6. S/PDIF Input/Output
75 Ω S/PDIF inputs for use with compatible equipment.
7. ADAT Connectors
One input & one output with up to 8 channels per line.
8. Thunderbolt™ port
Connect your interface to a Thunderbolt™ 2 or 3 port using a Thunderbolt™ cable (not included).
Windows users – please read the Antelope Audio Windows Thunderbolt Driver page.
9. USB High-Speed
Connect your interface to a USB port on a Windows or Mac computer with the bundled USB cable.
10. Word Clock Outputs
Two Word Clock outputs on BNC connectors for syncing external gear.
11. Stereo Monitor Output
Assignable balanced stereo output (left channel at the top and right channel below).
12. Line Outputs
Four assignable Line outputs on TRS connectors.

13. Mic/Line Inputs

Two console-grade Class A mic pres with discrete transistor design and individual phantom power. Mic input on XLR
connector, Line input on TRS connector.
