Access the [TEMPO/RHYTHM] "TmpMap" tab
page.
Select "TempoMap," and turn the [VALUE] dial to
select tempo map event "001".
Press the "Edit" button to open the "Select
TempoMap 001 Param" dialog box.
Use "Tempo" to set the tempo, "Beat" to set the time
signature, and "Rhythm" to specify the rhythm
pattern.
You cannot change the starting location (Start
Measure) of tempo map event "001".
You can only specify the ending location (End
Measure).
When you have finished making settings, press the
"OK" button.
3. Add tempo map events to change the tempo, time
signature, and rhythm pattern during the song.
Press the "New" button to display "Select TempoMap
002 Param".
Use "Meas" to specify the beginning (Start Measure)
and end (End Measure) of the tempo map event you
want to create. Use "Tempo" to specify the desired
tempo, "Beat" to specify the time signature, and
"Rhythm" to select a rhythm pattern. If you want to
overwrite the existing tempo map event, press the
"Insert" button to turn it off.
Press the "OK" button to add the tempo map event.
The tempo map events are renumbered from
beginning to end.
By adding tempo map events and using "Rhythm" to
change rhythm patterns, you can create drum
patterns for an entire song, including intro, fill-in,
and ending.
To delete or modify a tempo map event
You can delete an unwanted tempo map event, or modify
its measure location or tempo settings etc.
1. Select the tempo map event that you want to delete
or modify.
Access the [TEMPO/RHYTHM] "TmpMap" tab
page.
Select "TempoMap," and turn the [VALUE] dial to
select the appropriate tempo map event.
2. Delete or modify the tempo map event.
If you want to delete it, press the "Delete" button. A
message will ask you "AreYouSure?"
Press the "OK" button to delete the tempo map event
you selected in step 1. By turning the "SelectAll" but-
ton on (highlighted), you can delete all tempo map
events except for tempo map event "001".
You cannot Undo this operation.
If you want to modify the tempo map event, press
the "Edit" button to open the dialog box. Edit the
parameters as desired.
Tempo track
The tempo track records MIDI clock data from an
external device such as a MIDI sequencer, or records tap
tempo.
Recording MIDI clock data from an external MIDI
sequencer, and using it as the tempo track
Here's how MIDI clock tempo data from an external
MIDI sequencer can be recorded on the tempo track.
Use this when you wish to synchronize the D1600mkII
song with song data created on a MIDI sequencer in
which the tempo changes continuously.
1. Specify the time signature of the song.
If the time signature of the MIDI sequencer song data
changes during the song, you should create tempo
maps at the locations where the time signature
changes. (→"Tempo map")
If the time signature changes during the song, it
will be detected as an incorrect tempo unless you
have created a tempo map that matches the
changes in time signature. There is no need to
specify the tempo.
2. Connect the MIDI OUT of your MIDI sequencer to
the [MIDI IN] connector of the D1600mkII.
3. Make settings on your MIDI sequencer so that it
will transmit MIDI clock messages.
Refer to the owner's manual for your MIDI
sequencer.
4. Specify how tempo will be recorded.
In the [TEMPO/RHYTHM] "TmpTrk" tab page,
select "MIDI Clock."
5. Record the MIDI clock data.
Press the "RecStart" button to put the D1600mkII in
record-ready mode.
Start your MIDI sequencer.
When MIDI clock messages are received from the
MIDI sequencer, the display will indicate "Receiving-
MIDIClock."
6. When the MIDI sequencer finishes playing back,
stop the MIDI sequencer.
The D1600mkII will stop recording, and will display
"Complete." Press the "OK" button.
73
