8 Technical Data

Model
Inverter
Nominal battery voltage
Input voltage range
Nominal power @ 25°C
Maximum load 30 min. @ 25°C
Maximum load 5 sec
Maximum load
Maximum asymmetric load
Standby adjustment
Cos ϕ
Maximum efficiency
Consumption OFF/Standby/ON
Output voltage
Output frequency crystal controlled
Total harmonic distortion
Dynamic behaviour on load change 0 → 100 %
Overload and short circuit protection
Overheat protection
Battery charger (4 STEP) I-U-Uo-Equalize (every 25 cycles)
Charging current adjustable
Input current balance adjustment (Power Sharing)
Maximum input voltage
Minimum input voltage
Input frequency
Power Factor Correction (PFC)
Battery control (thresholds and times adjustable by the user)
Absorption time
End charge cycle voltage
Floating voltage
Equalisation voltage
Deep-discharge protection
Temperature compensation (option CT-35)
General data
Multifunction contact - potential free (3 points)
Max. current on transfer relay
Transfer time
Weight
Dimension h x l x L [mm]
IP protection index
EEC conformity
Working range
Ventilation
Acoustic level without / with ventilation
Recommended battery capacity (C10)
Warranty
Options
Remote control (112 x138 x 25mm / 20 m cable)
Remote power sharing (20 m. cable)
Battery temp. sensor (58 x 51.5x 22mm / 3 m cable)
Data may change without any notice
User manual
HPC2512 HPC4024
12 V
9.5 – 17 V 19 – 34 V
2500 W
2800 W
93 %
1.4/1.8/10 W 1.7/2/16 W
Automatic disconnection with 3 time restart attempt
Acoustic warning before shut-off - with automatic restart
0 – 110 A 0 – 100 A
1 – 30 A
Adjustable threshold from 150 to 230 Vac
14.4 V
13.6 V
15.6 V
10.8 V
30 A / 6.9 kVA 30 A / 6.9 kVA
33 kg
242/288/480
EN50081 I/II, EN 55014 – EN 55022, EN 61000-3-2
IEC 801 I/II/III/IV, CEI 555, IEC 1000-3-2, LVD 73/23/EEC
-20 to 55°C
from 45°C
< 10 dB / < 35 dB
> 5 x Pnom/Unom
2 years
RCC-01
RPS-01
CT-35
HP-COMPACT V3.0 E
