SEA SWING 2 DG R2F Manual

Electronic control unit for 1 or 2 230v/115v motors
Hide thumbs Also See for SWING 2 DG R2F:

Advertisement

Quick Links

n lis
International registered trademark n. 804888
SWING
DG R F
CT
C C
T
T
M T
SEA
S.p.A.
ona Ind striale Sant Atto
2
eramo I A
elephone
Fa
.seateam.com
seacom seateam.com
2
Re .
2/2

Advertisement

loading
Need help?

Need help?

Do you have a question about the SWING 2 DG R2F and is the answer not in the manual?

Questions and answers

Summary of Contents for SEA SWING 2 DG R2F

  • Page 1 n lis International registered trademark n. 804888 SWING DG R F S.p.A. ona Ind striale Sant Atto eramo I A elephone .seateam.com seacom seateam.com Re .
  • Page 2 English COMPONENTS TECHNICAL SPECIFICATIONS Control unit power supply: 230 Vac 50/60 Hz - 115Vac 50/60 Hz Absorption in stand by: 30 mA Environment temperature : -20°C +50°C Specifications of external enclosure: 183 X 238 X 120 - Ip55 120 mm JOLLY 3 RECEIVER RX LE CARD...
  • Page 3 English CONNECTIONS 10 11 12 13 14 15 16 17 18 19 CN6 ** CN8 *** LSC1 LSC1 20 21 22 23 24 25 26 27 LSO1 LSO2 The indicated load of 500 mA refers to the maximum load distributed on the two 24V outputs The limit switch connector CN6 is only available on version SWING 2 DG with limit switch (FC) CN8 dry contact connector (for general use, for example staircase lights timer activation) supports a maximum load of 3A - 250V.
  • Page 4 English PROGRAMMING QUICK START PROGRAMMING BUTTONS MENU MENU LANGUAGE ITALIANO DOWN Skip this step if you do not want to program a transmitter OK to exit Press the Menu or press MENU MENU MENU MENU button of the PRESS the button of TRANSMITTERS START STORED...
  • Page 5 English WORKING TIMES SELF LEARNING The control unit is pre-set with the default settings, to start the control unit with the DEFAULT settings just keep pressed the UP and DOWN buttons at the same time power supplying the control unit the display shows the message “Init”. The DEFAULT settings are shown in the Menues table.
  • Page 6: Function Logic

    English FUNCTION LOGIC AUTOMATIC LOGIC A start impulse opens the gate. A second impluse during the opening will not be accepted. A start impulse during closing reverses the movement. NOTE 1: To have the automatic closing it is necessary to set a pause time, otherwise all the logic will be semi-automatic.
  • Page 7 SWING 2 DG R2F MENU FUNCTIONS TABLE MENU DESCRIPTION DEFAULT VALUE Italiano Italian English English 1 LANGUAGE Français French English Español Spanish Dutch Dutch Start Start Partial opening Partial opening External module External module Stop Stop Storing of a command for unlocking the electric...
  • Page 8: Special Menu

