Preset Timing Modes
If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen
will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED
is on. Refer to the video card manual and adjust the screen as follows.
Table 1. Preset Timing Modes
Display Mode
VESA, 640 x 480
VESA, 640 x 480
VESA, 800 x 600
VESA, 800 x 600
VESA, 800 x 600
VESA, 800 x 600
VESA, 1024 x 768
VESA, 1024 x 768
VESA, 1024 x 768
VESA, 1280 x 1024
VESA, 1280 x 1024
SUN, 1152 x 900
SUN, 1152 x 900
SUN, 1280 x 1024
Copyright(c) 2004, Sun Microsystems, Inc. All rights reserved.
Horizontal Vertical
Frequency Frequency
(kHz)
37.500 75.000
37.861 72.809
35.156 56.250
37.879 60.317
46.875 75.000
48.077 72.188
48.363 60.004
56.476 70.069
60.023 75.029
63.981 60.020
79.976 75.025
61.846 66.003
71.810 76.150
81.129 76.106
Horizontal Frequency
The time to scan one line connecting the right edge to the left
edge of the screen horizontally is called Horizontal Cycle and the
inverse number of the Horizontal Cycle is called Horizontal
Frequency. Unit: kHz
Vertical Frequency
Like a fluorescent lamp. the screen has to repeat the same image
many times per second to display an image to the user. The
frequency of this repetition is called Vertical Frequency or Refresh
Rate. Unit: Hz
Pixel Clock
(MHz)
(Hz)
31.500
31.500
36.000
40.000
49.500
50.000
65.000
75.000
78.750
108.00
135.00
94.500
108.00
135.00
