (+) and negative (-) and are identified on Batteries contain substances which are very NOTE: the battery case. Cable clamps should be tight on dangerous for the environment.
Page 261: Engine Air Cleaner/Filter
SERVICING AND MAINTENANCE Engine Oil Filter Selection WARNING! WARNING! A full-flow type disposable oil filter should be used for cleaner, hoses, etc.) removed. Failure to do so can costly repairs. Refer to Warranty Information Book, replacement. The quality of replacement filters varies result in serious personal injury.
Page 262: Refrigerant Recovery And Recycling R-1234Yf - If Equipped
SERVICING AND MAINTENANCE NOTE: should be lubricated periodically with a lithium based Avoid using the wiper blades to remove frost or ice from grease, such as Mopar® Spray White Lube to assure the windshield or rear window. Make sure that they Use only manufacturer approved A/C system PAG quiet, easy operation and to protect against rust and are not frozen to the glass before turning them on to...
Page 263 SERVICING AND MAINTENANCE Lift the wiper arm to raise the wiper blade off of the glass, until the wiper arm is in the full up position. Wiper Blade With Release Wiper Blade Removed From Wiper Arm Tab In Unlocked Position 1 —...
Page 264: Rear Wiper Blade Removal/Installation
SERVICING AND MAINTENANCE 1 — Wiper Blade Slide the wiper blade up into the hook on the wiper 2 — Wiper Arm arm and rotate the wiper blade until it is flush 3 — Wiper Arm Pivot Cap against the wiper arm. Fold down the latch release tab and snap it into its locked position.
Page 265: Exhaust System
SERVICING AND MAINTENANCE NOTE: fumes to seep into the passenger compartment. In Still holding the bottom end of the wiper blade, addition, have the exhaust system inspected each time move the wiper blade upward and away from the The rear wiper arm cannot be fully raised off the the vehicle is raised for lubrication or oil change.
Page 266: Cooling System
SERVICING AND MAINTENANCE cool. Service, including a tune-up to manufacturer's CAUTION! WARNING! specifications, should be obtained immediately. performance and cause serious damage to the ● Keep hands, tools, clothing, and jewelry away from To minimize the possibility of catalytic converter engine.
Page 267: Selection Of Coolant
SERVICING AND MAINTENANCE lead to severe internal engine damage. If any coolant ● meets the requirements of the manufacturer Material Do not use water alone or alcohol-based engine is needed to be added to the system please contact an Standard MS.90032. When adding engine coolant: coolant products.
Page 268: Cooling System Pressure Cap
SERVICING AND MAINTENANCE is needed to be added to the system, please contact As long as the engine operating temperature is WARNING! a local authorized dealer. satisfactory, the coolant bottle need only be checked scalding or injury, do not remove the pressure cap once a month.
Page 269: Brake Master Cylinder
SERVICING AND MAINTENANCE Refer to the “Service and Warranty Handbook” for the ● Check the coolant freeze point in the radiator and in WARNING! proper maintenance intervals. the coolant expansion bottle. If engine coolant needs to be added, the contents of the coolant expansion ●...
Page 270: Automatic Transmission - If Equipped
SERVICING AND MAINTENANCE Lubricant Selection the transmission has no dipstick. An authorized dealer WARNING! can check your transmission fluid level using special be damaged, causing partial or complete brake Use only the manufacturers recommended service tools. If you notice fluid leakage or transmission ð...
Page 271: General Information
SERVICING AND MAINTENANCE Use only the manufacturer's specified transmission WARNING! CAUTION! ð fluid page 307. It is important to maintain replace a blown fuse with metal wires or any the transmission fluid at the correct level using the If it is necessary to wash the engine compartment, other material.
Page 272: Power Distribution Center/Fuses
SERVICING AND MAINTENANCE Power Distribution Center/Fuses CAUTION! The Front Power Distribution Center is located in the positioned and fully latched. Failure to do so may engine compartment. This module contains fuses and allow water to get into the power distribution center relays.
Page 273 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description * If Equipped – – Spare 40 Amp Green – SCR* 20 Amp Blue – SLM Feed LT* 30 Amp Pink – AGSM / DCSM / TCM / DTCM / SCCM 20 Amp Blue –...
Page 274 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description * If Equipped 40 Amp Green – Starter Motor Solenoid * 40 Amp Green – HVAC Fan – – Spare – 2 Amp Fuse Grey Steering Column Control Module (SCCM) Engine Control Module (ECM) / Radiator –...
