Manual of NVUM_SP
X Axis selected switch
9 X-IN
Y Axis selected switch
10 Y-IN
Z Axis selected switch
11 Z-IN
A Axis selected switch
12 A-IN
B Axis selected switch
13 B-IN
C Axis selected switch
14 C-IN
1 X multiplication
15 1X
switch
10X multiplication
16 10X
switch
100X multiplication
17 100X
switch
MPG Estop
18 ESTOP
Table 2-2. NVUM_SP on MPG's define and explaination
Short connect with GND meanas selecting X
aixs,cutoff means don't select
Short connect with GND meanas selecting Y
aixs,cutoff means don't select
Short connect with GND meanas selecting Z
aixs,cutoff means don't select
Short connect with GND meanas selecting A
aixs,cutoff means don't select
Short connect with GND meanas selecting B
aixs,cutoff means don't select
Short connect with GND meanas selecting C
aixs,cutoff means don't select
short connect with
multiplication,cutoff means no pulse
short connect with
multiplication,cutoff means no pulse
short connect with
multiplication,cutoff means no pulse
short connect with
effective,cutoff show invalid
- 12 -
www.nvcnc.com
GND means 1X
GND means 10X
GND means 100X
GND means Estop
