Network Telephone Interfaces

See also,

Telephony Interfaces

Interface
Number of Channels/TMS (Inbound/
Outbound)
Modularity
Total / MPS 500
Network Interface
Line Impedance
Line Coding
Cable Length
Connector Type
DTMF Input Level
Tone ON Time
Tone OFF Time
Freq. Deviation
Tone Twist
1. The European Conference of Postal and Telecommunications Administrations
Telephony Interfaces

Digital Interfaces

RJ48M

The TMS connects to the public switched telephone network (PSTN) through a USOC RJ48M 50-
pin connector located on the front panel of each DCC. This interface provides capacity for up to
eight T1 or E1 spans. The digital interface connections for span/line 1 are shown in the following
illustration. Connections for all spans are listed in the following table.
October 2014
on page 195.
North American
24, 48, 72, 96, or 192 (1, 2, 3, 4 or 8
T1 Spans)
24 Channels (1 T1)
8 Spans /192 Channels
1.544 Mbps ±75 bps Bipolar, Return
to Zero, D4 Framing (ESF Optional)
100 Ohms
AMI or B8Zs
Up to 600 ft.
RJ48M or RJ48C
+1 to -27 dBm
40 milliseconds
40 milliseconds
± 1.5%
-10 dB to + 10 dB
Avaya Media Processing Server 500 Hardware Installation and Maintenance
Comments? infodev@avaya.com
Network Telephone Interfaces
1
CEPT
30, 60, 90, 120, or 240 (1, 2, 3,
4, or 8 E1 Spans)
30 Channels (1 E1)
8 Spans /240 Channels
2.048 ± 100 bps Bipolar,
Return to Zero
120 Ohms Twisted Pair
HDB3
Ref - G.703
RJ48M or RJ48C
+1 to -27 dBm
40 milliseconds
40 milliseconds
± 1.5%
-10 dB to + 10 dB