Page 275 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description * If Equipped – 20 Amp Yellow Lumbar Adjust (Driver Seat Only)* Engine Control Module (ECM) / Fuel Injec- – 25 Amp Clear tors / PCM / ECM-UREA / PCM UREA –...
Page 276 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description * If Equipped F34A & B – – Spare – – Spare – 10 Amp Red Port UCI2 / Mod CVPM – 10 Amp Red Powertrain Control Module (PCM) – 10 Amp Red ECM/TCM/AGSM/DCSM/STM –...
Page 277 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description * If Equipped – – Spare – – Spare Drivetrain Control Module (DTCM) AWD – 30 Amp Green Power / DTCM-ECU Power – 30 Amp Green Front Windshield Defrost * – –...
Page 278 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description * If Equipped Automatic Gearbox Shifter Module – 5 Amp Tan (AGSM) – – Spare – – Spare – – Spare – 10 Amp Red PM SNSR – 20 Amp Yellow RR Power Outlet (12 Volt APO) –...
Page 279: Interior Fuses
SERVICING AND MAINTENANCE Cavity Cartridge Fuse Mini Fuse Description * If Equipped – 5 Amp Tan Intelligent Battery Sensor (IBS) – 15 Amp Blue MOD DCSD / Handsfree Liftgate / UCI + – 10 Amp Red USB Port / HRLS –...
Page 280 SERVICING AND MAINTENANCE Cavity Blade Fuse Description 7.5 Amp Brown Occupant Restraint Controller 20 Amp Yellow Window Motor Passenger 20 Amp Yellow Window Motor Driver Intrusion Module/Siren, Radio, UCI/USB Port, VSU, Climate Control, Electronic Steering 20 Amp Yellow Lock, Power Folding Mirrors, Security Gateway/DTV Instrument Panel Cluster, Drivetrain Control Module, Adaptive Cruise, ECC (HVAC) 10 Amp Red Blower...
Page 281: Rear Cargo Fuse/Relay Distribution Unit
SERVICING AND MAINTENANCE Cavity Blade Fuse Description Park Assist, Blind Spot, Voltage Stabilizer, Humidity Sensor, Electronic Steering Lock, 7.5 Amp Brown Temp Sense, Mirror, Heated Seats, Light And Rain Sensor, Start Stop Switch 7.5 Amp Brown Occupant Restraint Controller Electronic Climate Control, Occupant Classification, Rear View Camera, Climate Con- 7.5 Amp Brown trol, Headlamp Leveling, Terrain Select, Heated Rear Window, Trailer Tow, Haptic Lane 7.5 Amp Brown...
Page 282 SERVICING AND MAINTENANCE Cavity Mini Fuse Description * If Equipped 30 Amp Green Memory Seat 20 Amp Yellow Sunroof* 30 Amp Green Power Seat (Passenger Side) – Not Used 7.5 Amp Brown Power Lumbar (Power Seats) Heated Steering Wheel / Ventilated Seats / Comfort 15 Amp Blue Seats and Wheel Module (CSWM) Heated Seats* / Comfort Seats and Wheel Module...
Page 283 SERVICING AND MAINTENANCE On the Rear Cargo Fuse/Relay Distribution Unit bracket, there is a Maxi Fuse Holder for the Power Liftgate and an ATO / Uni Val Fuse Holder for the HIFI Audio System. Inline Fuse Holder Cavity Maxi Fuse Description * If Equipped 30 Amp Green...
Page 284: Bulb Replacement
SERVICING AND MAINTENANCE NOTE: EPLACEMENT The following bulb list may change without notice, Replacement Bulbs, Names, And Part always replace bulbs with the same bulb number as indicated on the bulb being replaced. See an authorized Numbers dealer for LED bulb replacement. In the instance a bulb needs to be replaced, this section includes bulb description and replacement part numbers.
Page 285 SERVICING AND MAINTENANCE Exterior Bulbs Lamps Bulb Number Low Beam Headlamps High Beam Headlamps Front Position/Daytime Running Lights (DRL) Base: WY21W Front Direction Indicator Lamps Premium: LED Front Position Front Fog Lamps Side Indicators (Front – HID) Side Indicators (Side View Mirror) Rear Side Indicators WY16 Rear Fog Lamps...
Page 286: Replacing Exterior Bulbs
SERVICING AND MAINTENANCE Exterior Bulbs Lamps Bulb Number Premium Tail Lights: LED Tail/Brake Lights Base Tail Lights: W21W LL W21WLL For Premium Tail Lamps Turn Signal Light W21/5WLL For Base Tail Lamps Center High Mounted Stop Lamp (CHMSL) License Plate Lamp Liftgate Lamp Reverse W21WLL Liftgate Lamp Tail...
