C� Power Requirements
The machine should be connected to a
standard 120 volt AC, three-wire grounded
outlet only.
Do not connect this machine to an outlet or
power line shared with other appliances that
cause "electrical noise." Air conditioners, electric
typewriters, copiers, and machines of this sort
generate electrical noise that often interferes
with communications equipment and the
sending and receiving of documents.
Connection of the Equipment
This equipment complies with Part 68 of the
FCC rules and the requirements adopted by the
ACTA. On the rear panel of this equipment is a
label that contains, among other information, a
product identifier in the format
US:AAAEQ##TXXXX. If requested, this number
must be provided to the telephone company.
The REN is used to determine the number of
devices that may be connected to a telephone
line. Excessive RENs on a telephone line may
result in the devices not ringing in response to
an incoming call. In most, but not all areas, the
sum of RENs should not exceed five (5.0). To be
certain of the number of devices that may be
connected to a line, as determined by the total
RENs, contact the local telephone company. For
products approved after July 23, 2001, the REN
for this product is part of the product identifier
that has the format US:AAAEQ##TXXXX. The
digits represented by ## are the REN without a
decimal point (e.g., 03 is a REN of 0.3).
An FCC compliant telephone line cable and
modular plug is provided with this equipment.
This equipment is designed to be connected to
the telephone network or premise wiring using
a compatible modular jack that is Part 68
This equipment may not be used on coin
service provided by the telephone company.
Connection to party lines is subjected to state
In Case of Equipment Malfunction
Should any malfunction occur which cannot be
corrected by the procedures described in the
User's Guide, disconnect the equipment from
the telephone line cable and disconnect the
power cord. The telephone line cable should
not be reconnected or the main power switch
turned ON until the problem is completely
resolved. Users should contact their local
authorized Canon Facsimile Service Dealer for
the servicing of equipment.
If your equipment malfunctions, please contact
your local authorized Canon dealer from whom
you purchased the equipment (if under
warranty), or with whom you have a servicing
contract. If you are not sure who to contact, and
have both purchased and are using the
equipment in the U.S.A., please refer to the
"SUPPORT" page on Canon U.S.A.'s Web site
Rights of the Telephone Company
If this equipment imagePRESS C165 causes
harm to the telephone network, the telephone
company may temporarily disconnect service.
The telephone company also retains the right
to make changes in facilities and services that
may affect the operation of this equipment.
When such changes are necessary, the
telephone company is required to give
adequate prior notice to the user. However, if
advance notice is not possible, the telephone
company will notify the customer as soon as
possible. Also, the customer will be advised of
his/her right to file a complaint with the FCC if
he/she believes it is necessary.
The Telephone Consumer Protection Act of
1991 makes it unlawful for any person to use a
computer or other electronic device, including
FAX machines, to send any message unless
such message clearly contains in a margin at
the top or bottom of each transmitted page or
on the first page of the transmission, the date
and time it is sent and an identification of the
business or other entity, or other individual
sending the message and the telephone
number of the sending machine or such
business, other entity, or individual. (The
telephone number provided may not be a 900
number or any other number for which charges
exceed local or long distance transmission
In order to program this information into your
machine, you should complete the procedure
for registering your name, unit's telephone
number, time, and date as described in Setting
Up or Basic Operations in the User's Guide.
Users in Canada
Preinstallation Requirements for Canon
Facsimile Equipment
The fax function is available only if the FAX
Board is installed.
A� Location
Supply a suitable table, cabinet, or desk for the
See "Specifications" in the User's Guide for
specific dimensions and weight.
B� Order Information
1. A single telephone line (touch-tone or
rotary) should be used. If the Super G3 2nd
Line Fax Board is installed, a multi telephone
line (touch-tone or rotary) can be used.
2. Order a CA11A modular jack which should
be installed by the telephone company. If
the CA11A jack is not present, installation
cannot occur.
3. Order a normal business line from your
telephone company's business
representative. The line should be a regular
voice grade line or an equivalent one. Use
one line per unit. If the Super G3 2nd Line Fax
Board is installed, you can use a multi-line.
DDD (Direct Distance Dial) line
IDDD (International Direct Distance Dial) line if
you communicate overseas
Canon recommends an individual line following
industry standards, i.e., 2500 (touch-tone) or 500
(rotary/pulse dial) telephones. A dedicated
extension off a PBX (Private Branch eXchange)
unit without "Call Waiting" can be used with
your facsimile unit. Key telephone systems are
not recommended because they send
nonstandard signals to individual telephones
for ringing and special codes, which may cause
a facsimile error.
C� Power Requirements
The power outlet should be a three-prong
grounded receptacle (Single or Duplex). It
should be independent from copiers, heaters,
air conditioners, or any electric equipment that
is thermostatically controlled. The rated value is
115 volts and 15 amperes. The CA11A modular
jack should be relatively close to the power
outlet to facilitate installation.
This product meets the applicable Innovation,
Science and Economic Development Canada
technical specifications.
Before installing this equipment, users should
ensure that it is permissible to be connected
to the facilities of the local
telecommunications company. The
equipment must also be installed using an
acceptable method of connection. In some
cases, the company's inside wiring associated
with a single line individual service may be
extended by means of a certified connector
assembly (telephone extension cord). The
customer should be aware that compliance
with the above conditions may not prevent
deterioration of service in some situations.
The Ringer Equivalence Number (REN)
indicates the maximum number of devices
allowed to be connected to a telephone
interface. The termination of an interface may
consist of any combination of devices subject
only to the requirement that the sum of the
RENs of all the devices not exceed five.
The REN of this product is 1.0.
Repairs to certified equipment should be
made by an authorized Canadian
maintenance facility designated by the
supplier. Any repairs or alterations made by
the user to this equipment, or equipment
malfunctions, may give the
telecommunications company cause to
request the user to disconnect the
Users should ensure for their own protection
that the electrical ground connections of the
power utility, telephone lines, and internal
metallic water pipe system, if present, are
connected together. This precaution may be
particularly important in rural areas.
Users should not attempt to make such
connections themselves, but should contact
the appropriate electric inspection authority, or
electrician, as appropriate.
This equipment complies with the Canadian
ICES-003 Class A limits.
Utilisation au Canada
Conditions à Remplir Préalablement à
L'installation d'un Télécopieur Canon
La fonction de Fax est disponible uniquement
lorsqu'une carte FAX est installee.
A� Emplacement
Prévoir une table, un meuble, ou un bureau
suffisamment solide et de taille appropriée (voir
"Spécifications" dans le guide de l'utilisateur
pour les indications de poids et dimensions).
B� Installation téléphonique
1. Une seule ligne téléphonique (tonalités ou
impulsions) doit être utilisée. Si le Super G3
