C100 HDS Software Update
Editing Cuts
To edit a Cut, select the Cut's Player and ensure that the Playlist button is not lit. Select the Cut with the Master
scroller then touch the Cut Edit button. The following window will open:
Audition controls
Start indicator
Current play
position
Note that the Cut Edit window can also be accessed from the Playlist Edit and Trigger Setup windows.
Important Note: Players must be in Stop before you enter the Cut Edit Page.
Touching the Fade In, Fade Out, Level, Start or Cut Tail title boxes will assign their associated value to the Master
Scroller. Alternatively, touching any of the value boxes will open a calculator pop-up in which a new value can be typed –
Clear sets the value to 0, Cancel cancels the pop-up along with any changes types, and Enter closes the pop-up and
activates the new value.
The following values regarding the playout behaviour of the Cut can be set:
Start The start time of the Cut
Cut Tail The end time of the Cut
Fade In The length of the fade in.
Fade Out The length of the fade out. (measured in length; Range = 0 – 9.99s)
Level Any level trim for the file.
Once a Start, Cut Tail, Fade In or Fade Out title box has been selected, the Master Scroller arrow buttons can be
used to cycle between Start and Cut Tail, or Fade In and Fade Out, or – if Loop is activated – all four.
Start
value
File Fade In
Start Start
The graphic at the base of the screen indicates the Start and Cut Tail values, and displays a progress bar during auditions.
Beneath the graphic is a numeric display of the edited Cut's Duration.
Note that the values associated with all of these parameters are always active, regardless of whether or not their title box
is highlighted.
Page 12
(from the start of the audio file; Range = 0 – 59.99s)
(from the end of the audio file; Range = 0 – 59.99s)
(measured in length; Range = 0 – 9.99s)
(Fade in starts at the Start time)
(Fade out ends at the Cut Tail time)
(Range = ±20dB)
Fade In value
Fade In
End
Fade Out value
Fade Out
Start
Close Cut Edit
'Title box'. Touch to edit
value with Master Scroller
'Value box'. Touch to edit
value with keypad pop-up
Cut Tail indicator
Cut
Tail
value
Cut File
End End