Page 287 SERVICING AND MAINTENANCE Side Indicators The Side Indicators are LED. See an authorized dealer for replacement. Rear Body Side Tail Lamps Contain the following: ● Position lights ● Stop lights ● Direction indicator Body Side Tail Lamp Reverse Side of Tail Lamp To replace the bulbs proceed as follows: 1 —...
Page 288 SERVICING AND MAINTENANCE Rear Fog Lamps Reinstall the body side lamp making sure to align the ball studs. Using a suitable non-marking tool, carefully pry at NOTE: the top inboard edge of the fog lamp to disengage the snap features. Ensure uniform gap between body and lamp assembly.
Page 289: Replacing Interior Bulbs
SERVICING AND MAINTENANCE Replacing Interior Bulbs WARNING! account the technical characteristics can cause Front Courtesy Light malfunctions with the risk of fire. To replace the bulbs proceed as follows: ● Halogen lamps contain gas under pressure, in the Using a suitable tool remove the front courtesy event of breakage be careful of the projection of light assembly.
Page 290 SERVICING AND MAINTENANCE Dome Light Glove Compartment Replace the bulbs by pulling straight out of bulb Replace the bulb, releasing it from the side housing. contacts, and then insert the new bulb, making To replace the bulb proceed as follows: sure that it is properly locked between the contacts.
Page 291 SERVICING AND MAINTENANCE Dome Light To replace the bulbs proceed as follows: Lower the handle in the direction shown; remove the dome light. Bulb Bulb Holder Insert the new bulb, locking it between the Fully disengage the bulb holder from the housing. contacts.
Page 292: Tire Markings
SERVICING AND MAINTENANCE Tire Markings Rotate bulb holder to replace bulb. WARNING! of the emitted light and you can also affect the life of the lamp. In case of accidental contact, rub the bulb with a cloth dampened with alcohol and allow to dry.
Page 293: Tire Loading And Tire Pressure
SERVICING AND MAINTENANCE Tire Loading And Tire Pressure This placard tells you important information about the: Number of people that can be carried in the NOTE: vehicle. The proper cold tire inflation pressure is listed on the driver’s side B-pillar or the rear edge of the driver's side Total weight your vehicle can carry.
Page 294: Tires - General Information
SERVICING AND MAINTENANCE — G Tread Wear IRES ENERAL NFORMATION WARNING! Improper cold tire inflation pressures can cause ● Overinflated or underinflated tires can affect Tire Pressure abnormal wear patterns and reduced tread life, vehicle handling and can fail suddenly, resulting resulting in the need for earlier tire replacement.
Page 295: Tire Pressures For High Speed Operation
SERVICING AND MAINTENANCE Tire pressure may increase from 2 to 6 psi (13 to Radial Ply Tires CAUTION! 40 kPa) during operation. DO NOT reduce this normal moisture and dirt from entering the valve stem, which pressure buildup or your tire pressure will be too low. WARNING! could damage the valve stem.
Page 296: Tire Spinning
SERVICING AND MAINTENANCE Run Flat Tires — If Equipped or for longer than 30 seconds continuously without stopping. Run Flat tires allow you the capability to drive 50 miles ð For further information page 249. (80 km) at 50 mph (80 km/h) after a rapid loss of inflation pressure.
Page 297: Replacement Tires
SERVICING AND MAINTENANCE Keep dismounted tires in a cool, dry place with as little ● Tire pressure - Improper cold tire inflation pressures WARNING! exposure to light as possible. Protect tires from contact can cause uneven wear patterns to develop across with oil, grease, and gasoline.
Page 298: Tire Types
SERVICING AND MAINTENANCE prohibit studded tires; therefore, local laws should be YPES WARNING! checked before using these tire types. All Season Tires — If Equipped Do not use Summer tires in snow/ice conditions. You — I PARE IRES QUIPPED could lose vehicle control, resulting in severe injury or All Season tires provide traction for all seasons (Spring, death.
Page 299: Tire Rotation Recommendations
SERVICING AND MAINTENANCE Compact Spare Tire — If Equipped the original equipment tire and reinstall on the vehicle WARNING! at the first opportunity. The compact spare is for temporary emergency use tread wear indicators, the temporary use spare tire only. You can identify if your vehicle is equipped with needs to be replaced.