    PRESS AT THE SAME TIME FOR 5 SECONDS TO ENTER OR TO EXIT THE SPECIAL MENU DOW N SPECIAL MENU FUNCTIONS TABLE SWING 2 DG R2F For entering into the special menu move on one of the menu and press the UP and DOWN buttons at the same time for 5 seconds...
  • Page 9 MENU SP DESCRIPTION DEFAULT VALUE 10% (Fast intervention) Adjusts Encoder Potentiometer OPENING SENSITIVITY 99% (Slow intervention) intervention time on Motor 1 in opening MOTOR 1 Off (Intervention excluded) Disabled 10% (Fast intervention) Adjusts Encoder Potentiometer CLOSING SENSITIVITY 99% (Slow intervention) intervention time on Motor 1 in closing MOTOR 1 Off (Intervention excluded)
  • Page 10 MENU SP DESCRIPTION DEFAULT VALUE From OFF to 50% of the stroke. On hydraulic 61 OPENING SLOWDOWN 2 Off (*) Hydraulic operators the slowdown will be hydraulic over the depends on motor From OFF to 50% of the stroke. On hydraulic 62 CLOSING SLOWDOWN 2 Off (*) Hydraulic...
  • Page 11 MENU SP DESCRIPTION DEFAULT VALUE With limit-switches, it adds an extra time to the 83 EXTRA TIME 0.0 s 10 s movement of the motors after the limit-switches 0.0 s reading 84 BRAKE 100% Adjusts the braking on the limit switches Only closing Pre-flashing only active before closing 85 PRE-FLASHING...
  • Page 12 MENU SP DESCRIPTION DEFAULT VALUE activated, photocell reverses Closing movement in closing; during the pause, it prevents the reclosing If activated, it blocks the movement as long as it is Opening and closing busy; when released, the opening movement continues If the photocell is activated before the Start input, the Start will be ignored.
  • Page 13 MENU SP DESCRIPTION DEFAULT VALUE Normal Normal N.C. contact 100 SECURITY EDGE 1 Normal Active edge protected by a 8K2 resistor Opening and closing Active in opening and closing Opening SECURITY EDGE 1 Only opening Active only in opening DIRECTION Closing Only closing Active only in closing...
  • Page 14 If the password has been forgotten, the only way to unlock the control unit is to contact the SEA technical assistance, which will assess whether to provide the procedure to unlock the control unit or not.
  • Page 15 Photocell 2 DOWN Note: The limit switches will be displayed only on version with limit switch MENU FUNCTION TABLE CHECK SWING 2 DG R2F INPUTS To access the Menu for input check keep pressed OK for about 5 seconds. Description...
  • Page 16 English RADIO TRANSMITTER SELF LEARNING WITH RECEIVER ON BOARD OF CONTROL UNIT WARNING: Make the radio transmitters programming before you connect the antenna and insert the receiver into the special CMR connector (if available) with turned off control unit. With RF UNI and RF UNI PG module it will be possible to use both Coccinella Roll Plus transmitters and radio transmitters with fixed code.
  • Page 17 English RADIO TRANSMITTER SELF LEARNING WITH RECEIVER RF FIX ON BOARD OF CONTROL UNIT WARNING: Make the radio transmitters programming before you connect the antenna and insert the receiver into the special CNS connector (if available) with turned off control unit. With the RF FIX module it will be possible to use only radio controls with fixed code.
  • Page 18 n lis START - STOP - PARTIAL START - ANTENNA - PHOTOCELL hotocell and hotocell 2 onnections Note If the photocells are not connected, it is not necessar put a umper between the clamps 12-13-14 of the CN1 terminal). 2 Accessories mA ma hotocell contact...
  • Page 19: Power Supply

    n lis MOTORS CONNECTION, CAPACITY AND POWER SUPPLY ap M ap M2 Motor Motor 2 connection M Opening /Closing Com COMMON Example Motor to be connected in case of single-leaf. Motor 2 Motor 1 connection Opening/Closing COMMON Example WER S E For power suppl connection follow the rules in force...
  • Page 20 n lis SAFETY EDGE AND FLASHING LAMP SAFE EDGE It is possible to connect a safet edge (ED E 1) between the contacts 22 and 23 of Cn5. The ED E 1 contact, when squeezed, causes the partial inversion of the m o t i o n i n b o t h o p e n i n g a n d c l o s i n g .
  • Page 21: Alarm Description

    English TRAFFIC LIGHT CARD CONNECTION 24V~ / (ac/dc) 230V~ Connect on EXP terminal 1 CNP ALARM DESCRIPTION Signals Kind of alarm Solutions Make sure there are no short circuits on the motor or on the Motors current FAILURE MOTOR control unit failure 24V Power supply Make sure there are no short circuits on the wiring or on the...
  • Page 22 English Advices Make sure all Safeties are turned ON Problem Found Possible Cause Solutions a) Check the connections or the jumpers on the connections of Operator doesn’t respond to a) Check the connected N.C. contacts the safety edge or of the stop and of the photocell if connected any START impulse b) Burnt fuse b) Replace the burnt fuse on the control unit...
  • Page 23 English Advices Make sure all Safeties are turned ON Problem Found Possible Cause Solutions a) Check menu for encoder parameters "Encoder Par" shall be from a low value +/- 10 (gate completely closed) to "Encoder a) ENCODER is not working properly if It's tot"...
  • Page 24 Materials handling must be made with appropriate vehicles.. WARRANTY LIMITS For the guarantee see the sales conditions SEA reserves the right to make any required modification or change to the products and/or to this manual without any advanced notice obligation.
  • Page 25 Transport of the goods sold shall be at Bu er s cost and ris . SEA shall not bear the costs of deliver giving the goods to the carrier, as chosen either b SEA or b the Bu er. An loss and/or damage of the goods during transport, are at Bu er s cost.
  • Page 26 5. Do not install the equipment in an explosive atmosphere. 6. SEA S.p.A. is not responsible for failure to observe ood Techniques in the construction of the loc ing elements to motorize, or for an deformation that ma occur during use.
