1. SAVE Button

Saves the current preset for future use & sharing.
2. LOAD Button
Loads a previously saved preset.
3. BP ALL Button
Instantly bypasses all effects processing.
4. DEL ALL Button
Instantly removes all effects currently loaded in the rack.
5. Presets Menu
Choose a preset from the drop-down menu.
6. ADD NEW EFFECT Menu
Choose an effect from the various categories and add it to the FX rack.
7. BP Button
Appears next to an effect – used to bypass it.
8. HOW TO Button
Launches a YouTube channel with Antelope Audio video tutorials to help you master the Control Panel & FX.
3.4 Routing System

3.4.1 Inputs and Outputs

In the routing system, the inputs and outputs of the Discrete 4 SC are organized as follows:
• General
• Digital Outs
•
Analog Outs
•
DAW
PREAMP 1-4
These are the 4 Discrete Mic Preamps.
COMPUTER PLAY 1-16
These are your DAW outputs, up to 16 channels.
ADAT IN 1-8
These are the 8 ADAT digital inputs.