Page 300: Storing The Vehicle
SERVICING AND MAINTENANCE to maintain mud, snow, and wet traction levels, and damage to the compressor when the vehicle is put CAUTION! contribute to a smooth, quiet ride. back into operation. Proper operation of four-wheel drive vehicles depends Refer to the “Service and Warranty Handbook” for the NOTE: on tires of equal size, type and circumference on proper maintenance intervals.
Page 301: What Causes Corrosion
SERVICING AND MAINTENANCE vehicle is operated, extreme hot or cold weather and using mild (neutral Ph) soap and water to maintain equipment to prevent damage to the wheels. Mopar® other extreme conditions will have an adverse effect on their luster and to prevent corrosion. Wash wheels with Wheel Treatment or Mopar®...
Page 302: Cleaning Headlights
SERVICING AND MAINTENANCE Dark Vapor Chrome, Black Satin Chrome, or Low Gloss Do not use abrasive cleaning components, solvents, CAUTION! Clear Coat Wheels steel wool or other aggressive material to clean the lenses. ● Do not use abrasive or strong cleaning materials CAUTION! such as steel wool or scouring powder that will RESERVING...
Page 303: Seats And Fabric Parts
SERVICING AND MAINTENANCE Stain Repel Fabric Cleaning Procedure — Sun damage can also weaken the fabric. Replace the ● If your vehicle is damaged due to a collision or belts if they appear frayed or worn or if the buckles do similar cause that destroys the paint and protective If Equipped not work properly.
Page 304: Cleaning Plastic Instrument Cluster Lenses
SERVICING AND MAINTENANCE a soft cloth and Mopar® Total Clean. Care should be When cleaning the rearview mirror, spray cleaner on the CAUTION! taken to avoid soaking your leather upholstery with towel or cloth that you are using. Do not spray cleaner may cause permanent damage.
Page 305: Technical Specifications
TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER (VIN) The VIN is found on the left front corner of the windshield and is visible from outside of the vehicle. The VIN number also is stamped into the right front body, on the front floor. With the right front seat in the rear most position, a door in the carpet can be opened to reveal the VIN.
Page 306: Torque Specifications
TECHNICAL SPECIFICATIONS vehicle will be much greater than that required with the the vehicle, the lug nuts/bolts should be torqued using power system operating. a properly calibrated torque wrench using a six-sided (hex) deep wall socket. If either of the two hydraulic systems lose normal capability, the remaining system will still function with ORQUE PECIFICATIONS...
Page 307: Fuel Requirements - Diesel Engine
TECHNICAL SPECIFICATIONS When using or parking the vehicle for a long time in the WARNING! mountains or cold areas, it is advisable to refuel using has been lowered. Failure to follow this warning may locally available fuel. In this case, it is also advisable to result in personal injury.
Page 308: Fluid Capacities
TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) All Engines 15.9 gal 60 L AdBlue® (UREA) Fluid Tank — If Equipped 3.4 gal 13 L Engine Oil With Filter 2.0L Diesel Engine 5.1 qt 4.8 L Cooling System* 2.0L Diesel Engine 6.8 qt 6.5 L * Includes heater and coolant recovery bottle filled to MAX level.
Page 309: Engine Fluids And Lubricants
TECHNICAL SPECIFICATIONS ENGINE FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part We recommend using Mopar® Antifreeze/Coolant 10 Year/150,000 mile (240,000 Engine Coolant kilometers) Formula OAT (Organic Additive Technology) meeting the requirements of the manufacturer Material Standard MS.90032. We recommend using (API certified SAE 5W-30 ACEA C2 - FCA 9.55535-S1 synthetic Engine Oil –...
Page 310 TECHNICAL SPECIFICATIONS Component Fluid, Lubricant, or Genuine Part Use only Mopar® AW-1 Automatic Transmission Fluid or equivalent. Failure to use the Automatic Transmission 6 Speed (FWD Models) – If Equipped correct fluid may affect the function or performance of your transmission. Use only Mopar®...
Page 311 TECHNICAL SPECIFICATIONS Component Fluid, Lubricant, or Genuine Part Refrigerant R-134a — If Equipped Charge Amount: All engines — 567 g (1.25 lb) Refrigerant Refrigerant R-1234yf — If Equipped Charge Amount: All engines — 482 g (1.063 lb) Use Only PAG Oil ND12: Compressor Oil 2.0L Diesel engines —...
Page 312: Customer Assistance
CUSTOMER ASSISTANCE CUSTOMER ASSISTANCE ● INDIA When you contact the distributor please provide all of IF YOU NEED ASSISTANCE the following information: Should this fail to resolve the problem, contact FCA India Customer Relations: ● Your name, address, and phone number FCAIO’s distributors are vitally interested in your FCA India Automobiles Private Limited ●...
Page 313 INDEX Air Conditioner System ........259 Audio Systems (Radio) ........Air Conditioning Filter ....... 56, Auto Down Power Windows ....... Air Conditioning, Operating Tips ......56 Auto Hold ............Active Speed Limiter ........132 Air Filter ............Automatic Dimming Mirror ........ Adding Engine Coolant (Antifreeze) ....265 Air Pressure Automatic Door Locks...
Page 314 Capacities, Fluid ..........Console ...............58 Caps, Filler Cooling Pressure Cap (Radiator Cap) .....266 Oil (Engine) ..........256 Cooling System ..........B-Pillar Location ..........291 Radiator (Coolant Pressure) ...... Adding Coolant (Antifreeze) ....... Battery ............. 100, Car Washes ............Coolant Level ........264, Charging System Light ........100 Carbon Monoxide Warning...
Page 315 Defroster, Windshield ........Electric Parking Brake ........Engine Oil Viscosity ..........258 Diagnostic System, Onboard ......109 Electrical Power Outlets ........59 Enhanced Accident Response Feature . 208, Diesel Electronic Stability Control (ESC) ....180 Exhaust Gas Cautions ........Display Messages ......... Electronic Throttle Control Warning Light ..100 Exhaust System ........
Page 316 Fog Lights, Rear ..........Fold-Flat Seats ........... Folding Rear Seats ..........35 Hazard Warning Flashers ........228 Ignition ..............Freeing A Stuck Vehicle ........Head Restraints ..........Switch ............Fuel ..............Head Rests ............Illuminated Entry ..........Light .............103 Headlights ............Inside Rearview Mirror ......39, Octane Rating ........
Page 317 Interior Fuses ........... Brake Assist Warning ......... Interior Lights ............. Brake Warning ..........99 iPod/USB/MP3 Control ........Bulb Replacement ........Lane Change And Turn Signals ....42, Cruise ............Lane Change Assist ........42, Daytime Running ........42, LaneSense ............107 Diesel Particulate Filter (DPF) Cleaning Lap/Shoulder Belts ..........191 In Progress ..........
Page 318 Hood Open ..........Towing Hook Breakdown ......Maintenance Free Battery .......257 Immobilizer Fail VPS Electrical Alarm ..106 Traction Control ...........182 Malfunction Indicator Light (Check Engine) ...103 Instrument Cluster ........Turn Signals ......42, 45, 108, Manual Transmission ......124, Intensity Control ..........Vanity Mirror ..........
Page 319 Outside Rearview Mirrors ......39, Overheating, Engine ........New Vehicle Break-In Period ......Radial Ply Tires ..........Radiator Cap (Coolant Pressure Cap) .... Radio Operation ..........Radio Remote Controls ........175 Paddle Shifters ..........Rain Sensitive Wiper System ......Paint Care ............Occupant Restraints ........189 Rear Camera ............
Page 320 Roof Type Carrier ..........73 Pretensioners ..........Shoulder Belts ..........191 Rotation, Tires ..........Rear Seat .............191 Side View Mirror Adjustment ...... 39, Reminder .............190 Signals, Turn ......42, 45, 108, Seat Belt Pretensioner ....... Snow Tires ............296 Seat Belt Reminder ........Spare Tires ..........
Page 321 Stuck, Freeing ..........Inflation Pressure ........Automatic ........... 120, Sun Roof ............64, Jacking ............Maintenance ..........268 Sun Visor ............Life Of Tires ..........Manual ............Supplemental Restraint System – Air Bag ..198 Load Capacity ..........Tread Wear Indicators ........Pressure Monitoring System (TPMS) 104, Turn Signals ........
Page 322 Voice Command ..........Wipers Blade Replacement ......Voice Recognition System (VR) ......Wipers, Rain Sensitive ........48 Wireless Charging Pad ........61 Warnings, Roll Over ..........10 Washers, Windshield .........47, Washing Vehicle ..........300 Weights Label ...........147 Wheel And Wheel Tire Care ......Wheel And Wheel Tire Trim ......Wind Buffeting ...........
Page 324 1 800 102 5337 ROADSIDE ASSISTANCE First Edition ©2024 FCA US LLC. All Rights Reserved. Jeep is a registered trademark of FCA US LLC. 25_M6_OM_EN_IN App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

Jeep COMPASS 2025 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Jeep COMPASS 2025

Summary of Contents for Jeep COMPASS 2025
